- Page 1 ASSEMBLY INSTRUCTIONS...
- Page 2 MIG models. You have chosen a high-quality product and we do hope you‘ll As you remove your chair from the box you enjoy your MAXNOMIC MIG chair ® may notice slight wrinkles or dents in the for many years to come! upholstery that have been caused by tight packing.
- Page 3 CONTENTS: 1x Headrest, 1x Star Base, 5x Wheels, 2x Joint Brackets, 2x Side Covers, 1x Tilt Mechanism, Set the armrests to their highest position to 1x Gas Spring, 1x Telescopic Cover (Gas Spring), remove all other parts from the box. 2x Plastic Levers, 1x Glove, 1x Grease, 1x Multitool, 2x Metal Screws Remove all parts from the box and use the foam packing...
- Page 4 Assemble both covers using the Use the provided multitool to remove the provided metal screws. screws from the backrest. IMPORTANT: Repeat this on the other side of the backrest. Use the side lever to adjust the joint bracket of the sitting element into a vertical position.
- Page 5 Tighten the screws in the backrest using the Tighten the prepared screws by hand. provided tool. Start with the screws at the top, then proceed Insert the screws and tighten the side covers carefully to tighten the screws below. with slight pressure using the provided multitool. DO NOT TIGHTEN TOO MUCH! Adjust the backrest to the rearmost The covers are only meant for the looks of your chair.
- Page 6 Turn the chair around. Use the foam packing Remove the pre-assembled screws using the material to protect your floor and the seat. provided multitool. Place the tilt mechanism on the threaded holes as shown Tighten the M8 screws diagonally. in the picture. The control knob for the tilt resistance points to the front of the sitting element.
- Page 7 Lubricate the opening for the gas spring with the Put the gas spring incl. telescopic cover in the provided grease. It facilitates the assembly and destined opening of the tilt mechanism. reduces possible moving noises later on. Push the plastic handles over the bars of the tilt Lubricate the bars for the plastic levers with the mechanism.
- Page 8 Lubricate the top part of the wheels with the provided Take the star base and wheels. grease. They will be easier to insert then. Turn the star base around and insert the Lubricate the opening of the star base with wheels one by one.
- Page 9 Sit down on the chair to connect the gas spring Place the headrest over the two designated holes ... with the star base..and push it down until it clicks into Well done! place at least once. We hope you‘ll enjoy your new MAXNOMIC seat! ®...
- Page 10 OPTIONAL – In case you’d like to extend the angle of the backrest: REMOVAL OF THE CHECK SCREW Remove the bracket side covers using the ... to extend the provided multitool. backrest tilt angle. Remove the check screw from the bracket as Without the check screw ...
- Page 11 INSTRUCTIONS FOR USE: Height Adjustment Tilt Mechanism Lock Tilt Mechanism Resistance CARE INSTRUCTIONS: HEADREST: UPPER MATERIAL / FAUX LEATHER: Use cleanser for synthetic leather (car Hand wash only accessories). Synthetic leather must not be treated with any cleanser for real leather: It leads to brittleness of the material due to the oils contained.
- Page 12 Design and technology are subject to change. NEVER All rights reserved. Copying of materials, even in part, require written permission! use the chair together with © Maxnomic GmbH another person Marco Wörenkämper at the same time! Wiesenstraße 13 B 34246 Vellmar Germany +49 (0) 561.708 66 22...
