Summary of Contents for Fitbil B107
-
Page 1: Assembly Guide
B107 Rowing Machine B107 Rowing Machine Assembly Guide Technical support phone: +1-206-792-9928 email address: service@fitbill.net... - Page 2 “to those just beginning an exercise regime, it should be less about the look or features of their exerciser and more about their commitment to a personal fitness program through continually tracking their progress” Daniel Woods （Co-founder）...
- Page 3 ABOUT fitbil ESmartGym is a renowned leader of innovative mobile and cloud based technology. Their android and IOS applications are integrated in many recognized brand name products in the health and fitness industry throughout the world. Fitbill™ is the vision ESmartGym has conceived for an inspiring and rewarding way to bring personalized wellness solutions into the homes of health conscious Americans.
- Page 4 If you forget your password, you will need to create a new account log in ID and password. Once you have logged in create your profile by depressing “me” in the lower right hand of your screen and entering the personalized information that applies to you.
- Page 5 ASSEMBLY INSTRUCTIONS Preparation A.Unpack your new equipment. Save your box and packaging. B.Clear a space on your floor or counter that will allow you to easily complete the assembly process. C.Before you begin, layout all parts and hardware to make sure all components have been received as shown on parts list .
- Page 6 EXPLODED VIEW...
-
Page 7: Parts List
PARTS LIST Name & Specification Name & Specification Slide rail Square inner plug Sensor Seat cushion Philips screw Slide base Front foot cover Flat washer D6 Flat washer D8 Allen bolt M6×15 Nylon nut M8 Round magnet Left base Limit pulley Allen bolt M8x40 Allen bolt M8x100 Cylinder connecting seat... -
Page 8: Assembly Instructions
Assembly Instructions Step 1 Fasten seat cushion (24) onto the slide base (25) with Allen bolt (27) and flat washer (26). Step 2 Set the left base (7) and right base (34) into slide rail (1) respectively; fasten them with carriage bolt (39), arch washer (40) and nylon nut (6). - Page 9 Step 3 Fasten pedal (42) onto slide rail (1) with hex bolt (43) and flat washer (41). Step 4 Fasten the left swing arm (15) onto left base (7) with Allen bolt (21), flat washer (5) and nylon nut (6); fasten the right swing arm (36) onto right base (34) with Allen bolt (21), flat washer (5) and nylon nut (6).
- Page 10 Fasten the cylinder (12) on left side onto the left base (7) and aluminum clamp (16) with Allen bolt (8), flat washer (5) and nylon nut (6); fasten the cylinder (12) on right side onto the right base (34) and aluminum clamp (16) with Allen bolt (8), flat washer (5) and nylon nut (6).
