iKON AVS DPA-40 Manual

DPA-40 Amplifier
The Ikon DPA-40 is a 20 watt per channel stereo wall and
dado mounting amplifier. It is ideal for multi-room audio,
classroom, hotel bedroom and small meeting room
applications.
Ikon AVS Reliability through quality & simplicity
Introduction
Available in brushed stainless steel, a flat white or black finish, the
DPA-40 fits a standard UK format double back box and requires only
a 35mm depth.
The DPA-40 uses an 86% efficient class D design and has a RMS*
output of 20 watts per channel into 8 Ohms when powered from an
18V power supply or 10 watts when powered by the included 12V
power supply, and as most quality loudspeakers are 8 Ohms,
maximum efficiency is assured. Additionally the amplifier also has
remote shutdown ability adopting an ultra low power standby state.
It is fitted with rear inputs on screw terminals for permanent
connections and a 3.5mm stereo jack on the front panel for other
sources making the DPA-40 easy to install & use.
Supplied Parts
The amplifier kit is supplied complete with:-
•
The amplifier module itself.
•
2 x M3.5 panel fixing screws.
•
12V switched mode power supply.
• 1
Mains power cable .
•
Instruction manual.
Please either retain packaging for future use or dispose of via
recycling. All packaging is recyclable.
Overview
The Ikon DPA-40 is a wall mounted amplifier with twin unbalanced
audio inputs. Input 1 is on the rear and connected via screw
terminals. Input 2 is on the front panel as a 3.5mm stereo jack
socket. Inserting a jack into the front socket will automatically
disconnect the rear input.
1
The mains power cable will be country specific and may
be supplied external to the main amplifier packaging.
