- Page 1 OPERATION MANUAL Serial Number E6CCXLX GATOR ® Battery-powered Tool Read and understand all of the instructions and safety information in this manual before operating or servicing this tool. Register this product at www.greenlee.com 52080026 REV 2 © 2017 Greenlee Textron Inc.
- Page 2 E6CCXLX Battery-powered Tool Table of Contents Description Description ..............2 E6CCXLX Battery-powered, High-speed Tool is a hand- held, self-contained tools intended to crimp cable, Safety ................2 cut cable and threaded rod, and punch holes with the Purpose of this Manual ..........2 proper adapters.
-
Page 3: Important Safety Information
E6CCXLX Battery-powered Tool IMPORTANT SAFETY INFORMATION SAFETY Wear eye protection when operating ALERT or servicing this tool. SYMBOL Failure to wear eye protection could result in serious eye injury from flying debris or hydraulic oil. This symbol is used to call your attention to hazards or unsafe practices which could result in an injury or property damage. -
Page 4: Important Safety Information
E6CCXLX Battery-powered Tool IMPORTANT SAFETY INFORMATION Do not dispose of batteries in a fire. They will vent Do not allow anything to contact the battery fumes and may explode. terminals. Failure to observe this warning could result in severe • Do not immerse the batteries in liquid. Liquid may injury from harmful fumes or burns from flying debris. -
Page 5: Identification
E6CCXLX Battery-powered Tool Identification 1. LED Work Light (white) 2. Adapter Release Buttons 3. Head 4. Latch (for opening head) 5. Lanyard Ring 6. Housing 7. Retract Button 8. LED Indicator (red) 9. LCD Screen 10. Battery 11. Trigger Specifications Tool Length ....................15.3"... -
Page 6: Operation
E6CCXLX Battery-powered Tool Operation • Inspect tool and dies before use. Replace any • Do not use this tool for continuous use. After 30 to worn or damaged parts. A damaged or improp- 40 cycles, allow the tool to cool for 15 minutes. - Page 7 E6CCXLX Battery-powered Tool Operation—Crimping Setup Preparing the Cable 1. Open the tool head. Follow the lug manufacturer’s instructions for appropri- ate cable strip length. 2. Remove any accessories from the tool head. Crimping Direction 3. Select the appropriate set of dies. Use the...
- Page 8 E6CCXLX Battery-powered Tool Operation—Crimping (cont’d) Crimping Procedure completely. 6. To stop the ram from returning fully, activate the trigger for a brief moment. This activation will close the retraction valve and stop the retraction motion. Wear eye protection when operating 7.
-
Page 9: Cutting
E6CCXLX Battery-powered Tool Operation—Cutting Accessory Table Task Blade Electric shock hazard: Copper and aluminum UC26 26 mm (1.00") max. This tool is not insulated. When using Copper and aluminum this unit on or near energized electri- UC40 40 mm (1.56") max. -
Page 10: Punching
E6CCXLX Battery-powered Tool Operation—Punching Electric shock hazard: A component failure could throw broken parts. Do not use this tool as a punch driver on or near live circuits. This includes, • Do not allow anyone to stand in but is not limited to, the following front of the punch. - Page 11 E6CCXLX Battery-powered Tool Operation—Punching (cont’d) Setup and Punching Procedure 8. Thread the 3/4" draw stud or 3/4" adapter com- pletely into the punch driver. Refer to the illustra- 1. Open the tool head. tions on the following pages. 2. Remove any accessories from the tool head.
- Page 12 E6CCXLX Battery-powered Tool Operation—Punching (cont’d) UA12P Punch Driver 33967 3/4" Adapter 1/2" (12.7 mm) Round Punches Pilot Hole 03248 Spacer Metric: 22.5 mm (max.) 30043 Conduit Size: 1/2" (max.) 3/8" Draw Stud Actual Size: 0.885" (max.) Punch 7/8" (22.2 mm)
- Page 13 E6CCXLX Battery-powered Tool Operation—Punching (cont’d) UA12P Punch Driver 60114 1/4" Adapter 60115 1/4" Draw Stud Square and Rectangular Punches 03248 Spacer Metric: 12.7 mm square Inches: 1/2" square End with Long Threads Metric: 11.1 mm x 22.2 mm rectangular Punch Inches: 7/16"...
-
Page 14: Operation
E6CCXLX Battery-powered Tool UA12P Operation—Punching (cont’d) Punch Driver 60118 3/4" Draw Stud Square and Rectangular Punches Metric: 46.0 mm to 68.0 square Inches: 1.811" to 2.677" square End with Long Threads Punch Metric: 33.3 mm x 66.7 mm to 35.0 mm x 65.0 mm rectangular Inches: 1.312"... -
Page 15: Available Adapters
E6CCXLX Battery-powered Tool Available Adapters Greenlee Adapter Description Part No. UA22 50070622 Adapter for Greenlee 22-Series dies 50070339 Adapter for Kearney and T&B dies 50070355 Adapter for W-type dies, D3 UC26 50067141 Cutter blades for copper and aluminum 26 mm (1") max. -
Page 16: Die Selection
E6CCXLX Battery-powered Tool Die Selection Crimps made on copper cable with Greenlee KC22-type dies and the copper connectors listed here are cUL and UL classified. Crimps made on copper or aluminum cable with Greenlee KA22-type dies and the dual-rated aluminum connectors listed here are cUL and UL classified. -
Page 17: Lcd Screen
E6CCXLX Battery-powered Tool LCD Screen This tool has an LCD screen, which displays informa- If there is no error code, cycle through the various tion about the tool. Turn on the screen by inserting the displays using the left and right buttons on either side of battery and jogging the tool. -
Page 18: Maintenance
E6CCXLX Battery-powered Tool Maintenance Daily Before use: 1. Inspect the tool for wear or damage, such as cracks, Wear eye protection when operating gouges, or chips. or servicing this tool. 2. Inspect the tool for damage or leaks. Failure to wear eye protection could result in serious eye injury from flying 3. -
Page 19: Troubleshooting
E6CCXLX Battery-powered Tool Troubleshooting Before You Begin 2. Use a nonflammable contact cleaner or pencil 1. Make sure that the battery is charged. Recheck eraser to clean the electrical contacts on the battery the battery after several minutes to make sure the and tool. - Page 20 4455 Boeing Drive • Rockford, IL 61109-2988 • USA • 815-397-7070 USA Tel: 800-435-0786 Canada Tel: 800-435-0786 International Tel: +1-815-397-7070 An ISO 9001 Company • Fax: 800-451-2632 Fax: 800-524-2853 Fax: +1-815-397-9247 Greenlee Textron Inc. is a subsidiary of Textron Inc. www.greenlee.com...
