Product Manual
GW1100 – Wireless Gateway
PRODUCT DESCRIPTION
The GW1100 Wireless Gateway is an
electronic communications device which
acts as the central processing "hub" of the
Audacy™ system. The GW1100 wirelessly
receives and prioritizes inputs from sensors,
switches, building automation systems
(BAS), and/or a dedicated internet interface
(e.g., website or app). It then
communicates wirelessly with each Smart
Connector to turn on, turn off, or dim light
fixtures, based on input from the systems
above. The GW1100 can also pass
information such as light fixture status,
sensor data, and energy usage to the
building automation system and/or internet
interface.
KEY FEATURES
24V AC or DC power input
FCC and IC approved
Flexible mounting options
RoHS compliant
ND 7944-2 02/2014
Users Manual – GW1100 Wireless Gateway
www.idealindustries.com
PRODUCT CONTENTS
The following items are included inside the
package:
Qty Description
1
GW1100 Wireless Gateway
2
Mounting Screws
Page 1
Advertisement
Summary of Contents for IDEAL GW1100
- Page 1 Product Manual GW1100 – Wireless Gateway PRODUCT DESCRIPTION The GW1100 Wireless Gateway is an electronic communications device which acts as the central processing “hub” of the Audacy™ system. The GW1100 wirelessly receives and prioritizes inputs from sensors, switches, building automation systems (BAS), and/or a dedicated internet interface (e.g., website or app).
- Page 2 IDEAL Model GW1100 Wireless Gateway Installation Instructions PHYSICAL MOUNTING 1. The GW1100 Wireless Gateway can be mounted on a wall or surface using the screws provided. Refer to Figure 1 for mounting hole dimensions. It is important to keep the external antennas oriented vertically, regardless of the orientation of the gateway enclosure.
- Page 3 Product Manual GW1100 – Wireless Gateway Figure 2: Horizontal Mount, Antennas Extended Figure 3: Vertical Mount, Antennas Extended ND 7944-2 02/2014 Users Manual – GW1100 Wireless Gateway Page 3 www.idealindustries.com...
- Page 4 Product Manual GW1100 – Wireless Gateway 24V Power Input Figure 4: Gateway Power Input Ethernet Input Figure 5: Gateway Ethernet Input ND 7944-2 02/2014 Users Manual – GW1100 Wireless Gateway Page 4 www.idealindustries.com...
- Page 5 Bone Dimensions 6.59” x 4.34” x 1.84” (167.4 x 110.2 x 46.7 mm) Weight 11.2 oz. Warranty 1 year SUPPORT Technical support for IDEAL INDUSTRIES products can be initiated through the following methods: Website: http://www.idealindustries.com/support/ Telephone: +1 800-435-0705 Email: contactus@idealindustries.com ND 7944-2 02/2014 Users Manual –...
- Page 6 This device is intended for commercial and industrial applications. Changes or modifications not expressly approved by IDEAL could void the user’s authority to operate the equipment. Use and maintain device only as specified in this manual.
- Page 7 IDEAL INDUSTRIES, INC. for its use, nor for any infringements of patents or other rights of third parties that may result from its use. IDEAL INDUSTRIES, INC. assumes no liability for misuse of this product. Specifications are subject to change without notice.
- Page 8 IDEAL. Subject to the limitations herein, IDEAL warrants that transmitters, when delivered by IDEAL or its authorized distributor, for one (1) year following the delivery date, will be free from defects in material and workmanship and will substantially conform to IDEAL publicly available specifications for such products in effect at the time of delivery.
