Summary of Contents for GCS CYSCAN
- Page 1 CyScan ™ Positioning System Installation and Maintenance Guide G U I D A N C E G U I D A N C E C O N T R O L C O N T R O L S Y S T E M S...
- Page 2 Various changes and additions Guidance Control Systems Limited 4 Dominus Way • Meridian Business Park Leicester • LE19 1RP • United Kingdom Tel: +44 (0)116 229 2600 Fax: +44 (0)116 229 2604 Email: cyscan@gcsltd.co.uk Website: http://www.gcsltd.co.uk Printed in the UK...
- Page 3 CyScan Installation ........4 Unpacking the CyScan System ..............4 Mounting the System Components ............6 When mounting two CyScan sensors on the same vessel ..6 Wiring the CyScan System ................. 8 Power Supply Unit (PSU) ..............8 The Data Converter ............... 10 Notebook computer ..............
- Page 4 Appendix 2 - CyScan Sensor Mounting Template ........33 Appendix 3 - CyScan PSU Mounting Template ......... 34 Appendix 4 - CyScan RS485 Data Converter Mounting Template ..... 35 Appendix 5 - Recommended Spares List ..........36 Appendix 6 - Using CyScan Admin Console ..........37 To start CyScan Admin Console .............
-
Page 5: Introduction
The coordinates of the targets are then declared to (or discovered by) the CyScan Console, and using this data the system is able to determine the exact position of the vessel relative to the mooring point. -
Page 6: Cyscan Installation
To unpack the CyScan system: 1 Position the CyScan flight case on a level surface, close to the area where the sensor will be installed. ! Warning: The CyScan Sensor and peripheral items weigh in excess of 30kg. Two people, should perform all lifting and carrying of the unit. - Page 7 9 From the access hole in the base of the flight case, remove the power supply and data converter boxes plus their accompanying cables. ï Remove the The system is now ready for peripheral items installation. CyScan Positioning System • Installation and Maintenance Guide r1.1...
-
Page 8: Mounting The System Components
When mounting two CyScan sensors on the same vessel In situations where two separate CyScan sensors are to be used on the same vessel, the following criteria should be met: •... - Page 9 PSU enclosure. To mount the CyScan Data Converter The CyScan Data Converter must be securely mounted in the vicinity of the CyScan notebook computer. 1 Prepare a suitable site for the Data Converter and pre-drill pilot holes for the mounting screws according to the template provided in Appendix 4.
-
Page 10: Wiring The Cyscan System
Wiring the CyScan System The CyScan system introduces four main items to the vessel, these are: • CyScan Sensor • Power Supply Unit • Data Converter • CyScan Console Notebook Computer The diagram below indicates the connections between the four items. - Page 11 Ensure that the crossover is correctly performed as the cable from the DP system is wired into the PSU. CyScan Positioning System • Installation and Maintenance Guide r1.1...
-
Page 12: The Data Converter
CyScan notebook (refer to mounting template in Appendix 4). The Data Converter requires a DC power supply between 7 and 35V – this can be derived either from the CyScan Power Supply Unit or from the vessel’s bridge, as required. -
Page 13: Connecting The Cyscan Sensor
To connect the CyScan Sensor: 1 Remove the protective dust caps from the Power, DP and Console sockets at the Stern end of the CyScan Sensor. Do not remove the protective cap from the fourth sensor connector. The cable connectors and corresponding sockets are similarly labelled. Also, the sockets and connectors are not interchangeable. -
Page 14: Cyscan Led Indicators
CyScan LED Indicators To provide instant status information, the CyScan sensor features three LED indicators mounted beneath the carrying handle at the Stern side. Each indicator displays the current status of three key elements of the sensor circuitry: Leveller diagnostic... -
Page 15: Cyscan Removal
OFF before the CyScan Sensor is disconnected. To exit CyScan Console and shutdown the system 1 Click the ‘CyScan’ button in the lower left corner of the screen (this button is unavailable while navigating). The control dialog will be displayed: 2 Click the down-arrow to reveal the three options. -
Page 16: Disconnecting The Cyscan Sensor
CyScan Sensor and also on the three cable connectors. Un-mounting the CyScan Sensor ! Warning: The CyScan Sensor weighs approximately 30kg. Two people, using the integral handles on either side, should perform all lifting and carrying of the unit. To un-mount the CyScan Sensor:... -
Page 17: Packing The Cyscan System
4 Place the lid of the inner box onto base and sides and insert the eight securing screws. Tighten the eight screws using a crosshead screwdriver. CyScan Positioning System • Installation and Maintenance Guide r1.1... - Page 18 8 Engage the four locking catches with the locking lips of the base and secure each of the locking catches by rotating the butterfly- wing tabs clockwise. The CyScan system is now ready for shipping. CyScan Positioning System • Installation and Maintenance Guide r1.1...
