Sentryway CurveTrack System Installation Manual

Travelling video surveillance system camera carriage
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
SENTRY WAY
®
VIDEOSURVEILLANCE SYSTEMS
CurveTrack
®
System
Installation Guide
CT V2 001
SENTRYWAY
Install Guide P/N : 0309-0218-00
Les Carrés du Parc
10 rue des Rosiéristes
69410 Champagne au Mont d'Or

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CurveTrack and is the answer not in the manual?

Questions and answers

Summary of Contents for Sentryway CurveTrack

  • Page 1 SENTRY WAY ® VIDEOSURVEILLANCE SYSTEMS CurveTrack ® System Installation Guide CT V2 001 SENTRYWAY Install Guide P/N : 0309-0218-00 Les Carrés du Parc 10 rue des Rosiéristes 69410 Champagne au Mont d’Or...
  • Page 3 The CurveTrack® is a product of Sentryway, and is protected patents. STATEMENT OF CONFIDENTIALITY This document discloses information proprietary to Sentryway, and no intent to abandon such proprietary information or to grant any rights to the recipient, is to be inferred from any transfer of this document. All...
  • Page 4 NOTICE TO USERS SENTRYWAY reserves the right to modify the contents of this manual at any time. Sentryway shall not be held liable for errors contained herein or for inci- dental or consequential damages in connection with furnishing, performance, or the use of material in this manual.
  • Page 5 SENTRY WAY System Installation Guide ® CT V2 001 VIDEOSURVEILLANCE SYSTEMS Table of Contents 1. INTRODUCTION.......................7 1.1 Explanation of Symbols..........................8 1.2 Technical Specifications..........................9 1.2.1 Physical Dimensions of the camera carriage..................10 1.3 Units of measure............................10 1.4 General safety precautions.........................10 1.5 Responsibilities of the Installer.........................11 2.
  • Page 6 SENTRY WAY System Installation Guide ® CT V2 001 VIDEOSURVEILLANCE SYSTEMS 6.4 Connecting rail Sections to Threaded Rod Assemblies–Method 1............42 6.5 Connecting rail Sections to Threaded Rod Assemblies–Method 2............43 6.6 Alignment of System Run..........................43 6.7 Guy Wire Suspension..........................51 7. INSTALLATION OF COPPER CONDUCTORS............53 7.1 General...............................53 7.2 Soldering copper conductors ........................54 7.3 Inserting conductors into plastic track.....................58...

  • Page 7: Introduction

    User’s Manual available from Sentryway Quiet, long lasting, trouble – free operation of the CurveTrack® system is dependent upon proper installation of all components. It is imperative that installation technicians read and understand this manual thoroughly before beginning an installation.

  • Page 8: Explanation Of Symbols

    SENTRY WAY System Installation Guide ® CT V2 001 VIDEOSURVEILLANCE SYSTEMS 1.1 Explanation of symbols The Exclamation Mark is used as a general safety alert. Read and follow instructions carefully when this symbol appears. NOTE A Note is a specific fact or time– saving tip that, if not followed, could affect the performance of the associated procedure.

  • Page 9: Technical Specifications

    System Installation Guide ® CT V2 001 VIDEOSURVEILLANCE SYSTEMS 1.2 Technical specifications Supplier’s name and address : Sentryway - Les carrés du parc - 10 rue des Rosiéristes 69410 Champagne-au-Mont-d’Or FRANCE Model or Type : CurveTrack® Electrical rating : Input 1 Power Chassis 100-240VAC;...

  • Page 10: Physical Dimensions Of The Camera Carriage

    1.2.1 Physical dimensions of the camera carriage (see figure 1-1) 119 mm 575 mm 121 mm 194 mm 3.6 kg Figure 1-1. CurveTrack Camera Carriage ® 1.3 Units of measure Dimensions and distances presented in this manual are expressed in metric units of measure. 1.4 General Safety precautions If possible, avoid installing units in occupied buildings during regular business hours.
  • Page 11 Comply with all local codes regarding the use of ladders, lifts and scaffolding. 1.5 Responsabilities of the installer While installing the CurveTrack® system, it is important that the installer understands that he /she is installing a one-of-a-kind system. Installation must follow the guidelines and instructions presented in this manual in order for the system to operate reliably providing years of good service with low maintenance.

