Summary of Contents for Rhino Motion EVO
- Page 4 ATTACHING MOTION Back out the accessory studs...
- Page 5 ATTACHING MOTION Place the motor on the drive shaft press down to compress the o-ring (if motor doesn’t drop in place, move the carriage slightly to align the shafts) Tighten the accessory studs to lock the motor in place...
- Page 6 PLUG IN MOTOR Align cable on the controller and plug in connector. For added security, fasten the retention screw to the controller...
- Page 7 PREPARE FOR SHOOTING Unlock carriage brake and you’re ready to start filming. Note: Rhino Motion will not work if the brake is locked in place...
- Page 8 POWER ON CONTROLLER Press and hold the power button to turn on the Controller...
- Page 9 BASIC FUNCTIONS Push in the Controller wheel to select menu items and change values. Use the back button to go back and exit menus...
- Page 10 SELECT YOUR SLIDER Choose the slider you are installing Rhino Motion on. Note: when changing sliders or rail lengths it is important to change your slider in settings...
- Page 11 HOME Live Motion, Time Lapse & Settings...
- Page 12 LIVE MOTION Select Turn Wheel to Slide or Create a Move...
- Page 13 CALIBRATE Before entering modes, Rhino Motion will auto calibrate to set its end points...
- Page 14 TURN WHEEL TO SLIDE Turn wheel to adjust direction and speed. Press wheel in to stop...
- Page 15 CREATE A MOVE Program a move with in and out points, ramping, and looping...
- Page 16 TIME LAPSE Select Simple Time Lapse or Advanced Time Lapse (must use included cable)
- Page 17 SIMPLE TIME LASPE Choose your distance, direction, and duration...
- Page 18 ADVANCED TIME LAPSE Choose your exposure, duration, and playback time...
- Page 19 MOTOR DOCK The Controller docks on the back of the motor for quick access...
- Page 20 TRIPOD DOCK The Controller also docks on the tripod for hands-free use...
- Page 21 CHARGING Using the included charger, Rhino Motion charges fully in about 3 hours. Under normal operation the battery will last about 7 hours. If you enable power saving mode in Settings, you can get up to 24 hours of battery in Advanced Time Lapse...
- Page 24 Thank You for purchasing Rhino Motion EVO. If you have any questions or comments, please email: support@rhinocg.com...
