USER MANUAL
1. Contents
1.1. Bluetooth keyboard 1pc
1.2. Instruction manual 1pc
1.3. USB Charging cable 1pc
2. Product Features
2.1. Use Broadcom 20730 main control chip, have Bluetooth 3.0 interface.
2.2. Industry leading bluetooth solutions, WIDCOMM BTW(Microsoft officially designated
software) bluetooth software
2.3. Built-in power management software, can be in Microsoft's Windows system automatically
usable capacity.
2.4. With folding design, keyboard can be carried easily
2.5. Mute design: effectively avoid disturbing other sleeping person (especially for one room with
several person)Architecture design ,provides comfortable handling feel
2.6. Support iPhone,Mac,Windwos and Android system etc, It's more convenient for you
2.7. Waterproof, anti-pollution, dustproof
3. Specifications
3.01. Executive standard: Bluetooth V3.0
3.02. Maximum operating distance: 10 meters
3.03. Modulation mode: 2.4G straight sequence fh(FHSS)
3.04. Transmit power: Class 2 levels
3.05. Working voltage: 3.7V
3.06. Working current: 1.5MA
3.07. Standby current: 1.0MA
3.08. Sleep current: 40uA
3.09. Charging current: 150mA
3.10. Standby time: 150 days
3.11. Theoretical use time: 30 days (average 2 hours everyday)
3.12. continuous uninterrupted use time:60 hours
3.13 theoretical charging time:1.5-2 hours
3.14. Lithium battery capacity:110mAh
3.15. The key dynamics:60+10g
3.16. Button life:5 million times
Advertisement
Table of Contents
Summary of Contents for Brand New Days 2930
- Page 1 USER MANUAL 1. Contents 1.1. Bluetooth keyboard 1pc 1.2. Instruction manual 1pc 1.3. USB Charging cable 1pc 2. Product Features 2.1. Use Broadcom 20730 main control chip, have Bluetooth 3.0 interface. 2.2. Industry leading bluetooth solutions, WIDCOMM BTW(Microsoft officially designated software) bluetooth software 2.3.
- Page 2 3.17.Operation temperature:0-55℃ 3.18.Storage temperature:-10-60 ℃ 4. Pairing Procedures 4.1. Attention: please confirm the tablet system before turning on the keyboard. 4.2. Keyboard pair with ios system tablets (1) As picture below, press the power button, keyboard blue LED indicator will flashing about 3 seconds then extinguished, indicate the keyboard is on, then press the pairing button about 5 seconds keyboard status LED indicator flashing, indicate the keyboard is pairing status...
- Page 3 （4）When keyboard pairing successfully, press FN+ ,keyboard can compatible with ios system 4.3. Keyboard pair with Android system tablets: (1) As picture below, press the power button, keyboard blue LED indicator will flashing about 3 seconds then extinguished ,indicate the keyboard is on, then press the pairing button about 5 seconds, keyboard status LED indicator flashing, indicate the keyboard is pairing status...
- Page 4 (4) When keyboard pairing successfully, press Fn+ , keyboard can compatible with Android system. 5. Charging When you use keyboard in process, the status tinkle which advise you the battery is shortage, you should charging . Charging procedure below: (1) Separate put the USB terminal cable plug into the PC and keyboard .As follow picture. (2) When you charging ,the charging LED indicator is red, when the light off, the battery is full enough.(theoretical charging time 1.5-2 hours) 6.
- Page 5 Press this button can realize the digital function of “2”, FN + this button to realize “virtual keyboard” function, shift + this button to realize”@” function. Press this button can realize the digital function of “3”, FN + this button to realize “language switch”...
- Page 6 (1) When you don’t want to use the keyboard and carry. Don’t forget turn off the power switch of keyboard in order to extend your battery life span. (3) If you want to store the keyboard long time. Don’t forget charging the keyboard around 1 hour till the battery half which can extend your battery life span.