  • Page 12: Identification Of Major Components

    SENTRY WAY System Installation Guide ® CT V2 001 VIDEOSURVEILLANCE SYSTEMS 2. Identification of major components 2.1 System components (see figure 2-1) 00010 Figure 2-1. Major System Components Page 12 of 70...
  • Page 13 SENTRY WAY System Installation Guide ® CT V2 001 VIDEOSURVEILLANCE SYSTEMS 2.1.1 Carriage – The carriage is the wheeled assembly that travels the length of the system run. The carriage provides mounting for the PTZ camera, control circuitry and the driving mechanism. In manual mode, carriage movement and position are determined by the operator.

  • Page 14: Rail Components

    SENTRY WAY System Installation Guide ® CT V2 001 VIDEOSURVEILLANCE SYSTEMS 2.2 Rail components WEIGHT: 1041 g Weight specified is for each single 5 m section of copper conductor. Remember that two such conductors, mounted parallel to each other, as shown to the right, are pressed into the plastic track and run the entire length of the rail.
  • Page 15 SENTRY WAY System Installation Guide ® CT V2 001 VIDEOSURVEILLANCE SYSTEMS 2.5 m 165.5 mm 150 mm 255 mm 185 mm Page 15 of 70...
  • Page 16 SENTRY WAY System Installation Guide ® CT V2 001 VIDEOSURVEILLANCE SYSTEMS 1.35 m Page 16 of 70...

  • Page 17: Carriage Components

    Do not rest the carriage on the brushes, pan and tilt assembly, or slip ring. If the carriage must be rested on a hard surface, lay it GENTLY on its side. Alternatively, lean the carriage on end against the wall. Figure 2-6. CurveTrack® Camera Carriage Page 17 of 70...
  • Page 18 SENTRY WAY System Installation Guide ® CT V2 001 VIDEOSURVEILLANCE SYSTEMS 2.4 Power supply assembly (Power End) components (See figure 2-7) Page 18 of 70...

  • Page 19: Site Evaluation And Planning

    SENTRY WAY System Installation Guide ® CT V2 001 VIDEOSURVEILLANCE SYSTEMS 3. Site evaluation and planning 3.1 Overview A good installation is always preceded by good preliminary planning. A comprehensive site survey and a set of floor plans are valuable assets for system planning. It is essential to determine the location best suited for the system run(s), and to identify the type of ceiling or roof structure from which it will be suspended, prior to specifying the required mounting materials.
  • Page 20 SENTRY WAY System Installation Guide ® CT V2 001 VIDEOSURVEILLANCE SYSTEMS Figure 3-3 illustrates a typical type of C – Purlin roof support structure. Special clamps, which require no drilling, are available from STC. Figure 3-4 illustrates a typical reinforced concrete type of roof support structure.

  • Page 21: Setting Up A Schedule

    SENTRY WAY System Installation Guide ® CT V2 001 VIDEOSURVEILLANCE SYSTEMS Locate two rod drops to align with the first and last rail coupler mounting channel. Locate the remaining rod drops along the centerline and placed no more than 5 meters (the length of two rail sections) apart. Drill a mounting hole for each hanger.

  • Page 22: Material Inspection And Inventory

    3.4 Material inspection and inventory All CurveTrack® equipment and installation materials that are at the site of the installation must be inspected for damage. All Claims for losses, or damage to the system in transit, must be made with the carrier. Packing slip documentation should be checked carefully against material received to ensure that everything that is needed has arrived.

  • Page 23: Recommended Tool List

    SENTRY WAY System Installation Guide ® CT V2 001 VIDEOSURVEILLANCE SYSTEMS 3.6 Recommended tool list This list includes tools required to install the entire CurveTrack®™ system. Safety Equipment Fastening Tools Safety Glasses Straight Blade Screwdriver First Aid Kit Phillips Screwdriver...

  • Page 24: Support Structure Installation

    4.2 Fastening Support Hardware to Bar Joists - Perpendicular Figure 4-1 illustrates a typical installation of the CurveTrack® rail to bar joist ceiling construction using pre- cut lengths of M10 threaded rod. See paragraph 3.3, Planning Installation of the System Run, to determine hanging height, and paragraph 5.2, Cutting the Threaded Rod, before cutting the threaded rod.

  • Page 25: Fastening Support Hardware To Bar Joists—Parallel

    SENTRY WAY System Installation Guide ® CT V2 001 VIDEOSURVEILLANCE SYSTEMS 4.3 Fastening Support Hardware to Bar Joists - Parallel When the installation requires the system run to be parallel to the bar joists, metal channel is used as a spanner to bridge the bar joists at each mounting point of the system run as shown in Figure 4-2.

