Summary of Contents for AquaMetrix Aqua-Check
- Page 1 ™ Aqua-Check Water Analyzer Operator’s Manual 4-30 Royal Crest Crt., Markham, On, L3R 9W8 Phone # 905-946-1064 Fax # 905-946-8064 Toll Free # 1-800-742-1413 www.aquametrix.com...
- Page 2 Notice The information contained in this document may be revised without notice. AquaMetrix shall not be liable for errors contained herein or for incidental, or consequen- tial, damages in connection with the furnishing, performance, or use of this material. No part of this document may be reproduced or photocopied, or translated to another language, without the prior written consent of AquaMetrix.
-
Page 3: Limited Warranty
AquaMetrix at the expense of the purchaser. Parts, labor, and return shipment to the customer shall be at the expense of AquaMetrix. - Page 4 Table of Contents Chapter 1: Introduction Introduction.......................1 Power.........................1 Specifications....................2 Options ......................3 Safety Information....................4 Chapter 2: Description of Components Water Analyzer Meter ..................5 Water Analyzer Probe ..................6 Chapter 3: Operation Removing the pH Boot ..................7 Preparing the Dissolved Oxygen Sensor............7 Probe Connection .....................8 Connecting the Probe to the Meter............8 Disconnecting the Probe from the Meter..........8 Turning on the Water Analyzer ..............8...
- Page 5 Chapter 5: Troubleshooting Troubleshooting....................25 Index Index........................27...
-
Page 6: Introduction
Chapter 1 Introduction The Aqua-Check Water Analyzer is a compact, rechargeable, battery-operated, field instrument that simultaneously measures the dissolved oxygen level, pH, conductivity, and temperature of water and aqueous solutions. The operator can elect to display either uncompensated values or values that have been compensated for external effects. -
Page 7: Specifications
Battery • 6 V rechargeable sealed lead acid. Discharge Time • 8 hours (6 hours with RS-232 option) • Low battery indicator and automatic shutoff to prevent calibration and stored reading memory loss Aqua-Check Water Analyzer Operator’s Manual Rev. 2.1... -
Page 8: Options
Recharge Time • 5.5 hours Operation Temperature • Meter: 0°–40°C • Probe: 0°–50°C Storage Temperature • 5°–40°C Dimensions • Probe: 12" H x 1.5" D (30 cm x 3.8 cm) • Meter: 7.5" H x 4.25" W x 1.5" D (19.2 cm x 10.9 cm x 3.8 cm) Weight •... -
Page 9: Safety Information
Safety Symbols The following symbols are located on the instrument: See accompanying instruction for more information. Indicates a hot surface. Indicates hazardous voltages. Indicates earth (ground) terminal. Aqua-Check Water Analyzer Operator’s Manual Rev. 2.1... -
Page 10: Chapter 2: Description Of Components Water Analyzer Meter
Chapter 2 Description of Components Water Analyzer Meter LCD Display RS-232 Battery Input/Output Charger Input Probe Connection Figure 2.1. Water Analyzer Meter and [DOWN] scroll through the menus and set values. [UP] Battery Charger Input connects the meter to the battery charger. ENTER selects menu items and skips calibration steps. -
Page 11: Water Analyzer Probe
Make sure that the guard is in place pH electrode dry. prior to using the probe. Temperature Sensor is in a stainless steel housing. This sensor requires little maintenance and is not field replaceable. Aqua-Check Water Analyzer Operator’s Manual Rev. 2.1... -
Page 12: Preparing The Dissolved Oxygen Sensor
Chapter 3 Operation This chapter describes the basics of taking a measurement with the Water Ana- lyzer. Refer to Figures 2.1 and 2.2 in Chapter 2 when necessary. Removing the pH Boot Before a measurement can be made, the boot must be removed from the pH sensor. The boot is a small polyethylene capsule that covers the pH sensor. -
Page 13: Probe Connection
Mode menu. Press the and [DOWN] key until you reach the [UP] “Setup Instrument” prompt. Press the [ENTER] key to activate the Setup Instrument Mode. See “Setup Instrument Mode” in this chapter. Aqua-Check Water Analyzer Operator’s Manual Rev. 2.1... -
Page 14: Storing Readings
Storing Readings Pressing the [STORE] key while the Water Analyzer is displaying readings will result in the data being stored in the measurement log. The numbered location assigned to the logged reading will appear on the display, near the temperature readout, for about three seconds. -
Page 15: Oxygen Display
Water Analyzer and an older, less sophisticated oxygen meter is required. If “Automatic Ox Cal.” is selected, you will be asked to specify the atmospheric pressure when calibrating the dissolved oxygen sensor (see “Dissolved Oxygen Aqua-Check Water Analyzer Operator’s Manual Rev. 2.1... -
Page 16: Conductance Display
Sensor Calibration” in this chapter). The Water Analyzer will calculate the appro- priate value for the oxygen concentration based upon the water’s temperature and the specified pressure. Once the desired selection is displayed, press either the [ENTER] or the [STORE] key to record the choice and advance to the conductance prompt. -
Page 17: Pressure Compensation
Frequently, the factory calibration will suffice for the life of the sensor; this is especially true if you are working with only slightly conductive (less than 5 mS/cm) solutions. Aqua-Check Water Analyzer Operator’s Manual Rev. 2.1... -
Page 18: Temperature Sensor Calibration
Each of the four sensors in the probe (dissolved oxygen, pH, conductivity, and temperature) are calibrated separately. When calibrating, allow the probe to sit in the solution for 5 minutes and then allow up to 10 minutes for the ADC (Analog Digital Conversion ) readout to stabilize. - Page 19 (100% humidity or a given standard solution), press the [STORE] key to complete the dissolved oxygen sensor calibration. To skip this step, press the [ENTER] key and the previous calibration information will be used. Aqua-Check Water Analyzer Operator’s Manual Rev. 2.1...
