CL915.book Page 1 Friday, May 4, 2001 11:35 AM IMPORTANT SAFETY INSTRUCTIONS IMPORTANT SAFETY INSTRUCTIONS IMPORTANT SAFETY INSTRUCTIONS ❑ Read and understand all instructions. ❑ Follow all warnings and instructions marked on the phone. ❑ Use only the battery type recommended in this manual.
Page 5
CL915.book Page 2 Friday, May 4, 2001 11:35 AM ARNING Warning: To prevent fire or shock hazard, do not expose this product to rain or moisture. AUTION CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER OR BACK. NO USER-SERVICEABLE PARTS INSIDE.
CL915.book Page 3 Friday, May 4, 2001 11:35 AM IMPORTANT SAFETY INSTRUCTIONS ATTERIES ❑ Disconnect the telephone when replacing the battery pack. ❑ Use only 3.6V 600mAh Nickel Cadmium (Ni-Cd) cordless telephone replacement battery pack (one included with phone). ❑...
Page 7
CL915.book Page 4 Friday, May 4, 2001 11:35 AM FCC R EQUIREMENTS This product complies with Part 68 of FCC rules. The Federal Communi- cations Commission (FCC) has established these rules that permit this device to be directly connected to the telephone network. Standardized jacks are used for these connections.
CL915.book Page 5 Friday, May 4, 2001 11:35 AM IMPORTANT SAFETY INSTRUCTIONS ARRANTY If your telephone is defective in material or workmanship and you return it within one year from the date of purchase, we will repair it, or, at our option, we will replace it.
CL915.book Page 6 Friday, May 4, 2001 11:35 AM INSTALLATION In addition to your User’s Manual and Quick Start Card you should find the following items for installation: LASTNAME FIRST 408 - 555-1212 9:18 10/16 IN USE 1 2 DELETE...
OUNTING Your new CL915 telephone may be installed on the studs of a standard wall phone plate or on to two screws (not included) fastened into the wall. When installing screws into plasterboard walls, use wall anchors (not in- cluded) to insure that the screws remain secure.
Page 11
CL915.book Page 8 Friday, May 4, 2001 11:35 AM ATTERY NSTALLATION 1. Slide open the battery compartment door on the back of the handset. 2. Securely plug in the wire and then lay the battery pack into the battery compartment.
CL915.book Page 9 Friday, May 4, 2001 11:35 AM INSTALLATION EADSET The headset jack is located on the side of the handset and is a standard 2.5mm plug. Simply plug the headset into the jack and the headset will be active.
CL915.book Page 10 Friday, May 4, 2001 11:35 AM FEATURES AND CONTROLS New Call/ Voice Mail Indicator Light Antenna Note: Handset may be placed face up or face down on the base. Battery Cover Phone In Use Light IN USE...
Page 14
CL915.book Page 11 Friday, May 4, 2001 11:35 AM FEATURES AND CONTROLS OCATION OF ONTROLS AND EATURES ❑ Talk - The TALK key is used to access the telephone line. ❑ Delete/Mute - The DELETE key is used to erase digits on the display.
Page 15
CL915.book Page 12 Friday, May 4, 2001 11:35 AM ❑ Ringer Switch - The RINGER switch is used to turn the handset ringer ON and OFF. ❑ Headset Jack - The headset jack allows for the hands-free use of your phone. You can use any standard headset with an 2.5mm connector.
Page 16
CL915.book Page 13 Friday, May 4, 2001 11:35 AM FEATURES AND CONTROLS ROGRAMMABLE HONE EATURES You can change the settings on the handset in the Setup mode. To pro- gram the settings see Handset Settings on page 14. The settings that can be changed are: ❑...
Page 17
CL915.book Page 14 Friday, May 4, 2001 11:35 AM ’ ROGRAMMING THE HONE EATURES Press and hold the SETUP/HOLD key until the phone displays ENGLISH. At any time during programming you can quit and the settings that you have already selected will be saved. Quit programming by pressing and holding the SETUP/HOLD key or let the programming time out by not pressing any key for 20 seconds.
Page 18
CL915.book Page 15 Friday, May 4, 2001 11:35 AM FEATURES AND CONTROLS 1: H ABLE ANDSET ETTINGS DISPLAY SHOWS TO CHANGE SETTING SETTINGS SELECT ENGLISH LOCL AREA Use the key to go to the first local Local Area Push CODE...