  • Page 26: Fastening Support Hardware To Steel Beams—Perpendicular

    SENTRY WAY System Installation Guide ® CT V2 001 VIDEOSURVEILLANCE SYSTEMS 4.4 Fastening Support Hardware to Steel Beams - Perpendicular Figure 4-3 illustrates the use of Beam Clamps for attaching threaded rod to steel beam ceiling construction. 4.4.1 Locate the approximate center line of the system run. Insert a locking strap (1, Fig. 4-3) into beam clamp (2, Fig.

  • Page 27: Fastening Support Hardware To Steel Beams—Parallel

    SENTRY WAY System Installation Guide ® CT V2 001 VIDEOSURVEILLANCE SYSTEMS 4.5 Fastening Support Hardware to Steel Beams - Parallel When the installation requires the system run to be parallel to the steel beams, channel is used as a spine to bridge the beams at the mounting point for each rail section as shown in Figure 4-4.

  • Page 28: Fastening Support Hardware To C–Purlin Beams—Perpendicular

    SENTRY WAY System Installation Guide ® CT V2 001 VIDEOSURVEILLANCE SYSTEMS 4.6 Fastening Support Hardware to C–Purlin Beams - Perpendicular Figure 4-5 illustrates the use of beam clamps for attaching threaded rod to C–Purlin beam construction. 4.6.1 Mark the centerline of the system run on beams. 4.6.2 Insert locking straps (1, Fig.
  • Page 29 SENTRY WAY System Installation Guide ® CT V2 001 VIDEOSURVEILLANCE SYSTEMS CAUTION It is important to remember that, when mounting the support structure to slanted ceilings, the ceiling pitch must be taken into account when measuring and cutting lengths of threaded rod. 4.6.5 Insert plastic bushings (9, Fig.

  • Page 30: Fastening Support Hardware To C–Purlin Beams—Parallel

    SENTRY WAY System Installation Guide ® CT V2 001 VIDEOSURVEILLANCE SYSTEMS 4.7 Fastening Support Hardware to C–Purlin Beams - Parallel When the installation requires the system run to be parallel to the C– Purlin beams, channel is used as a spine to bridge the beams at each mounting point of a rail section as shown in Figure 4-6.

  • Page 31: Fastening Support Hardware To Flush Concrete–Parallel And Perpendicular

    SENTRY WAY System Installation Guide ® CT V2 001 VIDEOSURVEILLANCE SYSTEMS 4.8 Fastening Support Hardware to Flush Concrete - Parallel and Perpendicular Installing support structure to concrete presents both special considerations and limitations as well as some advantages. An advantage of mounting in concrete is the unrestricted positioning of the locations for threaded rod drops that allow the support structure to be positioned at the optimum location (see Figure 4-7).
  • Page 32 SENTRY WAY System Installation Guide ® CT V2 001 VIDEOSURVEILLANCE SYSTEMS 4.8.5 Slide a M10 channel lock nut (6, Fig. 4-7) into the channel. 4.8.6 Establish the length for the threaded rod (7, Fig. 4-7) by measuring the distance from the concrete to the top of the rail section when the rail is at the desired height above the floor.

  • Page 33: Fastening Support Hardware To Reinforced Concrete Beams

    SENTRY WAY System Installation Guide ® CT V2 001 VIDEOSURVEILLANCE SYSTEMS 4.9 Fastening Support Hardware to Reinforced Concrete Beams Figure 4-8 illustrates the attachment of channel to one type of reinforced concrete. If the system run is parallel to beams (as shown), concrete anchors and lag bolts are used on each end of the channel spanning two beams. This type of installation uses threaded rod assemblies to hang the rail.

  • Page 34: Threaded Rod Installation

    SENTRY WAY System Installation Guide ® CT V2 001 VIDEOSURVEILLANCE SYSTEMS 5. Threaded rod installation 5.1 General Each rail section is suspended from the supporting structure using M10 threaded rod. Refer to Site Evaluation and Planning, paragraph 3, and, more specifically, Planning Installation of the System Run, paragraph 3.3, for suggestions on determining drop distance.
  • Page 35 SENTRY WAY System Installation Guide ® CT V2 001 VIDEOSURVEILLANCE SYSTEMS Cut two equal lengths of rod for the first two rail sections in the system run, and cut at least one more length for each remaining rail section. On C– Purlin and steel beam perpendicular installations that allow the beam clamps to be mounted in a vertical position, it is possible to run the threaded rod up and through the beam clamp, eliminating the swivel.

