Related Manuals for DomoClip DOP142
Summary of Contents for DomoClip DOP142
- Page 1 User manual Heating cooking machine Reference: DOP142 Version: Language: English WWW.DOMOCLIP.COM...
- Page 2 User manual You have purchased a product DOMOCLIP brand and we thank you. We take great care in design, ergonomics and ease of use of our products. We hope that this product will give you complete satisfaction. General Instructions PLEASE, TAKE TIME TO READ WELL THE INSTRUCTIONS FOR USE...
- Page 3 User manual heated oven. 9. Do not use outdoors (Household use only). 10. Do not touch the cutting blades and do not insert any kind of object (knives, forks, spoons etc.) into the bowl while the product is operation. A spatula may be used only when the product is not in operation, avoiding the risk of serious injury.
- Page 4 User manual • If the socket or the cord is damaged • If case of disfunctionning • If the appliance is damaged in any manner • If it fell in the water • If you dropped it 20. Always disconnect the appliance from the supply if it is left unattended and before assembling, disassembling or cleaning 21.
- Page 5 In any case you should return the appliance to this electrician This instruction manual is available too on our website www.domoclip.com SPECIAL MEASURES Warning...
- Page 6 User manual SPECIFICATION Voltage: 220-240V ̴ 50/60Hz Power: motor: 500W Element chauffant: 1000W KB: 2 min (Continuously maximum operating time) DESCRIPTION A. Measuring cup B. Bowl lid C. Airproof ring 1 D. Blades E. Airproof ring 2 F. Spanner G. Stirring attachment H.
- Page 7 User manual PANEL DESCRIPTION USE OF THE APPLIANCE Before cooking: Caution: A logo hot surface is on the bowl to that the marked item can be hot and should not be touched without taking care! The bowl of the appliance has maximum capacity of 3 litters, using capacity of 2 litters Caution: Never exceed maximum capacity (2L) limit of the bowl...
- Page 8 User manual to ensure safe usage. How to install the blade: In order to clean the blades and the bowl, the blade can be removed easily from the bowl. Please follow the instructions below: => => => => 1. Put the airproof ring (E) on the blade. Push the blade through the opening in the bottom of the bowl, ensure blade lock buckle in correct position 2.
- Page 9 User manual How to install the lid: CAUTION: If the lid is not well installed, you will not be able to switch on the product 1 Always put the lid from the spout as showed on the drawing 1. Then press the bowl lid slightly to ensure the lid cover close.
- Page 10 User manual How to program your appliance with the control panel Switch on/ switch off Switch on/off your appliance with the button on the right part of the base (S) You have a display to program time, temperature and speed The Time.
- Page 11 User manual Pulse button: This buttons allows you to have speed 12 for 2 seconds, then speed 1 working with 1 second, then circulation for working in this two speed mode. Note 1: be careful with projections and ensure the cap is on the bowl when you use this function especially when the food is hot Note 2: you can use it if the temperature is less than 60°C Turbo button:...
- Page 12 User manual The blades protection Use this accessory when you want to cook food and/or use slow cooker function without cutting food. The blade protection will be added to the blade cover following the steps below: 1. Hold the ball-shaped end of the blade cover (fig.1). 2.
- Page 13 User manual The heating resistant spatula The spatula is an element you use to stir the food during cooking in inserting it by the whole on the lid. The protection on the handle will avoid to touch the blades. You can also use to remove the food from the bowl. The end of the spatula is made to be able to be inserted between blades and the bowl.
- Page 14 User manual How to use the butterfly Please follow the steps: 1. Install the blade and butterfly, put the food in to the bowl 2. Then cover the bowl lid. 3. Install the bowl on the main appliance. 4. Rotate the bowl lid knob until it is locked in position. And put the measuring cup on the bowl lid. 5.
- Page 15 User manual You can use the steamers in either of the following two combinations: Combination 2 floor steamer: Storage Lid (O) + Food Steamer tray (M) + Steamer (N) + Lid (L) Note: Use the soup storage lid (O) under the steamer tray in order to collect the excess water You can use this combination for cooking different foods, such as vegetables with fish and/or fish Combination 1 floor steamer: Storage Lid (O) + Steamer (N) + Lid (L) Note: Use the soup storage lid (O) under the steamer in order to collect the excess water...
- Page 16 User manual 8. Put the food on the steamer, and then cover the lid. 9. Plug in and start the appliance. 10. Choose your cooking mode (use only heating mode or heating+ mixing mode optional) to steam. The stainless steel basket (inside steamer) It is perfect to cook delicate food which cannot be cooked directly inside the bowl or cook accompaniment as rice, pasta, potatoes…...
- Page 17 User manual To remove the inside steamer Use the spatula to take out the inside steamer. WORKING MODE Mode 1-To mix food: Please follow the steps: 1. Install the blade, put the food in to the bowl 2. Then cover the bowl lid 3.
- Page 18 User manual Mode 2-To make dough The blade is perfectly suited for such as making biscuit paste, sponge cake dough etc. Please follow the steps: 1. Install the blade, put the food in to the bowl 2. Then cover the bowl lid (as explained on the step by step above) 3.
- Page 19 User manual 8. After you finish the operation, the light of LCD display is flashing until reset manually by press any button. 9. After use, turn the main appliance off. Unlock and remove the bowl from the base 10. Remove the bowl lid. 11.
- Page 20 User manual • If you want to heat the food for a few more minutes, set the speed back to “0”.then press Start/Stop button. The appliance continues working. • Don’t heating milk more than 500ml! • High temperature protection: when temperature in the cup is more than 60 ℃ ， speeds is limited in speeds 1-5.
-
Page 21: Cleaning And Storage
User manual CLEANING AND STORAGE 1. Before you clean the appliance, switch the appliance off and remove the plug from the socket. 2. While cleaning, don’t immerse the bowl in water. 3. After the bowl cool down, Unscrew the screw ring and remove the blade from the bowl. Clean the inside and outside of the bowl. - Page 22 Household users should contact either the retailer where they purchased this product or their local authority office, for details of where and how they can take this item for environmentally safe recycling DOMOCLIP BP 61071 67452 Mundolsheim •...