-
Page 19: Maintenance And Servicing
The CyScan sensor is constructed from distinct modules that can be removed and re- placed as required. This section covers the removal, replacement, upgrading and servicing of the CyScan sensor system. A list of recommended spare parts is listed in Appendix 5. Removing and fitting key components... -
Page 20: Stage 2 - The Rotor
6 Ensure that the rotor can rotate freely without touching any part of the sensor gearbox. CyScan Positioning System • Installation and Maintenance Guide r1.1... -
Page 21: Stage 3 - The Body Cover
When screws are secure, smear a thin layer of silicone grease around the screw heads and washers to maintain a watertight seal. CyScan Positioning System • Installation and Maintenance Guide r1.1... -
Page 22: Stage 4 - The Motor Gearbox
When screws are secure, smear a thin layer of silicone grease around the screw heads and washers to maintain a water- tight seal. CyScan Positioning System • Installation and Maintenance Guide r1.1... -
Page 23: Stage 5 - The Cpu Module
CPU board and into the correspond- ing threaded mounting posts on the controller board. Using a flat blade screwdriver, tighten all four screws to reasonable hand tightness. CyScan Positioning System • Installation and Maintenance Guide r1.1... -
Page 24: Stage 6 - The Controller Board
ð Gyro Case LED Rotor Indicators If the Motor Gearbox is in place, also attach the motor Pitch Roll Actuator Actuator power and data cables. CyScan Positioning System • Installation and Maintenance Guide r1.1... -
Page 25: Stage 7 - The Yaw Gyro
3 Insert two M3 x 16 screws through the upper and lower frame bars and into the corresponding threaded holes of the yaw gyro board. Using a 2.5mm A/F hex tool, tighten both screws to reasonable hand tightness. CyScan Positioning System • Installation and Maintenance Guide r1.1... -
Page 26: Stage 8 - The Vertical Reference Unit (Vru)
3 Locate the VRU ribbon cable leading from the controller board and attach it to the starboard side connector of the two. 4 Locate the ribbon cable leading from the yaw gyro board and attach it to the port side connector of the two. CyScan Positioning System • Installation and Maintenance Guide r1.1... -
Page 27: Stage 9 - The Actuators
5 To remove the actuator base, remove the four M5 x 20 bolts from the two pedestal bearings at either side of the actuator base. see next page for fitting instructions CyScan Positioning System • Installation and Maintenance Guide r1.1... - Page 28 7 Locate the appropriate ribbon cable leading from the controller board and attach it (in the correct orienta- tion) to the connector on the rear of the actuator circuit board. CyScan Positioning System • Installation and Maintenance Guide r1.1...
-
Page 29: Cleaning The Cyscan Sensor
Cleaning the CyScan Sensor To maintain the CyScan Sensor in good working order it is important that both its casing and optical elements are kept free of contamination. To clean the casing and bellows: Use a sponge or cloth with warm water to wipe any sea spray or other contamination from the metal casing or the flexible bellows. -
Page 30: For Further Assistance
Troubleshooting For further assistance If you experience problems when installing or using the CyScan system, please check through this Troubleshooting section for a possible solution. If your problem is not listed here and you cannot resolve the issue, then please contact the system fitter or equipment provider who are trained to assist with installation and operation problems. -
Page 31: Sensor Rotates Slowly
• Check that the external supply voltage, supplied via the Power cable, to the sensor has not dropped below 18V. • Using CyScan Admin Console, check the reading given for the 24V Main on the System Status page. Also check the other supply voltage. These should be within 10% of their nominal values. -
Page 32: Alarm Codes
In addition a special category of leveller alarms in the code range 6xxx can occur in any of the four classifications above. These will signify events that are purely associated with the sensor rotor and leveller hardware and can provide clues about possible hardware faults. CyScan Positioning System • Installation and Maintenance Guide r1.1... -
Page 33: Cyscan Fuse Information
The CyScan system contains two fuses, their locations are: • Inside the Power Supply Unit casing on the AC input • On the Controller Board within the CyScan sensor housing on the DC input Power Supply Unit Fuse Fuse specification:... -
Page 34: Appendix 1 - Cyscan Sensor Connector Pin-Outs
Appendices Appendix 1 - CyScan Sensor Connector Pin-outs The CyScan sensor has four connectors situated at the Stern end of its base plate. Three of the connectors are used during operation, the fourth is used (offline) when the leveller component requires a software upgrade. -
Page 35: Appendix 2 - Cyscan Sensor Mounting Template
Appendix 2 - CyScan Sensor Mounting Template CyScan Positioning System • Installation and Maintenance Guide r1.1... -
Page 36: Appendix 3 - Cyscan Psu Mounting Template
Appendix 3 - CyScan PSU Mounting Template CyScan Positioning System • Installation and Maintenance Guide r1.1... -
