Platinum TFP- Operation And Installation Manual

Whole house air cleaner
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Table of Contents
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
TFP Questions & Answers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Materials Supplied . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
NOTE: Due to ongoing research and product development, specifications, ratings and dimensions are subject to change without notice.
Operation and Installation Manual
Whole House Air
Cleaner
Model
TFP-PLATINUM
Type 1 Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-6
Type 2 Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Type 3 Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8-9
Operating Instructions and Annual Check-up . . . . . . . . . . . . . . .10
Wiring Diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
69-TFP-PLATINUM
100716

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TFP-PLATINUM and is the answer not in the manual?

Questions and answers

Summary of Contents for Platinum TFP-PLATINUM

  • Page 1 Cleaner Model TFP-PLATINUM Table of Contents Overview ..........2 Type 1 Installation .

  • Page 2: Overview

    Particles are forced out into areas of no turbulence... and stay Fabric particle collector and aluminum spacer panels there because there is no airflow Model TFP-Platinum NOTE Collector and HEPA Filter life Part # 65-503 expectancy is based on normal Replace collector...

  • Page 3: Tfp Questions & Answers

    TFP Questions & Answers Why do I need a Platinum TrueHEPA?The air in today's homes is 3 to 5 times more polluted than outdoor air creating health problems such as asthma, allergies, headaches, and fatigue for the home's occupants. The Platinum TrueHEPA TFP Air Cleaner will remove 99% of these polluting particles from your home creating a clean and comfortable environment for you and your family.

  • Page 4: Specifications

    Easy to remove for cleaning and replacement. Annual inspection recommended. MOUNTING THE AIR CLEANER 29" 737 mm The TFP-PLATINUM air cleaner is to be mounted directly to the return duct of the forced air system. ON / OFF SWITCH OPTIONS...

  • Page 5: Operating Instructions And Annual Check-Up

    When new collectors are required, call your secondary collector is replaced every 3 years. dealer. As each home differs in size, occupancy, Model TFP-PLATINUM - 1 TFP Collector, 1 location, infiltration rates and homeowner HEPA filter needs, an estimation of when to change the collectors is difficult.

  • Page 6: Wiring Diagram

    Wiring Diagram DOOR SWITCH Line BLACK 120 VAC 60 Hz Neutral WHITE Ground GREEN 370V~50/60H CAPACITOR WHITE CAUTION /ATTENTION ELECTRICAL CONTROL PANEL, GREEN/YELLOW SERVICE BY TRAINED TECHNICIAN ONLY FAN MOTOR DISCONNECT POWER SUPPLY BEFORE SERVICING.
  • Page 7 410 Third St London, Ontario Canada N5W 4W6 Tel: (519) 686-3595 Toll Free: 1-877-339-4701 www.platinumaircare.ca LEAVE FOR HOMEOWNER TO BE COMPLETED BY CONTRACTOR AFTER INSTALLATION Installing Contractor _________________________________________Telephone / Contact _____________________ Serial Number______________________________________________Installation Date ________________________ Model _________________________________________________________________________________________...