  • Page 36: Installing Threaded Rod In Channel For Parallel Runs

    SENTRY WAY System Installation Guide ® CT V2 001 VIDEOSURVEILLANCE SYSTEMS 5.3 Installing threaded rod in channel for parallel runs Figure 5-2 illustrates a typical threaded rod installation where there are no turnbuckles used. Without turnbuckles, all height adjustments must be made from above the pre- installed support channel. If the threaded rod exceeds 1.25 meters in length, it is difficult to see leveling devices placed on the track.
  • Page 37 SENTRY WAY System Installation Guide ® CT V2 001 VIDEOSURVEILLANCE SYSTEMS NOTE Leave fasteners at the top of the rods loose so that rods can be turned into Twirl nuts i f you intend to pre– install Twirl nuts into rail section mounting channels. The hardware on each threaded rod is to be tightened later as the corresponding rail sections are hung and properly aligned.
  • Page 38 SENTRY WAY System Installation Guide ® CT V2 001 VIDEOSURVEILLANCE SYSTEMS 5.4 Installing turnbuckles threaded rods Figure 5-3 illustrates the recommended hardware necessary for attaching turnbuckles between the threaded rod assemblies and the rail sections. Turnbuckles may be used on all installations to aid in rail alignment, but are recommended especially for threaded rod drops exceeding 1.25 meters.
  • Page 39 SENTRY WAY System Installation Guide ® CT V2 001 VIDEOSURVEILLANCE SYSTEMS Page 39 of 70...

  • Page 40: Rail Section Installation

    SENTRY WAY System Installation Guide ® CT V2 001 VIDEOSURVEILLANCE SYSTEMS 6. Rail section installation 6.1 Rail section inspection Each rail section is suspended from the supporting structure using M10 threaded rod. Refer to Site Evaluation and Planning, paragraph 3, and, more specifically, Planning Installation of the System Run, paragraph 3.3, for suggestions on determining drop distance.
  • Page 41 SENTRY WAY System Installation Guide ® CT V2 001 VIDEOSURVEILLANCE SYSTEMS CAUTION Raising and attaching rail sections require a minimum of two persons. At exceptionally high installations, or when there are large, immovable objects beneath the erection site, power lifts or scaffolding may be required. 6.3.1 Position two step ladders of sufficient height below the intended location of the first two rail sections.

  • Page 42: Connecting Rail Sections To Threaded Rod Assemblies–Method 1

    SENTRY WAY System Installation Guide ® CT V2 001 VIDEOSURVEILLANCE SYSTEMS CAUTION Raising and attaching rail sections require a minimum of two persons. At exceptionally high installations, or when there are large, immovable objects beneath the erection site, power lifts or scaffolding may be required. 6.3.3 Connect threaded rods to rail sections.

  • Page 43: Connecting Rail Sections To Threaded Rod Assemblies–Method 2

    SENTRY WAY System Installation Guide ® CT V2 001 VIDEOSURVEILLANCE SYSTEMS 6.5 Connecting Rail section to threaded rod assemblies - Method 2 NOTE Refer to NOTE in paragraph 6.4. If M10 channel lock nuts (12, Fig. 5-2) have been inserted, or will be inserted, into the rail section mounting channels, make sure that the threaded rod assemblies are fastened to the support structure loosely enough to allow the threaded rod to be screwed into the Twirl nuts.
  • Page 44 System Installation Guide ® CT V2 001 VIDEOSURVEILLANCE SYSTEMS ® Tutorial for the installation and the assembly of the CurveTrack rails Start by lining up two rail sections and one aluminum coupler on the floor to fix them as described below.
  • Page 45 SENTRY WAY System Installation Guide ® CT V2 001 VIDEOSURVEILLANCE SYSTEMS Check that the sections are perfectly aligned and then start to fix the nuts without tightening them. Pre-tighten the nuts and when you are sure that the plastic rails are perfectly aligned and pressed one against the other, firmly hold them with one hand.
  • Page 46 SENTRY WAY System Installation Guide ® CT V2 001 VIDEOSURVEILLANCE SYSTEMS Turn the rail over and fix the strut you have previously cut on the couplers. Then insert a nut in the strut on each coupler Fix the pre-assembled rails on the threaded rods that you have previously installed.
  • Page 47 SENTRY WAY System Installation Guide ® CT V2 001 VIDEOSURVEILLANCE SYSTEMS For the following sections: start again the same process with two sections and one coupler on the floor. Each section assembled two by two is installed one after the other. The installation to the ceiling of each assembled section is done in the same way as before: press the aluminum cap and insert first the top screws...
  • Page 48 SENTRY WAY System Installation Guide ® CT V2 001 VIDEOSURVEILLANCE SYSTEMS Once you have installed all the Before the installation of the sections, you can fix the end caps to copper pipes, you have to insert both extremities of the rail. shock absorbers at all plastic junctions and all copper junctions.
  • Page 49 SENTRY WAY System Installation Guide ® CT V2 001 VIDEOSURVEILLANCE SYSTEMS Adjustment: If you observe an important gap after the installation of the copper pipes you can fix adjustment screws on the junctions. These screws will adjust the plastic rails depending on the screwing depth. WARNING: never screw the adjustment screws to full capacity.
  • Page 50 SENTRY WAY System Installation Guide ® CT V2 001 VIDEOSURVEILLANCE SYSTEMS The sanding: To make sure that the plastic junctions are perfectly smooth you have to sand them with a 120 sandpaper. Repeat this process for all the junctions of the entire rail. First sand the flat part of the junctions with a sanding block.

