INSTALLATION INSTRUCTIONS
ROADTHUNDER SOUND BAR BY MTX, SATIN SILVER
THANK YOU FOR CHOOSING KURYAKYN!
Protect yourself and others from possible injury and property damage or loss. Pay close attention to all instructions, warnings, cautions, and notices regarding the installation, use, and care of this product.
THIS INDICATION ALERTS YOU TO THE FACT THAT IGNORING THE CONTENTS DESCRIBED HEREIN CAN RESULT IN POTENTIAL DEATH OR SERIOUS INJURY.
THIS INDICATION ALERTS YOU TO THE FACT THAT IGNORING THE CONTENTS DESCRIBED HEREIN CAN RESULT IN MINOR OR MODERATE POTENTIAL INJURY.
THIS INDICATION ALERTS YOU TO THE FACT THAT IGNORING THE CONTENTS DESCRIBED HEREIN MAY NEGATIVELY AFFECT PRODUCT PERFORMANCE AND FUNCTIONALITY OR
DAMAGE THE PRODUCT ITSELF OR THE PRODUCT TO WHICH IT IS BEING ATTACHED.
ENSURE THAT THE FOLLOWING PARTS HAVE BEEN INCLUDED IN THE KIT:
YOU WILL ALSO NEED:
Metric Hex, Allen wrenches, hand crimping tool(18-22 AWG), pliers
THESE INSTALLATION INSTRUCTIONS CONTAIN IMPORTANT INFORMATION. ENSURE THE END USER RECEIVES THIS COPY AND IS AWARE
OF ITS IMPORTANCE FOR FUTURE USE.
WHEN CONNECTING POWER AND GROUND WIRES ENSURE THAT THE RED POWER WIRE IS FUSED AT THE POINT WHERE IT IS
CONNECTED TO THE VEHICLE'S BATTERY. FAILURE TO DO SO CAN RESULT IN DAMAGE TO THE VEHICLE IF A SHORT CIRCUIT DEVELOPS
BETWEEN THE VEHICLE CONNECTION POINT AND THE PRODUCT.
PAGE 1
302714
DPF-MRK-003 REV A 6/20/16
1
RoadThunder® Sound Bar
2
Sound Bar Mounting Clamps
2
7/8" Clamps
2
1" Clamps
2
1-1/8" Clamps
2
1-1/4" Clamps
1
Transparent Film
1 Hardware Kit containing:
2
M6-1.0 X 35MM Button Head
Hex Screws
2
M6-1.0 Lock Nut w/Washers
2
M6-1.0 X 14MM Cap Screws
2
M6 Split Washers
2
M4-0.7 X 10MM Set Screws
1
2MM Allen Wrench
1
10 Amp Mini Fuse
1
Quick Connect Male
1
T-Tap Quick Connect Female
4
Cable Ties
K U R YA K Y N . C O M
866 277 9598 | INFO@KURYAKYN.COM
454 COUNTY ROAD VV SOMERSET, WI 54025
2714
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Kuryakyn Road Thunder
Summary of Contents for Kuryakyn Road Thunder
-
Page 1: Installation Instructions
ROADTHUNDER SOUND BAR BY MTX, SATIN SILVER 2714 THANK YOU FOR CHOOSING KURYAKYN! Protect yourself and others from possible injury and property damage or loss. Pay close attention to all instructions, warnings, cautions, and notices regarding the installation, use, and care of this product. - Page 2 INTRODUCTION Thank you for purchasing this Kuryakyn RoadThunder Sound Bar by MTX that is designed to work with most Bluetooth enabled devices including iPhone® and Android® smartphones and tablets. This easy to install and use, all in one unit is capable of transforming your Bluetooth enabled mobile device into the center of your vehicle’s audio system.
- Page 3 • Connect wires to power, ground, and ignition. ORIENTATION EXAMPLES K U R YA K Y N . C O M 866 277 9598 | INFO@KURYAKYN.COM PAGE 3 454 COUNTY ROAD VV SOMERSET, WI 54025 302714 DPF-MRK-003 REV A 6/20/16...
- Page 4 Auxiliary out is a variable output that allows connection to a secondary audio device, whether it is an external amplifier connected to speakers or subwoofer. K U R YA K Y N . C O M 866 277 9598 | INFO@KURYAKYN.COM PAGE 4 454 COUNTY ROAD VV SOMERSET, WI 54025...
-
Page 5: Controlling The Volume
©2015 KURYAKYN HOLDINGS, LLC ALL RIGHTS RESERVED KURYAKYN, KURYAKYN K logo and the marks appearing on this instruction sheet are registered and common law trademarks of Kuryakyn Holdings except noted third-party trademarks. A full listing of trademarks and trademark registrations owned by Kuryakyn Holdings can be found at www.kuryakyn.com/legal-notice.
