Security Solutions, Inc. VPTZ-100 Operating Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Notes on Safety
Please read the instructions & quick setting guide thoroughly
◎
before installing or operating the unit.
Please do not mount the machine on an unstable surface or
◎
bracket.
Please prevent liquids or other material from entering the
◎
dome housing.
When connecting the power source, please follow all
◎
electrical safety standards and procedures. Use only the power
supply designed for this device. The speed dome's RS-485 and
video signal uses TVS technology to protect it from strong
electrical surges. This technology prevents damage to the
device resulting from impulse signals such as lightning strikes
or surges of power. Allow for enough distance between the
RS-485 and video signals and high-voltage equipment or
cables during the transmission process. Please do not power
the unit until all connections are secure and installation is
complete.
Avoid shooting very bright objects directly into the camera's
◎
CCD (such as the sun or light fittings).
When the machine is not operating properly, please refer to
◎
the instructions for information about how to service or repair
0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VPTZ-100 and is the answer not in the manual?

Questions and answers

Summary of Contents for Security Solutions, Inc. VPTZ-100

  • Page 1 Notes on Safety Please read the instructions & quick setting guide thoroughly ◎ before installing or operating the unit. Please do not mount the machine on an unstable surface or ◎ bracket. Please prevent liquids or other material from entering the ◎...
  • Page 2 your speed dome. Please protect the unit against extremes of vibration, ◎ pressure or dampness while transporting unit. Damage can occur from improperly packaging the unit while shipping. The outdoor dome camera system is designed to be installed ◎ in outdoor environments only.
  • Page 3 INDEX Ⅰ. INTRODUCTION………………………………………………………….…..1 Ⅱ. TECHNICAL DATA…………………………………………………………...1 Ⅲ. SETTINGS……………………………………………………………….…….2 3.1 XTS-SO10XDN-WP D DDRESS RANSMISSION PEED ROTOCOL ETTING ......................... 3 3.1.1 S PEED AMERA OMMUNICATION DDRESS ETTING ....4 3.1.2 S PEED AMERA OMMUNICATION ROTOCOL ETTING ....4 3.1.3 S PEED AMERA RANSMISSION PEED ETTING...
  • Page 4 4.7 M EMORY UNCTION OWER OFF ............12 4.8 A REPOSITION ..................12 V. CAMERA MENU (OSD MENU) SETTING…………………………………13 5.1 S YSTEM NFORMATION .................. 13 5.2 S OSD S PEED ETTING WITH ONTROL EYBOARD ......14 VI. CAMERA OPTIONAL FUNCTIONS……………………………………….24 6.1 A LARM INKAGE...

  • Page 5: Ⅰ. Introduction

    Ⅰ . Introduction Congratulations on purchasing our speed dome, an intelligent, high-speed dome with a high-performance DSP camera and sophisticated zoom lens. It is an advanced technological surveillance product combining an all-direction variable speed dome and digital decoder all in one unit. It can aim quickly and scan continuously, making omni-directional and non-blind-spot monitoring into reality.

  • Page 6: Ⅲ. Settings

    Outdoor Indoor Model Day/Night Speed Dome Speed Dome Power Supply AC24V±4V Operating temperature - 40 ~+60 ℃ ℃ 0 ~+40 ℃ ℃ Operating moisture ≤95% Power consumption ≤20W Communication RS-485 bus Communication transmission speed 1200bps / 2400bps / 4800bps / 9600bps Horizontal rotation speed 0.1°...
  • Page 7 setting of VT-100K. XTS-SO10XDN-WP Dome Address, Transmission Speed, Protocol Setting Before the dome is installed, the communication protocol, baud rate and dome address, should be confirmed. Set the code switch, keeping the setting consistent with the control system. The relative code switch site and connecting wires are diagramed below for reference.
  • Page 8 3.1.1 Speed Dome Camera Communication Address Setting The communication address code for the speed dome should be properly set before use to ensure accurate addressing of the dome at the control center and to control several dome cameras. The address code is made up of SW3 (8 bits) on PCB board. The 8 bit switch uses the 8421 binary coded decimal system.
  • Page 9 3.1.3 Speed Dome Camera Transmission Speed Setting (Baud Rate Setting) The 4th and 5th bits of SW2 on the PCB board are used to set the baud rate (see following figure). The default baud rate setting is 9600 bps. Baud Rate Options: 1200bps 、2400bps 、4800bps、9600bps Please refer to the controlling device and protocol for baud rate requirement.

  • Page 10: R Esistance

    3.1.4 RS-485 Bus Matching Resistance For better centralized control, a matching resistance should be connected in a parallel way at the connecting port where the RS-485 is connected into the device which is the furthest away from the center controller. By doing this, reflection and interference from the RS-485 signal and the like can be cleared up.
  • Page 11 3.2.1 Speed Dome Camera Communication Address...
  • Page 12 Setting The communication address code for the speed dome should be properly set before use to ensure accurate addressing of the dome at the control center and to control several dome cameras. The address code is made up of SW3 (8 bits) on PCB board. The 8 bit switch uses the 8421 binary coded decimal system.