-
Page 20: Ph Sensor Calibration
After the dissolved oxygen sensor calibration is complete, the Water Analyzer will resume displaying the four measured parameters: temperature, pH, conductivity, and oxygen. pH Sensor Calibration For maximum accuracy, the pH sensor is calibrated at three points: acid point, base point, and neutral point. 1. -
Page 21: Review Log
[DOWN] keys can be used to step through the list of numbered [UP] log entries. When all of the log entries of interest have been examined, press the [MODE] key to return to the Mode menu. Aqua-Check Water Analyzer Operator’s Manual Rev. 2.1... -
Page 22: Clear Log
Clear Log The Clear Log Mode allows the measurement log to be emptied. This clears the memory for the next set of readings to be stored. 1. To erase the measurement log, press the [MODE] key to access the Mode menu. 2. -
Page 23: Rs-232 Interface Procedure
10 seconds. If there are no stored readings, there will be a message. 8. When the stored readings have been displayed, type <Alt S> to close your saved file. Aqua-Check Water Analyzer Operator’s Manual Rev. 2.1... - Page 24 9. The Water Analyzer Communications Program may be exited by typing <Alt X>. Changing the COM port To change from the COM1 port to the COM2 port: 1. Type <Alt C>. The highlighted line at the bottom of the screen will prompt for the new entry.
- Page 25 Notes Aqua-Check Water Analyzer Operator’s Manual Rev. 2.1...
-
Page 26: Chapter 4 Maintenance
Chapter 4 Maintenance This chapter describes the maintenance of the Water Analyzer. General Sensor Maintenance The Water Analyzer normally requires only minimal maintenance, aside from periodic calibration. The frequency of required calibration will depend upon the accuracy of the readings desired, the frequency and manner in which the meter is used, and the storage condi- tions. -
Page 27: Dissolved Oxygen Sensor Maintenance
Note: The pH electrode must not be stored dry. If the electrode is allowed to dry, it will be rendered useless and the sensor will have to replaced or returned to the factory for repair. Aqua-Check Water Analyzer Operator’s Manual Rev. 2.1... -
Page 28: Conductivity Sensor Maintenance
Storing the pH electrode in deionized water (or any solution lacking sufficient KCl) will cause the electrode to drift and require increasingly frequent calibra- tion. O-ring Connector Retainer Ring Figure 4.3. pH Electrode With Boot Removed Conductivity Sensor Maintenance The conductivity sensor requires only minimal maintenance and is field replaceable. -
Page 29: Probe Storage
3. Store the pH sensor with the boot containing boot solution. 4. Disconnect and disassemble the dissolved oxygen sensor. Rinse all parts and blot dry. 5. Reconnect the dissolved oxygen sensor to the probe. Aqua-Check Water Analyzer Operator’s Manual Rev. 2.1... -
Page 30: Chapter 5 Troubleshooting
Chapter 5 Troubleshooting The Aqua-Check Water Analyzer is not designed for field repair. Some problems, however, may be remedied without the need for any physical disassembly. The more common of these and their remedies are listed below. If a problem still exists after reviewing the following chart or if a particular problem is not addressed, contact your dealer or the factory for assistance. - Page 31 Notes Aqua-Check Water Analyzer Operator’s Manual Rev. 2.1...
- Page 32 Index Atmospheric Pressure 14 Auto Logging 17 Automatic Oxygen Calibration 14 Barometric Pressure 14 Battery 1, 2 Battery Charger Input 5 Calibrate Oxygen Mode 13 Calibrate pH Mode 15 Calibrate Temp Mode 13 Calibration 12 Automatic Oxygen 14 Conductivity Sensor 15 Dissolved Oxygen Sensor 13 Manual Oxygen 14 Oxygen Value 10...
- Page 33 Oxygen Compensation 10 Oxygen Setup 9 Review Log 16 Setup Instrument 8, 9 ON/OFF 5 Operation 7 Operation Temperature 3 Operator Precautions 4 Options 3 Oxygen Calibration Value 10 Compensation 10 Display 10 Membrane 6 Sensor 6 Aqua-Check Water Analyzer Operator’s Manual...
- Page 34 Oxygen Compensation Mode 10 Oxygen Setup Mode 9 pH Boot Removing 7 pH Display 9 pH Electrode Maintenance 22 pH Sensor 6 pH Sensor Calibration 15 Power 1 Precautions 4 Pressure Atmospheric 14 Barometric 14 Pressure Compensation 12 Probe 6 Connecting 8 Disconnecting 8 Probe Connection 5...
- Page 35 Storage Temperature 3 STORE 5 Storing Readings 9 Temperature Operation 3 Storage 3 Temperature Display 9 Temperature Sensor 6 Time Discharge 3 Recharge 3 Timed Readings 17 Troubleshooting 25 Turning On 8 Units Changing 9 Weight 3 Aqua-Check Water Analyzer Operator’s Manual...
- Page 36 Notes Index...
- Page 37 4-30 Royal Crest Crt. Markham, On, L3R 9W8 Tel: (905) 946-1064 • FAX: (905) 946-8064...
