Summary of Contents for AsconPool MS3D-UD
- Page 1 MS3D-UD MULTI SOLAR CONTROLLER UP-DOWN...
- Page 2 INSTALLATION: INCLUDED Solar Controller Down pipe Sensor Up pipe Sensor Mounting kit and template...
- Page 3 INSTALLATION: REQUIRED 6mm Masonry drill bit P-2 Phillips head (required for raw plugs) screw Driver Drill with hammer action ½” or 12.5mm Drill bit Or cutting Tool (ms-Drill)
- Page 4 INSTALLATION: DO’S 1.5m 3.5m Unit must be 3.5m from pool zone Less than 1.5m from the pump Unit must be mounted using screws provided Unit must be installed in the upright position 1 metre from the ground...
- Page 5 INSTALLATION: DO NOT’S! Do not immerse. Do not place unit upside down. Do not place within direct splashing or spray from the pool.
- Page 6 INSTALLATION: UP PIPE SENSOR Using the 12.5mm drill bit, drill a hole into the up pipe. Put the grommet in first, then push in the up pipe sensor. Plug sensor cable into the unit using the red connectors.
- Page 7 INSTALLATION: DOWN PIPE SENSOR Using the 12.5mm drill bit, drill a hole into the down pipe. Put the grommet in first, then push in the down pipe sensor. Attach the cables to the unit using the red connectors.
- Page 8 INSTALLATION For a ‘stand alone’ system Plug controller piggy back into GPO if a stand alone system. Plug the solar pump into the base of solar controller...
- Page 9 INSTALLATION For an ‘integrated’ system Plug the chlorinator into the power point Plug the solar controller grey piggy back into the chlorinator. Plug the filter pump into the grey piggy back Plug the solar pump into the solar controller...
- Page 10 OPERATION: START UP When the unit is turned on, there will be a period of 2 mins while the MS3D-UD and the solar pump synchronise (indicated by flashing light). After 2 mins the unit will run for at least 6 mins to reset the down pipe sensor.
- Page 11 OPERATION: CLOCK SET UP The clock will need to be set after the unit is powered When the unit is turned on, the set time LED will be flashing. Set the time using for the hours and the for the minutes.
- Page 12 OPERATION: COMFORT TEMP ADJUSTMENT The comfort temperature is the temperature the user wants their pool to Press button Press button to to increase to decrease to maximum 40°C minimum 20°C by 1°C increments. by 1°C increments. When the comfort temperature is set, this temperature will be stored, even when the unit is turned off.
- Page 13 OPERATION: DIFFERENTIAL TEMP ADJUSTMENT The differential temperature is the difference in the temperature between the up pipe and the down pipe. Press the buttons at the same time. The unit will show the display. The current differential is displayed. To change the differential, press the button to increase, and the...
- Page 14 OPERATION: FINISH TIME ADJUSTMENT The time of the day that the unit will cease operation until 8am the next day. The default time is 4pm. (Unit operates in 24 hour time) Press the button and the button at the same time. The unit will display Use the button the adjust the...
- Page 15 OPERATION: DISPLAY MODE The display mode allows the user to check each mode setting without accessing or changing the current settings. To read up and down pipe temperatures, clock and comfort temperature settings, press The unit will cycle through the settings showing: For the up pipe temp.
- Page 16 OPERATION: WINTER MODE Winter mode allows the users solar system to function during cooler months. This extends the life of the solar heating system. At the end of the season press for winter mode. At the start of the season press for normal operation.
- Page 17 OPERATION: OVERRIDE What does override do? Override On To select a 1 hour override, Press at the same time. To select a 4 hour override on, press and hold the at the same time for 5 seconds. Press both buttons again to cancel the operation.
- Page 18 OPERATION: CALIBRATION To calibrate the unit…. Press to calibrate the pool sensor Display reads CAL then +00 . Press the to offset the temperature.
- Page 19 TROUBLE SHOOTING GUIDE...
- Page 20 For further information, please refer to the Installation Guide and Instruction Manual www.asconpool.com.au...
