6 CH REMOTE CONTROL QUAD COPTER
INSTRUCTION MANUAL
Key features of quadcopter
Four-axis structure makes the quadcopter more exible and rapid when
ying.
Built-in 6 axis gyroscope for precise hovering in the sky.
Simple modular design makes changing parts easy.
With 360º 3D eversion and throwing ight function.
The materials and speci cacion metioned in this instruction manual or the parts inside this
package are for reference only.
AGES +14
Advertisement
Table of Contents
Summary of Contents for Hobbyland REH13128
- Page 1 AGES +14 6 CH REMOTE CONTROL QUAD COPTER INSTRUCTION MANUAL Key features of quadcopter Four-axis structure makes the quadcopter more exible and rapid when ying. Built-in 6 axis gyroscope for precise hovering in the sky. Simple modular design makes changing parts easy. With 360º...
- Page 2 PREFACE Dear Customers: Thank you for purchasing our ying model. Please read this instruction manual carefully in order to master the skill more quickly and operate this product more safely. In the mean time, please well keep the original of this instruction manual for future reference.
- Page 3 GET TO NOW YOUR TRANSMITTER Headless ON/OFF Mode Auto return Left sideward fly fine-tuning 3D Eversion Forward fine-tuning Accelerator Right sideward fly fine-tuning Backward fine-tuning Light Control Turn left fine-tuning Direction Control Speed Gear Turn right fine-tuning 4 X AAA(LR03) 1.5V Batteries Step2: Connect the battery Step1: Open the battery...
- Page 4 Charging time: about 40 minutes - Flying time: about 6-8 minutes!
- Page 5 1. Battery should be put in the dried or ventilated place with enviroment temperature about 18-25 ºC. 2. In order to enhance the using life of the battery, please avoid repeat charging or excessive discharging. 3.When the battery needs to be stored for a long time, please charge the battery rst. That is to say, charge the battery for about 50-60 % of the volume and then well store it.
- Page 6 ①.Press the power switch ②.Connect the battery to the .Press the power swith to ③ to turn on the transmitter. battery port of quadcopter. turn on the quadcopter. .When the quadcopter indicator quickly flashing to ④ slowly flashing,please push the throttle lever to the highest position,and then pull it back to the lowest position.Then the quadcopter indicator changed from slowly flashing to normal lights up.
- Page 7 Auto-return function： When you want the aircraft to auto-return, please drive your aircraft in front of you, and press down the right control lever at once, when aircraft flying back, please keep controlling the up and down stick. 3D EVERSION AND THROWING FLIGHT INSTRUCTIONS When you are familiar with the basic operation, you can do some awesome &...
- Page 8 PEÇAS E ESQUEMA Upper Frame Lower Frame Gear Cover Battery Battery Door Protector Body length:30cm Body width: 30cm Body high: 8.5cm Main motor code: Battery: 3.7V 380 mAh Li-poly 30 cm...