  • Page 51: Guy Wire Suspension

    CT V2 001 VIDEOSURVEILLANCE SYSTEMS 6.7 Guy wire suspension Figure 6-2 shows the recommended method for stabilizing a CurveTrack®™ system run with a threaded rod drop of 1.5 meters or less. NOTE Guy wires must be used in both the center, and at each end, of the rail for systems up to 76 meters in length.
  • Page 52 SENTRY WAY System Installation Guide ® CT V2 001 VIDEOSURVEILLANCE SYSTEMS Page 52 of 70...

  • Page 53: Installation Of Copper Conductors

    SENTRY WAY System Installation Guide ® CT V2 001 VIDEOSURVEILLANCE SYSTEMS 7. Installation of copper conductors 7.1 General The copper conductors transmit video, power, and control signals between the carriage and the control equipment. Figures 7-1 through 7-3 illustrate the recommended method for assembling and installing the conductors.

  • Page 54: Soldering Copper Conductors

    SENTRY WAY System Installation Guide ® CT V2 001 VIDEOSURVEILLANCE SYSTEMS 7.2 Soldering copper conductors It is impossible to overstate the importance of proper copper conductor connector piece (coupler) installation. Each and every connector must be cleaned, fluxed, and soldered in a professional, workmanlike manner in order to ensure conductivity and mechanical functionality.
  • Page 55 SENTRY WAY System Installation Guide ® CT V2 001 VIDEOSURVEILLANCE SYSTEMS 7.2.1 Clean two connector pieces (Fig. 7-2) and two end plugs (Fig. 7-3), if necessary, with a nonabrasive cleaning pad, and coat lightly with flux. 7.2.2 Install conductor end plugs in one end of the first two copper conductors (Fig.7-3), and insert the connector pieces into the opposite end of the tubing as far as they will go.
  • Page 56 SENTRY WAY System Installation Guide ® CT V2 001 VIDEOSURVEILLANCE SYSTEMS Cover the extremity of the copper pipes with the stripper paste and put them closer to make sure that they are well aligned. Cover the extremity of the copper pipes with the stripper paste and put them closer to make sure that they are well aligned.
  • Page 57 SENTRY WAY System Installation Guide ® CT V2 001 VIDEOSURVEILLANCE SYSTEMS Start to heat the coppers with a welding torch. You need to press both pipes one against the other. Make sure that the pipes are perfectly aligned and straight without any space at the junction. You can stop heating as soon as you start to see the silver colour at the junction.

  • Page 58: Inserting Conductors Into Plastic Track

    SENTRY WAY System Installation Guide ® CT V2 001 VIDEOSURVEILLANCE SYSTEMS 7.3 Inserting Conductors into Plastic Track NOTE The copper conductors should be pressed into the plastic track sections only after the solder joints have been allowed to cool and the joints have been inspected and smoothed as necessary.

