Summary of Contents for Speedx Mustang
- Page 3 You can log in website SPEEDX.COM to check out the video of opening the box. Please read "Bicycle manual " to get more help.
- Page 4 Unpacking Operation...
- Page 5 STEP 1 Open carton box...
- Page 6 STEP 2 Take out the bicycle Take out the bicycle from the carton box and clip front fork in cartons box. Untie the bundled bicycle cushion and Velcro and blocks of front tire and handlebar, and disassemble the rest protective films. Turn on the front fork to the right direction and check out the appearance of the bicycle.
- Page 7 STEP 3 Install front wheel Disassemble the protective sheets and the protective bar of the front fork, turn on the front fork to the right direction. Keep the front tire’s bearing and the back tire’s bearing to the same direction, put the front wheel’s bearing into the front wheel. (Front wheel need to be the center of the front fork without deviation).
- Page 8 STEP 4 Install handlebar Take out the aheadset Stem ’s lower cap, put the handlebar to the aheadset Stem and align the center graduated line, screw four screws into the screw hole, slightly fixed, align aheadset Stem to the graduated line of handlebar. Adjust the handlebar’s angle, align aheadste Stem’s “0”...
- Page 9 STEP 5 Install seat tube Connect the power cord inside the seat tube with the power cord inside the frame tube and insert those to the card slot. Please check out whether the intelligent control open normally and the taillight light up normally. Smear the specials lubricant for carbon fiber on the sat tube, insert the seat tube to the frame tube.
- Page 10 STEP 6 Install pedal Distinguish the direction between left and right of the pedal R = Right L = Left. Lock the pedal into the crank with a M6 inner hexagon and rotate pedal with front direction. Until all the pedal is locked into the tooth pattern, force slowly to lock the pedal tighten.
- Page 11 STEP 8 Pump up tire Based on rider’s weight and riding environment, pump up the tire’s pressure value to 100PSI at least.(Refer the tire’s pressure value to 100-145PSI/70-10BAR). Tighten inner tube’s gas nozzle, and lock tighten the gas nozzle cap to the gas nozzle.
- Page 12 Intelligent control instruction...
- Page 13 Power on and Standby 1. Power on: When the seat tube wire is connected, the intelligent control is automatically activated. 2. Standby: After stop riding 5 minutes, the intelligent control will automatically be standby. 3. Wake-up: When press the primary key or detect motion, the intelligent control will be awakened, and can recover the values before standby.
- Page 14 Mileage TIME Average Velocity Left Key Right Key Edition Electricity Primary Key...
- Page 15 2. Install the “Beast riding” APP on your phone (two-dimen- sional code) Scan the right two-dimensional code or log in SPEEDX.COM / APP. HTML to download, support Android 4.4 and iOS 8.0 or more advanced systems, support BLE (Bluetooth 4.0).
- Page 16 Connectting... Conntectting... BACK Mustang Control Center language setting After successful connection, click “setting” on the upper right corner, select the language which you need, save and return. Unit setting After successful connection, click “setting” on the upper right corner, select the mileage unit...
- Page 17 Riding Record Start riding First press the primary key for a long time to enter the reset page, as the installation process will produce displacement. Again press the primary Long press start a new riding key for a long time to clear the current riding data, and start a new riding. Short press to continue riding Pause riding In the riding process, press the primary key for a long time to enter the...
- Page 18 Check bicycle After successfully assembled, please check out bicycle. Start your MUSTANG riding trip. whether the brake is sensitive whether the cushion and cushion’s lever are locked whether the brake’s disc is rubbed whether the pedal is locked whether the chain will be dropped...
- Page 20 FCC statements: This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
