- Page 2 User’s Manual Table Of Contents Page 2. Table of contents Page 3. Σημαντικές Οδηγίες Ασφαλείας Page 4. Important Safety Instructions Page 5. Introduction Page 6. BZ1 Front Panel Page 7. BZ1 Rear Panel Page 8. PU2 Pickup Page 9. Application Examples Page 10.
-
Page 3: Important Safety Instructions
User’s Manual Important Safety Instructions Caution 1. Read these instructions. 2. Keep these instructions. Caution 3. Heed all warnings. 4. Follow all instructions. This symbol, wherever it appears, alerts you 5. Do not use apparatus near water. to the presence of uninsulated dangerous 6. -
Page 4: Introduction
Introduction Dear customer, Thank you for choosing the EBS BZ1/PU2 Bouzouki amplification package. The products are manufactured in England to the highest standards using high quality materials. They have been designed and tested to be reliable, long lasting state of the art products with a sound for the Bouzouki that is second to none. -
Page 5: Bz1 Front Panel
1. Input Jack: Use a Mono Jack lead to plug in your EBS PU2 pickup. If using a wireless system, be sure to set its output level so that it is no higher than the PU2’s output level. Boosting the output level of your pickup will cause the BZ1 to overload! 2. -
Page 6: Bz1 Rear Panel
BZ1. Additionally when powering the BZ1 On or Off, always mute the appropriate channel on the PA console/mixing desk that the Lineout is connected to. Please ensure the BZ1 is switched off and unplugged from the mains electricity supply before being moved. BZ-1 Rear Panel Output Characteristics: Output:... - Page 7 Fully balanced output for connecting to a powered speaker or a power amplifier driving a passive speaker. This output serves as the main output since it includes all the BZ-1 sections including level changes made from the volume control. This output can be considered as the “Bouzouki Player’s Output”...
-
Page 8: Application Examples
Output Notes: 1: Use the mixers input level (fader) to control the bouzouki level going through the main speakers. 2: Use the BZ-1 volume to adjust the level of the Active Monitor active monitor Stage Monitor Lineout Powered Mixer Output... -
Page 9: Specifications
User’s Manual Specifications BZ-1 Bouzouki Preamplifier: Inputs: Input Impedance 308KΩ Effects Return Impedance 13KΩ Outputs: Output Impedance 600Ω Balanced Stage Line Output Impedance 600Ω Balanced FOH DI Line Output Impedance 600Ω Balanced Effects Send Impedance 600Ω Power Supply: Mains Voltage 230VAC / 50Hz –... -
Page 10: Warranty Registration
Alternatively register your warranty online at www.ebsaudio.gr Warranty 1. EBS Audio Solutions warrants that this product will be free from any defects in materials and / or workmanship for a period of 1 year from the purchase date providing you have completed the warranty registration card. - Page 11 ………………… …………………… ………………… …………………… ………. Pleas se cut out and m mail the warra nty Registratio on Form to: EBS A Audio Solutio Ερατ τοσθένους 25 5, Παγκράτι Αθήν να Τ.Κ 11635 Τηλ: 210 7569803 3 / 210 756980 Fax:...
