Summary of Contents for Direct Place 1022301
- Page 1 Scandi - 2 Door 3 Drawer Wardrobe Assembly Instructions - 1022301 Please keep for future reference Dimensions Width 81.1 cm Depth 49.0 cm Height 191.3 cm Assembly Instructions - Please keep for future reference Issue 1 - 15-10-2012 350209 MDF...
- Page 2 ! Safety and Care Advice Important - Please read these instructions fully before starting assembly • Check you have all the • Do not stand or put weight on components and tools listed on the product, this could cause pages 2 and 3. damage.
- Page 3 Components - Panels Please check you have all the panels listed below Top/bottom (78,1 cm x 47,2 cm) Plinth, back (78,1 cm x 6 cm) Plinth, front (79,3 cm x 9,6 cm) Top rail (79,2 cm x 8 cm) Back (174,1 cm x 39,7 cm) Side, right (183,3 cm x 47,5 cm)
- Page 4 Components - Fittings Please check you have all the panels listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required. ø7.8 x 40mm Wooden dowel x ø6 x 30mm Wooden dowel x 12 ø3.5 x 15mm Screw x ø3 x 12mm Screw x...
- Page 5 Assembly Instructions Step 1 Fix the drawer sides to the drawer back shown, using screws Step 2 Knock the dowels into the holes indicated on the drawer sides using a smal hammer. Step 3 Slide the drawer bottom into the drawer sides Step 4 Screw the bolts...
-
Page 6: Step
Assembly Instructions Step 6 Important! Make sure the 90° 90° angle between the drawer front 90° the drawer sides is 90° 90° before the drawer bottom 90° is fixed. Fix the drawer bottom the drawer back and the drawer front using To adjust the angle between the drawer sides and the... -
Page 7: Step
Assembly Instructions Step 9 Slide the top of the drawer runners backwards. Fix the front end of the drawer runners to the sides using screws through the holes indicated. See details. Step 10 Slide the top of the draw- er runners forwards. -
Page 8: Step
Assembly Instructions Step 11 Knock the dowels into the holes indicated on the top/bottom the back plinth using a small hammer. Press the magnets into the holes indicated on the top/bottom Step 12 Place the sides onto the , the bottom and the back plinth... -
Page 9: Sides
Assembly Instructions Step 14 Place the backs into the rabbets in the sides and the H-profile Important! Make sure the angle between the top and the sides is 90° when the backs is attached. Fix the backs to the sides , the top and the back plinth using nails... -
Page 10: Step
Assembly Instructions Step 16 Warning! The wardrobe is heavy. Lift with care. Its recommended that the Wall strap and instruction wardrobe is fixed to the wall. Use the fittings . Follow the instructions included with the fittings. Pull out the drawer runners. - Page 11 Assembly Instructions Step 17 Place the cup hinges into the holes indicated on the doors Fix the hinges using screws Fix the magnet catches using screws into the holes indicated. Step 18 Place the hanger rail into the supports Slide the cup hinges onto the crossplates Fix the hinges using the premounted screw in the...
- Page 12 Assembly Instructions Step 19 Adjusting the doors left/right. To adjust the door towards the left hand side - turn the adjusting screw to the right. To adjust the door towards the right hand side - turn the adjusting screw to the left. Adjusting the doors forwards/backwards.
