- Page 1 PR-450UDM Contactless IC Card Reader/Writer User’s Manual...
- Page 2 ® ® * Microsoft and Windows are trademarks or registered trademarks of Microsoft Corporation in the U.S.A. and other countries. * FeliCa is a registered trademark of Sony Corporation. FeliCa is a contactless IC card technology developed by Sony Corporation. ®...
- Page 3 Federal Communication Commission Interference Statement NOTICE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
- Page 4 Eesti: Käesolevaga kinnitab DENSO WAVE INCORPORATED seadme PR-450UDM vastavust direktiivi 1999/5/EÜ põhinõuetele ja nimetatud direktiivist tulenevatele teistele asjakohastele sätetele. Español: Por medio de la presente DENSO WAVE INCORPORATED declara que el PR-450UDM cumple con los requisitos esenciales y cualesquiera otras disposiciones aplicables o exigibles de la Directiva 1999/5/CE.
- Page 5 Português: DENSO WAVE INCORPORATED declara que este PR-450UDM está conforme com os requisitos essenciais e outras disposições da Directiva 1999/5/CE. Slovensko: DENSO WAVE INCORPORATED izjavlja, da je ta PR-450UDM v skladu z bistvenimi zahtevami in ostalimi relevantnimi določili direktive 1999/5/ES.
- Page 6 Svenska: Härmed intygar DENSO WAVE INCORPORATED att denna PR-450UDM står I överensstämmelse med de väsentliga egenskapskrav och övriga relevanta bestämmelser som framgår av direktiv 1999/5/EG. Íslenska: Hér með lýsir DENSO WAVE INCORPORATED yfir því að PR-450UDM er í samræmi við grunnkröfur og aðrar kröfur, sem gerðar eru í tilskipun 1999/5/EC.
- Page 7 Be sure to observe all these safety precautions. ■ Please READ through these instructions carefully. They will enable you to use the PR-450UDM correctly. ■ Always keep this manual handy for easy reference. Strict observance of these warming and caution indications is a MUST for preventing accidents which could result in bodily injury or substantial property damage.
-
Page 8: Power Supply
Do not use the PR-450UDM in places where any inflammable gases may be emitted. Doing so could cause fire. Do not use the PR-450UDM in places where it is subject to strong vibration or shock. Doing so could cause the device to break or burn. - Page 9 Implantable Medical Equipment: A patient with implantable medical equipment (cardiac pacemaker, etc.) is strongly advised to operate the PR-450UDM away from at least 12 cm from the said medical equipment. A survey conducted on the wireless card systems has reported the possibility of their affecting or giving unfavorable impact on implantable medical equipment.
- Page 10 This will introduce noise in the sound or display due to electromagnetic waves generated by the device. Make sure to hold the plug when connecting and disconnecting the cable. This may cause the PR-450UDM or the cable to break, or result in burn, fire or electrical shock.
- Page 11 Preface The PR-450UDM reader/writer, which is easy to plug in to your host computer with a USB cable, is an IC card reader/writer capable of reading contactless IC cards. This user’s manual sets forth the procedures for handling, setting and operating this product. You should study it carefully to make sure that you use this product both correctly and effectively before starting the operation.
- Page 12 ・Modify or change the reader/writer unit and reapply for a new model type. ● If it is judged by DENSO WAVE that malfunction of this product is caused by its having been dropped or subjected to shock or impact, repairs will be made at a reasonable charge even within...
- Page 13 Consult your system administrator. System Configuration The PR-450UDM is a contactless IC card reader/writer designed to operate on the host computer. Supported contactless IC cards include MIFARE, FeliCa and ISO/IEC 14443 Type A and Type B. You can use this device on the computer equipped with WindowsXP or Windows 2000.
- Page 14 Start your computer at the right of administrator before moving to the setup procedure. ➌ Prepare a driver. Using the PR-450UDM requires you to install the dedicated USB driver provided by DENSO WAVE. You need to downloaded this driver from our website at http://www.denso-wave.com before starting the setup procedure.
- Page 15 Do not place the PR-450UDM on a metal plate Do not place the PR-450UDM on a steel desk or computer with a metal housing. It will generate harmful interference due to the effects of metal, which may block wireless networking with IC cards.
- Page 16 Setting Up the PR-450UDM 1. Connecting to your computer Connect the PR-450UDM to the USB port on your computer or to the USB powered hub through the USB cable provided in the package. Important! Leave at least 10 msec intervals when connecting and disconnecting the USB cable.
- Page 17 2. Installing the driver Soon after the PR-450UDM is connected to the host computer, Found New Hardware Wizard starts. Install the driver in the following steps. Installing on WindowsXP ➊ ➋ ① ② ③ ④ Select ① Search for the new driver in these...
- Page 18 “Uninstalling the driver” in page 11. Notes on COM Port Number: 1. To access to the DENSO WAVE USB-SER Comm.Port from the application software, you need the COM port number identified by the device manager.
- Page 19 Check ① Specify a location (S) check box and select When “New hardware device driver found” the folder of the driver you have downloaded in “Before messages appear, click Next. ② Starting the PR-450UDM” in page 4. Then click Next.
- Page 20 “Uninstalling the driver” in page 11. Notes on COM Port Number: 1. To access to the DENSO WAVE USB-SER Comm.Port from the application software, you need the COM port number identified by the device manager.
- Page 21 Login your computer with the administrator’s right. In WindowsXP/2000, removing the driver requires the administrator’s right. ➋ Release the PR-450UDM from your computer. How to remove You can remove the driver with the dedicated uninstaller Pcd_SerRemover in the steps below.
- Page 22 Reboot the host computer. ➍ Connect the PR-450UDM to the computer. ➎ Install a new driver. When you connect the PR-450UDM to the host computer, the new hardware wizard will automatically run. Follow the wizard and install a new driver.
- Page 23 Notes to users Do not unplug the USB cable from the PR-450UDM while the application is still running. This may cause the host computer to become unstable or the data stored in the PR-450UDM will be lost or broken. Proper card position You MUST place the card sideways as shown in the figure below.
-
Page 24: Specifications
Specifications ● Standard Item Specification Operating environment Office environment MIFARE (Standard 1k, 4k) ISO/IEC 14443 Type A (Incl. MIFARE DESFire) Supported card type ISO/IEC 14443 Type B FeliCa Interface Complying with USB 1.1 (Power is supplied via USB interface) Supported OS WindowsXP, Windows2000 Power voltage &... - Page 25 Outer dimensions All the measurements given in the figures are provided as referential values. Unit: mm Main unit USB cable 1200...
-
Page 26: Troubleshooting
Problem • If any other USB cable than the one provided by DENSO WAVE is used, you need to change it to the cable attached to this product. Connect the attached cable directly to the USB port on your computer and check the operation after that. - Page 27 PR-450UDM” in page 5.) • If the PR-450UDM is placed near a metal object, such as on a steel desk or computer with a metal housing, move the device away from that metal object. (Refer to “Notes for placing the PR-450UDM”...
- Page 28 Contactless IC Card Reader/Writer PR-450UDM User’s Manual Second Edition, August 2007 DENSO WAVE INCORPORATED Toranomon 4-Chome MT Bld. II, 4-2-12 Toranomon, Minato-ku, Tokyo, 105-0001 http://www.denso-wave.com/...