Page 37: Appendix 4 - Cyscan Rs485 Data Converter Mounting Template
Appendix 4 - CyScan RS485 Data Converter Mounting Template BOTTOM Remove the Converter lid to access the fixing holes. Mount the unit close to the CyScan Console laptop computer. CyScan Positioning System • Installation and Maintenance Guide r1.1... -
Page 38: Appendix 5 - Recommended Spares List
20-0032-0 Cylindrical Reflector 1.5m cylindrical reflector including shackle. 38-0001-1 CyScan Console Notebook User Console Notebook Computer. 33-0032-3 Programming Leads Dual programming lead set for programming of Sensor rotor and navigator. CyScan Positioning System • Installation and Maintenance Guide r1.1... -
Page 39: Appendix 6 - Using Cyscan Admin Console
CyScan sensor software upgrades. This appendix provides brief details about how to start and exit CyScan Admin Console. Note: It is not possible to run CyScan User Console and CyScan Admin Console at the same time. To start CyScan Admin Console 1 If it is running, exit from CyScan User Console on the notebook computer. -
Page 40: Cyscan Admin Console Quick Start
CyScan Admin Console Quick Start 1 Switch on the CyScan notebook and login as described on the previous page. 2 A System Status screen similar to that shown below will be displayed: ? – Click to invoke the help feature. The Tabs –... -
Page 41: Setting Up The User Console Vessel Orientation
Setting up the User Console Vessel Orientation 1 Select the Advanced tab. 2 Insert the relevant parameters in the Vessel Parameters and CyScan Position fields. 3 Click the Apply button. Vessel and CyScan Position Parameters CyScan Positioning System • Installation and Maintenance Guide r1.1... -
Page 42: Checking The Comms Port Settings
Checking the Comms Port Settings 1 Select the Comms tab. 2 The serial port Connection area shows the correct settings. Serial port Connection area CyScan Positioning System • Installation and Maintenance Guide r1.1... -
Page 43: Reinitialise The Communications Link
1 On the System Status page, observe the Console Status line at the foot of the screen. 2 The Comms link status can be checked and tested by toggling the Reset button in the lower right corner of the screen. Reset Console Status line CyScan Positioning System • Installation and Maintenance Guide r1.1... -
Page 44: Enable Sensor Components
1 In the System Status page, check in the Operations section that the Leveller and Scanner are not disabled. 2 Select Scanner Enabled and select a Leveller mode other than ‘Disabled’. 3 Click Apply. Operations section CyScan Positioning System • Installation and Maintenance Guide r1.1... -
Page 45: Check Scanner Enabled
Check Scanner Enabled 1 Select the Scanner tab. 2 Set the Scanner field to Enabled and click Apply. Scanner field CyScan Positioning System • Installation and Maintenance Guide r1.1... -
Page 46: Check System Supply Voltages
Check system supply voltages 1 In the System Status page, check in the Components section that the supply voltages are within 10% of their nominal values. Voltage readings within the Components section CyScan Positioning System • Installation and Maintenance Guide r1.1... -
Page 47: Mooring Point Reflectors - Installation And Definition
Mooring Point Reflectors - Installation and Definition Reflector types Two main types of reflectors are used with the CyScan system, flat and cylindrical. These are shown below: Flat reflectors Flat reflectors are generally attached using steel clips to rigid structures such as metal posts. -
Page 48: Reflector Installation
Reflector Installation Key to the operation of the CyScan system are correct installation of reflectors and accurate information about their positions on the Mooring Point/Vessel. Please follow the guidelines given below when installing target reflectors on the Mooring Point/Vessel. Once the reflectors are installed, their relative positions should ideally be measured (by theodolite using a fully qualified site surveyor) and declared to CyScan Console. -
Page 49: Defining Reflector Positions
• The direction in which each reflector faces must be declared to the CyScan Con- sole. All measurements are made using the direction of the reflector face relative to the direction of the A axis. -
Page 50: Reflector Positioning Examples
Reflector Positioning Examples These three pages provide examples of typical reflector layouts. Example 1 - Ship on Tanker’s Port side, CyScan on ship’s Starboard side Reflector Positions 1 A=0, B=0, orientation= 270 A=+52.52m, B=0, orientation= 270 A=+64.89m, B=0, orientation= 270... - Page 51 Example 2 - Ship on Tanker’s Starboard side, CyScan on ship’s Port side Reflector Positions 1 A=0, B=0, orientation=+90 A=+56.21m, B=0, orientation=+90 A=+42.51m, B=0, orientation=+90 * When auto-surveyed (Items shown in grey) Specifically, the auto-surveyed reflector positions would be: A=0, B=0, orientation=+270 A=13.7m, B=0, orientation=+270...
- Page 52 2 The reflector numbering should be chosen so that they form an anti-clockwise sequence when seen by CyScan. 3 If the reflector positions are in northings and eastings, CyScan gives the ship’s position in northings and eastings and gives the heading relative to true north.
