DM434 IMPORTANT SAFETY INSTRUCTIONS The apparatus shall not be exposed to dripping or splashing and that no objects with liquids, such as vases, shall be placed on the apparatus. The MAINS plug is used as the disconnect device, the disconnect device shall remain readily operable.
The microphone input impedance is less than 2k ohms� in such venues as hotels, convention centers, theatres, The outputs of the DM434 are electronically balanced with restaurants and retail outlets. The DM434 offers three output impedance lower than 120 ohms� When driving...
DM434 5 7 6 FRONT PANEL DESCRIPTION 1. Mid Control 7. Mono Button The MID EQ is set at 800Hz with +/-15 dB of boost or When this button is pressed, the L&R zone outputs are cut available� Adjust this knob clockwise to add fullness summed to mono�...
These are unbalanced line-level stereo RCA inputs� There power cable in here and connect the other end of the cable are three in total on the DM434� These are most commonly to an appropriate AC mains power supply� used with music players such as CD players, MP3 players and notebook computers�...
DM434 SPECIFICATIONS INPUT Microphone Input Impedance 2kΩ Gain -∞ to +55 dB Frequency Response 40Hz to 20 kHz, ±0.5 dB -128 dBu CMRR 100 dB @ Max Gain Phantom Power +15V DC Input Connectors Balanced XLR Stereo BGM Input Input Impedance 40kΩ...
Page 9
INTRODUCCION Conectores Le damos la enhorabuena, por su compra de la mezcladora de 4 zonas DM434, que es ideal para ser Las mezcladoras de zona DM434 utilizan; conectores de utilizada en todo tipo de lugares; como hoteles, centros entrada balanceadas de micrófono XLR para “Paging”, de convenciones, teatros, restaurantes y puntos de entradas RCA estéreo desbalanceadas para entradas de...
Page 10
DM434 5 7 6 DESCRIPCION DEL PANEL FRONTAL 1. Control de Medio 7. Botón Mono El EQ de Medios está preestablecido a 800 Hz con +/-15 Cuando se presiona el botón MONO, las salidas de zona dB de aumento o recorte. Ajuste esta perilla de control en L &...
Page 11
Estas son entradas RCA estéreo de nivel de línea no VDC sin que importe la posición de los polos negativos o balanceadas� Hay tres en total en la DM434� Estas son los positivos� Activará la función de emergencia, que enviara más utilizadas con los reproductores de música, tales como...
Page 12
DM434 ESPECIFICACIONES ENTRADA Micrófono Impedancia de Entrada 2 Kohm Gain -∞ a 55 dB Respuesta de Frecuencia 40 Hz a 20 kHz, ± 0.5 dB -128 dBu CMRR 100 dB @ Máximo Aumento Phantom Power + 15V DC Conectores de Entrada...
DM434 DIMENSIONS DIMENSIONES 437 mm / 17.2” All measurements are shown in mm/inches� Todas las medidas están mostradas en mm/pulgadas� Appendix...
Page 14
ALTAVOZ ALTAVOZ ATTENUA TO ATENUADOR ATENUADOR AUDIO CASSETTE CD/LD/VCR PLAYER PAGING MIC CASSETTE DE AUDIO REPRODUCTO DE CD/LD/VCR MIC DE PAGING TO NEXT DM434 ALARM SYSTEM A SIGUIENTE DM434 SISTEMA DE ALARMA AM/FM TUNER SPEAKER SPEAKER ALTAVOZ ALTAVOZ OFFICE LEFT...
