1. Introduction
The Ackermann TFT monitors are state of the art high-tech flat panel TFT monitors,
incorporating high quality TFT-LCD panels with maximum resolution of 1280x1024. It is
based on the newest technology with high brightness 4-lamp CCFL backlight units. The
monitors are made of steel and hardened glass providing excellent stability and strength.
The integrated hinge and high adjustment means you are able to manouvre the monitors
for optimal viewing angle and comfort.
Panel technology
•
PVA (Patterned Vertical Alignment)
Connections
•
S-VHS (Y/C)
•
RGB
DVI
•
Features
• State of the art high performance picture quality design
Full CRT multi-sync monitor compatibility
•
Multi-sync capability up to SXGA resolution, 75Hz max., compatible standard
•
DOS, VGA, SVGA, XGA and SXGA VESA timing
•
Expand DOS, VGA, SVGA and XGA to full screen display
•
24 bit (16.7 million) true color data processing and display driving
•
Single control operated & transparent On-Screen-Display (hereafter 'OSD')
•
User interface
•
Full control of all relevant display and interface parameters via OSD
•
Multi language support
•
VESA DDC1/2B compliant
•
Compatible with VESA DPMS power saving modes
•
+12VDC single power: 45watts AC/DC power adapter
recommended (Supplied)
•
Operating temperature: 0 to 50°C