Page 19
CL915.book Page 16 Friday, May 4, 2001 11:35 AM ROGRAMMING THE PEED IRECTORY Your new phone will store up to 20 Speed Dial numbers. Up to 10 can be programmed for 1-touch dialing. To program your Speed Dial selec- tions: 1.
Page 20
To accept the next location given press DIRECTORY, or enter a two digit number for a different location. If there is a name/number already stored in the location selected, the CL915 will ask you if you would like to erase the original memory location. Press the DIRECTORY key to accept or any other key to reject.
Page 21
CL915.book Page 18 Friday, May 4, 2001 11:35 AM ROGRAMMING OICE If you subscribe to Voice Mail from your local telephone company, this feature will access your Voice Mail messages by pressing one key. 1. With the handset not in use, dial your voice mail access number.
CHARGE light is on. OCATING A ANDSET Your CL915 has a PAGE button to help you locate the handset when it is not on its cradle. 1. Press the PAGE key on the base. If the handset is within range, it will beep for 20 seconds.
Page 23
15 continuous seconds, it will release the call. HANNEL HANGING If you are experiencing interference during a telephone call, press the CHANNEL key. The CL915 will scan up to 15 channels and select the clearest one to provide the best possible reception.
You can quickly redial the last number dialed. 1. Press the REDIAL/PAUSE key. The display will show CONNECTING. Once the CL915 has acquired a line, the display will show the channel that it is using (e.g. CHANNEL 15). The redial memory holds up to 32 digits, so you can redial long distance as well as local numbers.
To One-Touch Dial a Memory Number: 1. Press the DIRECTORY key. The phone displays DIRECTORY. 2. Press and hold the key for the desired memory location. The CL915 automatically dials the stored number. To recall and dial a Memory Number: 1.
Caller ID stored in memory. 4. Your CL915 will keep track of all calls received, even if they were not answered, depending on how you set up the handset (see Programming the Phone’s Features on page 14).
Page 27
CL915.book Page 24 Friday, May 4, 2001 11:35 AM ETURNING A CALL FROM THE ALLER RECORDS You can return calls by using the Caller ID recall feature. 1. Press CALLER ID. 2. Use the keys to scroll to the call record you wish to call back.
CL915.book Page 25 Friday, May 4, 2001 11:35 AM CALLER ID OPERATION ID R ELETING ALLER ECORDS Deleting Individual Records 1. Press CALLER ID, then repeatedly press REVIEW/VOLUME until the Caller ID record you want to delete appears. 2. Press DELETE. DELETE? appears.
CL915.book Page 26 Friday, May 4, 2001 11:35 AM ID D ALLER ISPLAYS 4: C ID D ABLE ALLER ISPLAYS ISPLAY ESCRIPTION Display shows name, telephone number, SMITH JOHN time, date and the number of the call in 888-555-1212 your call records. It will also indicate if it’s 12/08 11:46AM RPT 20 a new number or a repeat call.
Page 30
CL915.book Page 27 Friday, May 4, 2001 11:35 AM CALLER ID OPERATION 4: C ID D ABLE ALLER ISPLAYS ISPLAY ESCRIPTION Appears when you review a Caller ID record from someone who has called more than one time from the same number.
CL915.book Page 28 Friday, May 4, 2001 11:35 AM TROUBLESHOOTING ROBLEM UGGESTION No dial tone or Check that you have plugged the AC power adapter phone will not dial into a working outlet. Check all telephone cord connections or try another jack.
Page 32
CL915.book Page 29 Friday, May 4, 2001 11:35 AM TROUBLESHOOTING ROBLEM UGGESTION Static Interfer- Do not place the base near appliances or large ence metal objects. (crackling sound Keep the handset away from interference sources during call) such as computers, remote control toys, wireless...
CL915.book Page 30 Friday, May 4, 2001 11:35 AM CARE AND MAINTENANCE You new CL915 telephone is an example of superior design and craftsmanship. The following suggestions will help you care for your phone so you can enjoy it for years.
CL915.book Page 31 Friday, May 4, 2001 11:35 AM CARE AND MAINTENANCE EPLACING THE ATTERY If you follow the instructions in “Connecting and Charging the Battery Pack”, the battery pack should last approximately one year. If the battery does not hold a charge for more than 2 hours after an overnight charge, replace the battery with a new 3.6 volt, 600 milliampere battery with a...
