- Page 1 BUILT-IN OVENS USER MANUAL (Gas Oven Series) * PLEASE READ THIS MANUAL CAREFULLY BEFORE INSTALLATION AND OPERATION www.tehkhno-home.com...
-
Page 2: Instructions For Use
Instructions for use Befare using your new appliance, please read these. Instructions for Use carefully. WARNING! Please operate the appliance fallowing this manual. They contain important infarmation concerning your Personal safety as well as on use and care of the appliance. Security Measures Please follow the instruction and advice as following: 1. - Page 3 11. Flammable objects such as wall covering, curtains should keep distance from the oven. 12. Linen such as dish towel,dishcloth or the can shelf should be kept at a safe distance from the oven. 13. Wooden,plastic vessels or canned faod should keep distance from the oven. 14.
-
Page 4: Oven Structure
of the oven door, and the metal part of the control board. ii.The interna! surfaces may be still hot when you open the door. 31. You can fix the food support to get the food more smoothly, which can also prevent you touching the oven door or the hot interna! and get burnt. 32. -
Page 5: The Control Panel
Gas Controller 10. Enamal tray Smoke outlet 11. Turn Spit Roof liner 12. Deep enamel tray Lamp 13. Grid Circulate fan set 14. Door Side rack 15. Door hande Fire damper board Accesories: Thermostat Clamp torceps Switch The control panel Digital for series GOH****** Mechanichal for series GOM****** Note: The practica! function setti ng should re fer to the specific... - Page 6 Installation: The applience may only be connected by a qualified expert. Important: keep this book for your installer’s reference. ReS carefully and keep this manual for further use. The appliance should be installed and debugged by a qualified instalattion technician. The appliance should be earthed.
- Page 7 1. The appliance cannot be used far heating. lt's dangerous if the oven works over time in poorly ventilated rooms.Warning! Cut the power when connection. Accident of shock or death! 2. The appliance should be connected directly to the breaker via bendy non- metal cable.
-
Page 8: Gas Connection
The type of cabinet must be correct to make the oven work normally. ºThe board and adhesiva must bear 120 C. The oven can't contact to the other electrical components. Warning! Electrical Hazards! * The appliance must be ground connected. * The appliance cannot connect to power before permanent earth connection. - Page 9 3. Put the loop on the rubber tube, if use the rubber tube connection. Connect to the tube tie-in which in the back wall of the oven .lnsert the gas inlet into the pipe about 20mm and close with nut .The maximum length of the tube must be not exceed 1.5m and the loop must be in accord with the national safety requirement.
- Page 10 www.tehkhno-home.com...
- Page 11 1.-Time control (Note: Not for all items) (Sketch 1-8) Turn the knob one complete round clockwise, then turn the knob counter clockwise to the place you need, the time controller begin to work. When the pre-set time has elapsed, the bell rings and reminds you to close the oven. The enactment time can be decided by the different food and the quantity, the most can be done is 120 minutes.
- Page 12 Turn-spit (Rotisserie): 1 ---Put the enamel tray in the oven, and insert the stand of the turn- spit.(sketch 1-11) 2 ---Fork the meat or food on the middle of the spit, and then put one side onto the motor mouth, the other side fix in the ring of the stand center, twirl the handle or the spit so that they are separated and you can take out the handle(sketch 1-12).
- Page 13 www.tehkhno-home.com...
- Page 14 Baking and roasting setting: 1. Turn the temperatura nob to the appropriate temperatura you need. 2. Turn the functions nob to the right function. 3. Turn the timer nob to the appropriate cooking time you need. 4. lf it's digital timer, please set the time by the digital timer controller. 5.
- Page 15 www.tehkhno-home.com...
- Page 16 www.tehkhno-home.com...
- Page 17 www.tehkhno-home.com...
- Page 18 www.tehkhno-home.com...
- Page 19 www.tehkhno-home.com...
- Page 20 www.tehkhno-home.com...
- Page 21 www.tehkhno-home.com...
- Page 22 www.tehkhno-home.com...
