Summary of Contents for Furniture 2 Go 1022501
- Page 1 Scandi - 3 Door 5 Drawer Wardrobe Assembly Instructions - 1022501 Please keep for future reference Dimensions Width 120.9 cm Depth 49.0 cm Height 191.3 cm Assembly Instructions - Please keep for future reference Issue 1 - 22-10-2012 350212 MDF...
- Page 2 ! Safety and Care Advice Important - Please read these instructions fully before starting assembly • Check you have all the • Do not stand or put weight on components and tools listed on the product, this could cause pages 3 and 4. damage.
- Page 3 Components - Panels Please check you have all the panels listed below (117,9 cm x 47,2 cm) Bottom (117,9 cm x 47,2 cm) Plinth, back (117,9 cm x 6 cm) Plinth, front (119,1 cm x 9,6 cm) Divider (139,3 cm x 47,2 cm) Top rail (119 cm x 8 cm) Divider, small...
-
Page 4: Tools Required
Components - Fittings Please check you have all the panels listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required. ø7.8 x 40mm Wooden dowel x ø6 x 30mm Wooden dowel x 20 ø4 x 60mm Screw x ø3.5 x 15mm Screw x... - Page 5 Assembly Instructions Step 1 Fix the drawer sides to the drawer backs as shown, using screws Step 2 Knock the dowels into the holes indicated on the drawer sides using a smal hammer. Step 3 Slide the drawer bottoms into the drawer sides Step 4 Screw the bolts...
-
Page 6: Step
Assembly Instructions Step 5 Push the drawer fronts onto the drawer sides shown. Push cams into the holes indicated. Arrow pointing towards the front. Turn the cams to the right to fix the front Step 6 90° Important! 90° 90° 90°... -
Page 7: Step
Assembly Instructions Step 8 Knock the dowels into the holes indicated on the back plinths , the and the bottom using a small hammer. Press the magnets into the holes indicated on the top and the bottom Screw the bolts into the holes indicated on the top... -
Page 8: Step
Assembly Instructions Step 10 Slide the top of the drawer runners backwards. Fix the front end of the drawer runners to the sides using screws through the holes indicated. See details. Step 11 Slide the top of the draw- er runners forwards. -
Page 9: Step
Assembly Instructions Step 12 Slide the top of the drawer runner backwards. Fix the front end of the drawer runners to the dividers using screws through the holes indicated. See details. Slide the top of the drawer runners forwards and fix the back end of the drawer runners to the... - Page 10 Assembly Instructions Step 15 Press the dividers onto the bottom Push cams into the holes indicated on the dividers . Arrows pointing towards the bottom Turn cams to the right to fix the dividers Step 16 Fix the plinths to the dividers using screws...
- Page 11 Assembly Instructions Step 17 Place the divider onto the plints Push cams into the holes indicated on the divider . Arrows pointing towards the plinths Turn the cams to the right to fix the divider Step 18 Place the sides onto the top the bottom and the...
- Page 12 Assembly Instructions Step 19 Place the backs into the rabbets in the sides and the H-profile Important! Make sure the angle between the top and the sides is 90° when the backs is attached. Fix the backs using nails . Use the nail holder and a small hammer.
- Page 13 Assembly Instructions Step 21 Place the top rail onto the top Fix the top rail to the using angles and screws Step 22 Warning! The wardrobe is heavy. Lift with care. Its recommended that the wardrobe is fixed to the wall. Wall strap and instruction Use the fittings .
- Page 14 Assembly Instructions Step 23 Place the cup hinges into the holes indicated on the doors Fix the hinges using screws Fix the magnet catches using screws into the holes indicated. 350212-14 MDF...
- Page 15 Assembly Instructions Step 24 Fix the supports for hangerrails onto the sides and the divider using screws Step 25 Place the hanger rail into the supports Slide the cup hinges onto the crossplates Fix the hinges using the premounted screw in the crossplates.
- Page 16 Assembly Instructions Step 26 Adjusting the doors left/right. To adjust the door towards the left hand side - turn the adjusting screw to the right. To adjust the door towards the right hand side - turn the adjusting screw to the left. Adjusting the doors forwards/backwards.
