Summary of Contents for Strong Frontier TE800-T
- Page 1 08-09-01-007-0 Tire Pressure Monitoring System OWNER’S MANUAL An advance tire pressure monitoring system that gives you the maximum control...
- Page 2 TABLE OF CONTENTS Notices ……………………………………………………………………………..….……………... Page 1 FCC Notice System Scope of Use and Warnings System Installation and Usage Reacting To Alerts Use of Chemicals 1. Technical Specifications ……………………………………………………………………………. Page 2 Sensor/Transmitter Module Display/Receiver Module 2. Components Part List ……..………………………………………………………………………... Page 3 3.
- Page 3 1. TECHNICAL SPECIFICATION Sensor / Transmitter Module Operating Temperature Range -40°C to +125°C Operating Humidity 100% Weight 32 gram Size (LxWxH) 71 mm x 36 mm x 21 mm Battery Life (Projected) 5 years in normal use Transmitting Frequency 433.92 MHz Transmitter Activation By pressure change Table 1...
- Page 4 3. GETTING STARTED Troubleshooting Guide How it works Symptoms Possible cause(s) Solution Pressure and temperature information are sent to the Receiver and displayed on the LCD display. When an under- No display on LCD panel. No power. Check connections of Power cable at both inflated, over-inflated or over-heated tire is detected, the Receiver will emit an audible warning and activate the ends.
- Page 5 Sensor ID Learning Mode (S- 4) Installing Sensor/Transmitter Module For programming of a new receiver unit with ID Learning Mode, refer to the following steps. The following is suggested installation sequence: Step 1 Transmitter Wheel Position Press [OK] button to enter the ID learning Mode. Red (1) Left Front Yellow (2)
- Page 6 Recommended Installation for Display/Receiver Module and Bracket Programming Threshold Setting (S- 2) Press [OK] to enter the Threshold setting mode. There are two available threshold setting mode available, 1. User setting (USr) 2. Factory Default (FAC) Figure 25 Upon entering this mode, the selected threshold setting mode will blink, indicating that the currently selected mode and it is ready to accept changes of the mode.
- Page 7 6. PROGRAMMING Display Mode (S- 1) Press [OK] to enter programming display mode. ‘ror’ or ‘noL’ will blink to indicate that it is ready to accept changes. Toggle [+] or [-] button to alternate between Rotation Mode and Normal Mode. Rotation Mode Figure 20 Each of the tires will be ‘scanned’...
- Page 8 5. DISPLAY/RECEIVER MODULE Sensor ID Exchange Mode (S- 3) Pressure in Kpa Measured Pressure Pressure in Psi Readout After rotation of tires, the Sensor ID data in the receiver must be changed accordingly to ensure that it indicates Pressure in Bar. the correct tire when there are any irregularities.
- Page 9 4. SENSOR/TRANSMITTER MODULE Turn Backlight On/Off (S- 5) Installation For programming backlight setting, refer to the following steps. 1. Backlight On (Permanent On) Caution: Qualified personnel must perform the following installation 2. Backlight Off (Auto) procedures to ensure that the Sensor/Transmitter Module are properly installed and undamaged.
- Page 10 Annexes 2. COMPONENTS PART LIST Annex I After unpacking, ensure that all the parts listed below are available. Should any part(s) is/are found missing, please Psi To Kpa To Psi Conversion Table return to your dealer and get a complete replacement set. Kpa to Psi Conversion Table Item Description...
- Page 11 NOTICE FCC Notice This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