  • Page 59: Installation Of Bumpers Stop Brackets

    SENTRY WAY System Installation Guide ® CT V2 001 VIDEOSURVEILLANCE SYSTEMS 8. Installation of bumper stop brackets 8.1 General Bumper stop brackets are installed at each end of the system run. These brackets are fastened inside the first and last rail couplers. They serve two purposes. Their primary function is to provide a margin of safety in the event of a limit switch failure resulting in the carriage striking either end of the system run.

  • Page 60: Installation Of Rf Adapter And Terminator Boards

    SENTRY WAY System Installation Guide ® CT V2 001 VIDEOSURVEILLANCE SYSTEMS 9. Installation of RF adapter and terminator boards 9.1 RF Adapter PCB Installation (See Figure 9-1) 9.1.1 Align the top, unthreaded hole on each extension bar with the corresponding hole in the conductor end plug and install a screw with captive washer in each.

  • Page 61: Installation Of Limit Switch Actuators

    SENTRY WAY System Installation Guide ® CT V2 001 VIDEOSURVEILLANCE SYSTEMS 10. Installation of limit switch actuators 10.1 General Limit Switch Actuator Magnets are detected by the camera carriage as it travels back and forth on the plastic track inside the rail enclosure. The two actuators are to be inserted into holes drilled in the plastic track at opposite end of the system run––...

  • Page 62: System Cabling With Power End Cap Assembly

    SENTRY WAY System Installation Guide ® CT V2 001 VIDEOSURVEILLANCE SYSTEMS 11. System cabling with power end cap assembly NETWORK POWER 24VDC Page 62 of 70...

  • Page 63: Installing The Carriage

    SENTRY WAY System Installation Guide ® CT V2 001 VIDEOSURVEILLANCE SYSTEMS 12. Installing the carriage 12.1 Carriage inspection CAUTION To avoid damaging the carriage, lift the top foam insert straight upwards. 12.1.1 Separate the preformed foam packaging inserts and remove the carriage. CAUTION Any time you lift the carriage, it must be supported with both hands.

  • Page 64: Inspecting The System Run

    SENTRY WAY System Installation Guide ® CT V2 001 VIDEOSURVEILLANCE SYSTEMS 12.2.5 Remove the Nylock nuts securing the bumper stop bracket to the end rail coupler, and remove the bumper stop bracket, the extension bars, and the RF Adapter PCB from the rail as a single unit.

  • Page 65: System Initialization And Powering Up

    SENTRY WAY System Installation Guide ® CT V2 001 VIDEOSURVEILLANCE SYSTEMS 13. System initialization and powering up 13.1 Power up / Initialization CAUTION Before powering up the system, make certain that foam bumpers are installed on each end of the system run. Upon initialization, the carriage calibrates the camera and then travels down the rail toward the Terminator end of the system run.

  • Page 66: Windows

    SENTRY WAY System Installation Guide ® CT V2 001 VIDEOSURVEILLANCE SYSTEMS 14. Windows 14.1 General Description. (See Figure 15-1) The window material used on the VideoSentry system is a PET (Polyethylene terephthalate) film approximately 0.2032 mm thick. It is supplied to the job site on 304 mm wide, 30.5 meters long rolls. The window material has a mirror finish applied to one side.
  • Page 67 SENTRY WAY System Installation Guide ® CT V2 001 VIDEOSURVEILLANCE SYSTEMS 1200 mm 14.2.4 Gently bend the window material up and around and clip it to the rail sections using the clips installed in the window’s punched holes in the previous step. 14.2.5 Continue down the system run, installing window segments in the manner described.
  • Page 68 SENTRY WAY System Installation Guide ® CT V2 001 VIDEOSURVEILLANCE SYSTEMS 14.3 Window installation on curve sections of rail Installing window on curved sections of rail necessitates that the window material be cut into short, rectangular pieces approximately 180 mm wide. Each segment requires two holes to be punched on each outside edge to accommodate four clips per segment.

  • Page 69: Field Replaceable Parts List

    SENTRY WAY System Installation Guide ® CT V2 001 VIDEOSURVEILLANCE SYSTEMS 16. Field replaceable parts list Page 69 of 70...
  • Page 70 ® VIDEOSURVEILLANCE SYSTEMS YOUR TECHNICAL & SUPPORT INTERLOCUTORS Guillaume MERLE Manufacturing & Aftersales Manager email : guillaume.merle@sentryway.com Phone : +33 4 72 86 08 54 Phone : +33 6 69 29 60 72 YOUR ADMINISTRATIVE INTERLOCUTORS Clémence ROGER Sales Assistant email : clemence.roger@sentryway.com...
