Summary of Contents for SEOHWA SHPR19-F1
- Page 1 User’s Manual for Wireless Repeater Model No : SHPR19-F1 ( PCS 1.9G Pico Repeater ) SEOHWA TELECOM CO., LTD. Seohwa Telecom 1page Rev. 1.0...
- Page 2 1. AGC : Automatic Gain Control 2. ALC : Automatic Limit Control 3. Automatic output interception function (MUTE) 4. RSSI : Received Signal Strength Emission 5. Small size, light - weight 6. Simple installation & Maintenance Seohwa Telecom 2page Rev. 1.0...
- Page 3 Name & Function by each parts - Front- - Side - - Back Side - Seohwa Telecom 3page Rev. 1.0...
- Page 4 It is shut down against more than +9dBm signal automatically. - MUTE LED ( Red Colored Lamp ) : ON for a 5sec and OFF for a 2sec, repeatedly - RSSI LED ( Green Colored Lamp ) : OFF Seohwa Telecom 4page Rev. 1.0...
- Page 5 Exterior adapter having AC 100– 240V input supplies DC 7 V power to the repeater to run active circuits. RG400 RF Cable RG 400 RF Cable, which is used for connecting with feeding cable coming from Donor antenna. Bracket The bracket is used for fixing the repeater on the wall. Seohwa Telecom 5page Rev. 1.0...
- Page 6 Fix repeater body on a wall Installation exterior antenna & Laying Feeding Cables Measurement of Receiving Level from Base Station Connect power supply adapter Adjust the direction of Antenna Inspection Testing for calling quality Completion Seohwa Telecom 6page Rev. 1.0...
- Page 7 Caution: Make sure 120V available to connect power transformer (do not power up) Adjust the direction of Antenna To improve calling qualities, adjust the direction of Patch Antenna in front of body. Testing for calling qualities Seohwa Telecom 7page Rev. 1.0...
-
Page 8: Troubleshooting
Check a failure of the repeater and input of Auto shutdown wrong signal into the repeater 3) For more information, call Seohwa Telecom Co., Ltd. at 82- 2 - 838 – 5511. Seohwa Telecom 8page Rev. 1.0... -
Page 9: Specifications
Mechanical Specifications -10 ~ +50 °C Operating Temp. Cooling Convection Input/Output Connector SMA (Female) Power 7 V DC / 100 ~ 240 V AC Dimensions (W x H x D) 180x120x50 mm Weight 800 g Seohwa Telecom 9page Rev. 1.0...