  • Page 13: R Esistance

    Baud Rate Options: 1200bps 、2400bps 、4800bps、9600bps Please refer to the controlling device and protocol for baud rate requirement. 3.2.4 RS-485 Bus Matching Resistance For better centralized control, a matching resistance should be connected in a parallel way at the connecting port where the RS-485 is connected into the device which is the furthest away from the center controller.

  • Page 14: Iv. Basic Function Of Dome Camera

    IV. Basic Function of Dome Camera Use the keyboard controller to utilize the complete potential of the speed dome. (The keyboard control protocol is set as the default protocol for the speed dome.) 4.1 Objective Tracking A user can rotate the camera lens up, down, left and right to view objects through the field of vision using the control keyboard.

  • Page 15: Pattern Tours Setting

    4.3.2 Pattern Tours Setting 4.3.2.1. The Speed dome camera has the capacity to set up to 8 pattern tours each of which can have up to 16 preset positions. 4.3.2.2. Add preset positions in the pattern tours. 4.3.2.3. Set dwell time (1-60 seconds) and the rotational speed (1-64 grades) of each present positions.

  • Page 16: Iris Control

    a. The object is not in the center of the picture; b. Attempting to view images that are far and near at the same time; c. Object is strongly lighted object, such as neon lamp, etc.; d. Objects behind glass covered with dust; e.

  • Page 17: V. Camera Menu (Osd Menu) Setting

    V. Camera Menu (OSD Menu) Setting 5.1 System Information 5.1.1 The speed dome will automatically start self-testing once power is on. The following default information of the speed dome will be displayed on the screen of the monitor. SYSTEM INFORMATION: 1.

  • Page 18: S Peed D Ome Osd S Etting With C Ontrol K Eyboard

    5.2 Speed Dome OSD Setting with Control Keyboard 5.2.1 Enter OSD Menu With Default Protocol 5.2.1.1 Select the speed dome address on the keyboard and then press “CAM” key. Press the “FUN” key once in the main menu of keyboard display（To press the ”EXIT”...
  • Page 19 OSD setting and their functions are listed below respectively: “UP” (the “SEQ” key)：To the previous menu. “DOWN” (the “MON” key)：To the next menu. “LEFT” (the “Area” key)：To reduce such number by “1” at each hit. “RIGHT” (the “CAM” key)：It is a triple-function key playing different roles in different occasions.
  • Page 20 After pressing IRIS CLOSE, The command to the dome that keyboard or DVR made was not to control the OSD menu, but the operation of the dome, Press IRIS CLOSE again, the command was retrieved to the operation of the OSD menu. 5.2.3 When the OSD menu display.
  • Page 21 Diagram 3 structure of OSD menu 5.2.4.2 The Main Menu 1. CAMERA SETUP >> (Sub-menu for camera function setting). 2. PRESET POINT >> (Sub-menu for preset point setting). 3. AUTO OPERATION >> (Sub-menu for automatic movements...
  • Page 22 setting). 4. X-Y INDICATOR >> (Sub-menu for indicator on horizontal and vertical position of the speed dome/ X-Y INDICATOR display). 5. DATE&TIME SETUP >> (Sub-menu for date and time setting). 6. PASSWORD SETUP >> (Sub-menu for password setting). 7. SYSTEM INFORMATION (Sub-menu for system information display).
  • Page 23 preset points or even establish a new preset point. 1. NUMBER： (USED) To select (input) a number for preset point (numbers from 1 to 128 available). It the number for the point used there will be display of “USED” and the speed dome will turn to the preset point automatically to ease your confirmation on position of the point.
  • Page 24 3． A—B SCAN >> (For two points scanning setting). 4． A—B SCAN TEST >> (For two points scanning testing). 5． START ROTATION >> (For the submenu of starting 360° rotation scanning). 6． GUARD POINT >> (For the submenu of auto-reposition setting). 7．...
  • Page 25 You can position the cursor in ahead of the serial number of the points to be reset and then start to amend the number. (just like using PC). If the numbers for points in a group are displayed as blank，it means that preset point not yet been set.
  • Page 26 1. ROTATION SPEED： Set the speed for 360°rotation scanning (number from 1 to 64 available). 2. START ROTATION 3. EXIT SUBMENU << 5.2.4.11 Menu On Auto-reposition Setting 1. RETURNING TIME： Set time for speed dome to return the guard point from any point. 2.
  • Page 27 1. YEAR For year setting and amendment. ：XX MONTH：XX For month setting and amendment. 3. DAY： For day setting and amendment. 4. SAVING…. Amendment won’t be saved until click this “SAVING” panel. 5. EXIT SUBMENU << 5.2.4.15 Menu On Time Setting (This function might be set into some special dome cameras).

