Summary of Contents for V-TEK DT607C-S1
- Page 1 DT607C-V1 / 201608 2-WIRE SERIES MODEL DT607C USER MANUAL DT607C-S1 DT607C-S2 DT607C-S3 DT607C-S4 • Please read this manual carefully to ensure safe and correct operation • Keep this manual for future reference...
- Page 3 CONTENTS PARTS AND FUNCTIONS Parts Names Mounting External Motion Detection SETUP INSTRUCTIONS Functions Setting Up Setting Door Station Address Setting Door Station Calling Mode Setting Unlock Mode Setting Unlock Time Setting Nameplate Illumination Mode Setting Night View LED Illumination Mode Setting Ring Tone WIRING Connecting Electric Lock...
-
Page 4: Parts Names
PARTS AND FUNCTIONS Parts Names [11] [10] [12] [13] [1] Microphone [6] Front panel [10] Rain cover [2] UNLOCK indicator [7] Speaker [11] Mounting hook [3] CALL indicator [8] Night view LED [12] Connection port [4] Call button [9] Camera lens [13] Screw hole [5] Nameplate Mounting... -
Page 5: External Motion Detection
PARTS AND FUNCTIONS Terminals description Lock Control Jumper PIR Motion Detector Connect ion Port P L S + L 1 L 2 Main Connect ion Port Lock Control Jumper: To set lock type Motion Detector Connection Port: To connect external PIR motion detector Main Connection Port: To connect the bus line and the electric lock... -
Page 6: Setup Instructions
SETUP INSTRUCTIONS Functions Setting Up This section explains the settings of each function. Please refer to the following table. To perform the settings for the function LED_UNLOCK you want, you should remove door station LED_TALK cover plate KEY_SET KEY_4 Each operation is indicated by the lighting LED_NAME KEY_3 up of the LED indicator on the unit and by... -
Page 7: Setting Door Station Address
SETUP INSTRUCTIONS Setting Door Station Address Total 4 addresses can be configured. It can be modified either before or after installation. 0 is default, to change the setting, please follow the steps: ID=0,1 door station ID=1,2 door station ID=2,3 door station ID=3,4 door station In standby mode, press... - Page 8 SETUP INSTRUCTIONS Each call button will respond different addresses when set in different calling modes Refer to the following for more information 1.Standard Calling Mode (Address range 01-04 default) Call buttonA: call the monitor with address 01 by default Call buttonB: call the monitor with address 02 by default Call buttonC: call the monitor with address 03 by default Call buttonD: call the monitor with address 04 by default 2.Group Calling Mode...
-
Page 9: Setting Unlock Mode
SETUP INSTRUCTIONS Setting Unlock Mode There are 2 unlock modes, Normally opened and Normally closed Normally opened is default. To change it, please follow the steps: In standby mode, press Press KEY_1 button to set Press KEY_1 button again KEY_SET button three the unlock mode to to set the unlock mode to times... -
Page 10: Setting Nameplate Illumination Mode
SETUP INSTRUCTIONS Setting Nameplate Illumination Mode There are 3 illumination modes for nameplate: Normally On,Normally Off and Auto Normally On is default. To change the setting, please follow the steps: Press KEY_3 button to set Press KEY_3 button again Press KEY_3 button again and In standby mode, press KEY_SET button three the nameplate illumination... - Page 11 SETUP INSTRUCTIONS Setting Door Station Ringtone There are 3 ringtone options available to choose from: Ringing ones, Ringing continuously and No ringtone Ringing ones is default. To change the setting, please follow the steps: In standby mode, press Press KEY_1 button to set Press KEY_1 button again Press KEY_1 button again KEY_SET button four...
-
Page 12: Wiring
WIRING Connecting Electric Lock Door Lock Controlled with Internal Power 1 2 3 1.Electronic lock of Power-on-to-unlock type should be used Jumper position on 2&3 2.The door lock is limited to 12V, and holding current must be less than PL S+ S- 250mA 3.The jumper should be placed on position 2 and 3 before connecting the lock... -
Page 13: Connecting Multiple Door Stations
WIRING Connecting 1- Monitor and 1-Door Station System ID=0 Code=1, DIP6=on 100~240VAC PC6A BUS(IM) BUS(DS) L1 L2 PL S+ S- DIP Switches 1 2 3 4 5 6 • The door station work in Standard mode in this situation. Refer to Page 8 for details Connecting Multiple Door Stations door station door station... -
Page 14: Connecting Multiple Monitors
WIRING Connecting Multiple Monitors Daisy Chain In-Out Wiring Door Station in Standard Mode • Recommended for up to 4-Monitors system • All monitors in the system should have Code=1, DIP6=on same User code 1 (Slave 3) • Program first monitor as ‘Master’ and others as ‘Slave’... - Page 15 WIRING Star Wiring Door Station in Group Calling Mode Code= 0 ，DIP6=on Code= 1 ，DIP6=on Impedance OFF ON switch Code= 2 ，DIP6=on Code= 3 ，DIP6=on 100~240VAC PC6A DBC4A1 BUS(IM) BUS(DS) Optional Interfaces BDU signal amplifier module RLC staircase light controller module DBC4A1 2/4 inputs branch distributor ID=0 •...
-
Page 16: Appendix
APPENDIX Precautions • Please clean the unit with soft cotton cloth, don't use the organic impregnant or chemical clean agent. If necessary, please use a little pure water or dilute soap water to clean the dust • The unit is weather resistant. However do not spray high pressure water onto door station directly. - Page 17 APPENDIX Cables and Requirments The maximum distance of the wiring is limited in the DT system. Using different cables may also affect the maximum distance which the system can reach Basic IN-OUT Wiring Mode Cable and distance(unit:m) Cable Usage ≤2 IM ≤16 IM Twisted cable 2x0.75mm Twisted cable 2x1mm...
- Page 18 APPENDIX Star Topology Wiring Mode With DBC4A1 DBC4A1 PC6A Cable and distance(unit:m) Cable Usage Twisted cable 2x0.75mm Twisted cable 2x1mm -15-...
- Page 19 Note -16-...
- Page 20 DT-ENG-DT607C-V1 The design and specifications can be changed without notice to the user. Right to interpret and copyright of this manual are preserved.
