Summary of Contents for Flaircomm Technologies BTHF180
- Page 1 Flaircomm Technologies Inc. BTHF180 User Manual - 1 - Address: No.5 Bibo Road, Keyuan Building, 4F, Zhangjiang Hi-Tech Park, Shanghai 201203, P.R.China Telephone: 86-21-51088733 Fax:86-21-50276101 www.flaircomm.com...
- Page 2 Flaircomm Technologies Inc. Declaration: Without written permission from original manufacturer, reproduction, transfer, distribution or storage of part or all of the contents in this document in any form is prohibited. The company reserves rights to make any changes and improvements to the product described in this document without prior notice.
- Page 3 Flaircomm Technologies Inc. Certification and Safety Approvals This product has been tested and found to comply with Bluetooth BQB requirements, part 15 of FCC rules, R&TTE Directive（99/5/EC） or CE marked requirements. Users should not make changes or modify the device in any way. Changes or modifications without expressly approved by the party responsible for compliance could void the user’s authority to operate the device.
- Page 4 Flaircomm Technologies Inc. INTRODUCTION ..........................5 ........................5 LUETOOTH ECHNOLOGY ..........................5 EATURES ........................... 5 ACKAGE ONTENTS ............................6 VERVIEW ...................... 6 EFINITIONS OF NDICATORS USING YOUR HANDSFREE ......................8 ....................... 8 ATTERY HARGING AND SAGE ....................... 8 OUNTING THE ANDSFREE ........................
-
Page 5: Main Features
Better portability with internal rechargeable Lithium Polymer battery Easy-to-mount with angle-adjustable sun-visor clip, can adjust to appropriate angle 1.3 Package Contents Bluetooth Handsfree Speaker BTHF180 Angle-adjustable Sun-Visor Clip - 5 - Address: No.5 Bibo Road, Keyuan Building, 4F, Zhangjiang Hi-Tech Park, Shanghai 201203, P.R.China Telephone: 86-21-51088733 Fax:86-21-50276101 www.flaircomm.com... -
Page 6: I Con I Ndicators
Flaircomm Technologies Inc. Car Charger Set（or Traveling Charger，Optional） User Manual 1.4 Overview Figure 1 Overview “ ”: Switch the device on/off. “ ”: Answer/end a call, transfer a call between handsfree and phone, execute menu items, play/pause AV. “ ”: Volume up, scroll up menu items, last number redial. - Page 7 Flaircomm Technologies Inc. “ ”: AV connection indicator, displayed after establishing the connection of AV service. “ ”: Battery information indicator, with 5 grades , displayed according to battery capacity. - 7 - Address: No.5 Bibo Road, Keyuan Building, 4F, Zhangjiang Hi-Tech Park, Shanghai 201203, P.R.China Telephone: 86-21-51088733 Fax:86-21-50276101 www.flaircomm.com...
-
Page 8: Usage
Flaircomm Technologies Inc. Using Your Handsfree 2.1 Battery Charging and Usage This device contains a rechargeable Li-Polymer battery. First-time charging time is about 4 hours. Later-on recharging time is around 3 hours. Detailed charging procedures as follows: 1. Connect the charger cable to the device. -
Page 9: H Andsfree
Turn on the Device Press and hold button for few seconds until two power-up tones are heard and “BTHF180” appears on the screen, and then release the button. This indicates the handsfree is now turned on. Turn off the Device... - Page 10 Flaircomm Technologies Inc. A user friendly control menu is provided for assisting the user to use the product. Listed below are menu page contents and the usage of each menu item: Pairing, a series of pairing operations It has three submenu items: Start, Erase and Exit.
-
Page 11: Perations
Bluetooth equipment found by the phone at the end of the searching process. c) Select this Bluetooth equipment ‘BTHF180’ from the list and initiate pairing following handset’s on-screen prompts. Then enter passkey “0000”and confirm to pair the device with your handset. - Page 12 Flaircomm Technologies Inc. If the device and the handset have been paired, to connect them, you can either quick press handsfree’s button initiate a connection request or follow the handset’s user guide to find the handsfree and send a connection request from the handset.
- Page 13 Flaircomm Technologies Inc. Voice Dialing If the connected handset support voice dialing, you can press and hold button ━ for 3 seconds to activate voice dialing. Before using voice dialing, you must record voice tag in your handset. Please refer to your handset manual for detailed descriptions on how to set up voice dialing and recording voice tags.
- Page 14 3. After finding your handsfree device, right click “BTHF180”, and choose “Pair Device”. 4. Enter passkey ’0000’ and confirm to pair the Handsfree with your computer. 5. After paired, a red “√” will occur before device name “BTHF180”. Connection for supporting “Bluetooth AV Service” will then be established automatically.
- Page 15 8. For voice communications such as chatting over the Internet, you must disconnect “Bluetooth AV Service”, and connect “Bluetooth Headset Service”. First, right click “BTHF180”, and choose “Disconnect—>Bluetooth AV Service”. 9. Then, right click “BTHF180” and choose “Connect—>Bluetooth Headset Service”. Once you hear indicating tones from the handsfree, press button to make the connection.
-
Page 16: Phonebook Operations
Flaircomm Technologies Inc. 3. Phonebook Operations 3.1 Download/Synchronize Phonebook Initiate Phonebook Downloading from Handsfree: Enter the menu, choose ‘Phonebook’ and execute ‘Download’ submenu, the device starts to download phonebook records from the handset. Icon indicator will appear on the screen until the end of downloading process. The downloading process will replace the existing phonebook stored in the handsfree by the new one. - Page 17 Flaircomm Technologies Inc. the last handset). If the handsfree is in the connected mode, records associated with the connected handset will be displayed. Call History Records Enter the menu, choose ‘Call History’ and execute ‘View’ submenu, or press button for few times to display call history records.
-
Page 18: Upgrade Software
1. Download software upgrade tool ‘DFU Wizard’ from our website and install it in your PC. 2. Download the latest version of software for BTHF180 from our website or dealer. 3. Connect the handsfree with PC using the USB cable coming with the package. (In order to update the software successfully, it is better to unplug other Bluetooth equipment from the PC USB port at the same time.) -
Page 19: Important Messages And Frequently Asked Questions
AV connection with BTHF180 initiatively. Once the handset establish AV connection with BTHF180, the device will unable to operate the menu and phonebook. You must disconnect them, and initiate connection request from BTHF180. -
Page 20: Maintenance
Flaircomm Technologies Inc. Maintenance Bluetooth handsfree speaker BTHF180 is well-designed High end communications device. Careful maintenance and proper use will extend the product life and keep its performance. The maintenance procedures recommended below may be helpful to you： Always turn off power and keep your device in a safe place when it is not in use Keep the device dry, away from water, precipitation, humidity, moisture, and various liquids that may corrode electronic circuits.