  • Page 28: Vi. Camera Optional Functions

    VI. Camera Optional Functions 6.1 Alarm Linkage Function Speed dome camera supports a 4 alarm input. Every alarm input end matches a preset position No.: 29, 30, 31, 32. When speed dome camera detects an alarm input, the camera will automatically turn to the preset position that has been set.
  • Page 29 Chart 1 Camera Functions by Adjusting Preset Position Preset Position Code Function 180º reversal Viz. flip Return 0º Viz. home Start Point A to B scanning (low-speed) Start Point A to B scanning (mid-speed) Start Point A to B scanning (high-speed) Start No.1 cruise Into Camera OSD Menu Cursor (up)
  • Page 30 Chart 2 Camera Functions by Loading Preset Position Preset Position Code Function Set Point A Set Point B Set Auto-reposition Auto-reposition Open Auto-reposition Close Run Pattern Stop Pattern Set Left Limit Stop(Point A) Set Right Limit Stop(Point B) Enter Menu Mode If another control device is used to control the speed dome camera, Some of the special functions of Intelligent high speed dome can’t be realized because of protocol limitation.

  • Page 31: Viii. Address-Binary Code Chart

    VIII. Address-Binary Code Chart Binary Default PELCO-D PELCO-P SAMSUNG KALATEL System Code Protocol 00000000 00000001 00000010 00000011 00000100 00000101 00000110 00000111 00001000 00001001 00001010 00001011 00001100 00001101 00001110 00001111 00010000 00010001 00010010 00010011 00010100 00010101 00010110 00010111 00011000 00011001 00011010 00011011...
  • Page 32 Binary Default PELCO-D PELCO-P SAMSUNG KALATEL System Code Protocol 00011100 00011101 00011110 00011111 00100000 00100001 00100010 00100011 00100100 00100101 00100110 00100111 00101000 00101001 00101010 00101011 00101100 00101101 00101110 00101111 00110000 00110001 00110010 00110011 00110100 00110101 00110110 00110111 00111000 00111001...
  • Page 33 Binary Default PELCO-D PELCO-P SAMSUNG KALATEL System Code Protocol 00111010 00111011 00111100 00111101 00111110 00111111 01000000 01000001 01000010 01000011 01000100 01000101 01000110 01000111 01001000 01001001 01001010 01001011 01001100 01001101 01001110 01001111 01010000 01010001 01010010 01010011 01010100 01010101 01010110 01010111...
  • Page 34 Binary Default PELCO-D PELCO-P SAMSUNG KALATEL System Code Protocol 01011000 01011001 01011010 01011011 01011100 01011101 01011110 01011111 01100000 01100001 01100010 01100011 01100100 01100101 01100110 01100111 01101000 01101001 01101010 01101011 01101100 01101101 01101110 01101111 01110000 01110001 01110010 01110011 01110100 01110101...
  • Page 35 Binary Default PELCO-D PELCO-P SAMSUNG KALATEL System Code Protocol 01110110 01110111 01111000 01111001 01111010 01111011 01111100 01111101 01111110 01111111 10000000 10000001 10000010 10000011 10000100 10000101 10000110 10000111 10001000 10001001 10001010 10001011 10001100 10001101 10001110 10001111 10010000 10010001 10010010 10010011...
  • Page 36 Binary Default PELCO-D PELCO-P SAMSUNG KALATEL System Code Protocol 10010100 10010101 10010110 10010111 10011000 10011001 10011010 10011011 10011100 10011101 10011110 10011111 10100000 10100001 10100010 10100011 10100100 10100101 10100110 10100111 10101000 10101001 10101010 10101011 10101100 10101101 10101110 10101111 10110000 10110001...
  • Page 37 Binary Default PELCO-D PELCO-P SAMSUNG KALATEL System Code Protocol 10110010 10110011 10110100 10110101 10110110 10110111 10111000 10111001 10111010 10111011 10111100 10111101 10111110 10111111 11000000 11000001 11000010 11000011 11000100 11000101 11000110 11000111 11001000 11001001 11001010 11001011 11001100 11001101 11001110 11001111...
  • Page 38 Binary Default PELCO-D PELCO-P SAMSUNG KALATEL System Code Protocol 11010000 11010001 11010010 11010011 11010100 11010101 11010110 11010111 11011000 11011001 11011010 11011011 11011100 11011101 11011110 11011111 11100000 11100001 11100010 11100011 11100100 11100101 11100110 11100111 11101000 11101001 11101010 11101011 11101100 11101101...
  • Page 39 Binary Default PELCO-D PELCO-P SAMSUNG KALATEL System Code Protocol 11101110 11101111 11110000 11110001 11110010 11110011 11110100 11110101 11110110 11110111 11111000 11111001 11111010 11111011 11111100 11111101 11111110 11111111...

  • Page 40: Ix. Exception Handling

    IX. Exception Handling Issue Possible Reason Solution Power on, no Power line connected wrong Correct it movement, no image, Power damaged Replace indicator light does not Blowout Replace light Power line be connected bad Check it Power on, self check, The machine’s address code or Reset has image, can’t...
