Thank you for purchasing our products.
·
Please carefully read this User's Guide(in particular, precautions for safety) before using a product and follow instructions
to use a product exactly.
·
The products are subject to change without prior notice.
Lift Control Module
User Manual
Advertisement
Summary of Contents for EALINK NL01
- Page 1 Lift Control Module User Manual · Thank you for purchasing our products. · Please carefully read this User's Guide(in particular, precautions for safety) before using a product and follow instructions to use a product exactly. · The products are subject to change without prior notice.
- Page 2 Index 1. Warning ................................1 2.The outlook and ports of the product ......................1 3. Features ..........................错误！未定义书签。 4. Package content .............................2 5. System wiring ..............................2 6. Installation ...............................3 (1) Surface mounted ............................3 (2) Guide rail mounted ............................3 7. Specification ..............................4 Version：V1.0...
- Page 3 1. Warning (1). Please read the user manual carefully before installation. (2). Please do not modify or disassemble the product. (3). Please do not install the product near a heat or humid place. (4). It’s forbidden for any unprofessional people to change the coding switch or the connection wires. 2.
- Page 4 3. Features ◆ Maximum support 4 lift control modules to give lift control output signal for 64 floors building. ◆ Distribute and protect network signal. ◆ Module design, increase the system stability and easy for maintenance. ◆ Relay output, support all kinds of lift control system. ◆...
- Page 5 （2） Choose output port NC/NO according to actual needs, then connect it and port COM to the certain lift control system input port. REMARK: If the lift control module is installed at the end of the vertical bus, it needs to set the match switch. Operation way: set the SW1 to be ON.
-
Page 6: Specifications
(2) Guide rail mounted (a). Fix the guide rail on the wall with screws and expansion bolt as the below picture; (b). Pull down the cards, and install the lift control module onto the guide rail; (c). Push up the cards to lock the lift control module. 7.
