Atlas WDF Service And Installation Manual

Wdf and wdf-l series ice cream freezer
Hide thumbs

Advertisement

Quick Links

Download this manual
ICE CREAM FREEZER-WDF & WDF-L SERIES
Service and Installation Manual
Please read this manual completely before attempting to install or operate this equipment!
Notify carrier of damage! Inspect all components immediately. See page 1.
WDF
DROP-IN ICE CREAM FREEZER
REFRIGERATED, SELF CONTAINED
WDF-L
DROP-IN SLIM-LINE ICE CREM
FREEZER , REFRIGERATED, SELF
CONTAINED
Effective Date: 2017
IMPORTANT INFORMATION
READ BEFORE USE

Advertisement

loading
Need help?

Need help?

Do you have a question about the WDF and is the answer not in the manual?

Questions and answers

Summary of Contents for Atlas WDF

  • Page 1 ICE CREAM FREEZER-WDF & WDF-L SERIES Service and Installation Manual Please read this manual completely before attempting to install or operate this equipment! Notify carrier of damage! Inspect all components immediately. See page 1. WDF-L DROP-IN ICE CREAM FREEZER DROP-IN SLIM-LINE ICE CREM...
  • Page 2 6. SAVE ALL CRATING MATERIALS UNTIL INSPECTION HAS BEEN MADE OR WAIVED. SERIAL NUMBER LOCATION THE SERIAL AND MODEL # CAN BE FOUND ON THE CONDENSING UNIT ENCLOSURE - SEE OPERATORS SIDE CONTROL PANEL WHEN CALLING ATLAS FOR PARTS AND SERVICE ALWAYS HAVE THIS INFORMATION AVAILABLE. SERIAL #: _______________________________________________________ MODEL #:_______________________________________________________...
  • Page 3 Project: ___________ Item No.:  ___________ Quantity:  ___________ DROP-IN SERVING EQUIPMENT ICE CREAM FREEZER WDF-2 WDF-3 Refrigerated, Self-Contained WDF-2 SPECIFICATIONS STANDARD FEATURES TOP: Constructed of 18 gauge, type 304 stainless steel, die Fully insulated for maximum efficiency and energy stamped with a raised perimeter bead. There shall be a solid...
  • Page 4 WDF-2: 22-1/2” I.D. WDF-3: 36-1/4” I.D. 16-1/2” 13-1/2” 16” 24” 10-3/4” 21-1/2” 21-3/4” PLAN VIEW ELEVATION END VIEW SHIP WT. INTERIOR CU. FT. LBS. ELECTRICAL CUT-OUT MODEL “A” “B” (LBS.) DIMENSIONS CAPACITY CAPACITY CHARACTERISTICS REQUIRED 29-3/4” 6-7/8” 16-1/2” X 22-1/2” X 13-1/2”...
  • Page 5 ___________ Item No.:  ___________ Quantity:  ___________ SLIM-LINE DROP-IN SERVING EQUIPMENT SLIM-LINE ICE CREAM FREEZER WDF-L Refrigerated, Self-Contained WDF-L SPECIFICATIONS STANDARD FEATURES TOP: Constructed of 18 gauge, type 304 stainless steel, die Slim-line configuration - it can install in counters only stamped with a raised perimeter bead.
  • Page 6 REFRIGERATED ICE CREAM FREEZER COMPRESSORS FOR REMOTE INSTALLATIONS WITHOUT COMPRESSOR Units include Refrigerated Ice Cream Freezer, 2029 - 1/5 HP for WDF-LX Thermostat, Cap Tube & Drier (for hook up in field by others) Atlas Metal Industries 1135 NW 159th Dr. Miami, FL 33169 (800) 762-7565 Fax: (305) 623-0475 atlasfoodserv.com...
  • Page 7 ICE CREAM FREEZERS WDF & WDFL SERIES --------------------------------------------------------------------------------------------------------------------------------------------------------- INSTALLATION Provide the correct counter cut-out opening (see chart below) and drop in. The vinyl gasket assures complete seating. A non-toxic silicone seal may be used between the gasket and counter top (not required).

  • Page 8: Parts List

    2043-0 Thermostat 1099-0 Pilot Light 2029-0 1/5 H.P. Compressor WDFL 2029-1 1/4 H.P. Compressor WDF-2 & 3 4043-1 Handle Screws (Not Shown) 7003-0+Model # Throat Gasket (Not Shown) 2027-0 0.031 Cap Tube for 1/5 H.P. Comp. WDFL only (Not Shown) 2026-0 0.042 Cap Tube for 1/4, H.P.

  • Page 9: Trouble Shooting Guide

    Subsidiary of Mercury Aircraft, Inc. 1135 N.W. 159th DR., MIAMI, FL 33169 PHONE (305) 625-2451, (800) 762-7565, FAX (305) 623-0475, E-mail: sales@atlasfoodserv.com Refrigerated Drop-In Trouble Shooting Guide Symptom Probable Cause Unit not plugged in. No power at receptacle. Unit will not run Thermostat and or switch not in the on position.

  • Page 11: Limited Warranty

    (18) months after date of shipment from factory. During this period of time Atlas Metal Industries, Inc. will replace all defective parts and will pay for authorized replacement labor. Replacement and installation of such parts and labor shall be provided only upon prior written authority of Atlas Metal Industries, Inc.

  • Page 12: Warranty Information

    An authorization number must be obtained from the factory prior to performing any warranty service. _______________________________________________ Atlas Metal will not approve excessive labor due to poor access to the unit being serviced. If design does not allow reasonable access, contact the factory. _______________________________________________ All travel time that exceeds 100 miles round trip must be authorized by the factory.
