Axiom MC13192U Hardware User's Manual

Application module for the freescale mc13192 2.4ghz rf transceiver

Hide thumbs

Table Of Contents

Table of Contents

Quick Links

Download this manual

DOC-0361-010 Rev B.

Application Module for the Freescale MC13192

Reference Documentation:

1) SMAC software and documentation for Microcontroller specific software application

notes.

2) Freescale MC13192RM and MC13192EC device reference manuals for detailed

transceiver device operation and electrical specifications.

1) See the

www.Freescale.com

MC13192 internet web page for full support documentation and application notes.

The MC13192U module schematic and hardware support information may be found

at the

www.axman.com

section.

Cautionary Notes: ........................................................................................................................... 2

Terminology.................................................................................................................................... 3

Module Features ............................................................................................................................. 3

Module Block Diagram................................................................................................................... 4

Operational Description .................................................................................................................. 4

Channel Frequency Chart ........................................................................................................... 5

Module Option Jumpers.................................................................................................................. 6

JP1 - Select Signal Option .......................................................................................................... 6

JP2 – Clock-Out Enable Option.................................................................................................. 6

J1 Connector – Default Host I/O Connection ................................................................................. 6

J2 Connector ................................................................................................................................... 7

J104 – SMA Test Connector........................................................................................................... 7

Installation ...................................................................................................................................... 7

MCU Project Board - Module Installation.................................................................................. 8

CSM, DEMO or Host MCU Board - Module Installation on Socket Header ............................ 8

CSM, DEMO or Host MCU Board - Module Installation on Ribbon Cable.............................. 9

Supporting Platforms and Signal Charts......................................................................................... 9

CSM-12C32 Module Platform:................................................................................................. 10

DEMO9S08RG60 Module Platform: ....................................................................................... 10

Axiom Manufacturing • 2813 Industrial Lane • Garland, TX 75041

Email:

– Wireless and mobile - ZIGBEE™ - Transceivers –

internet web site in the Support – MC13192U Module

Table of Contents

Sales@axman.com

MC13192U

2.4GHz RF Transceiver

Hardware User Guide

Web:

http://www.axman.com

07/21/06

Table of Contents

Need help?

Do you have a question about the MC13192U and is the answer not in the manual?

Questions and answers

Summary of Contents for Axiom MC13192U

Page 1 – Wireless and mobile - ZIGBEE™ - Transceivers – MC13192 internet web page for full support documentation and application notes. The MC13192U module schematic and hardware support information may be found at the www.axman.com internet web site in the Support – MC13192U Module section.
Page 2: Cautionary Notes
1) Electrostatic Discharge (ESD) prevention measures should be applied whenever handling this product. ESD damage is not a warranty repair item. 2) Axiom Manufacturing reserves the right to make changes without further notice to any products to improve reliability, function or design. Axiom Manufacturing does not assume any liability arising out of the application or use of any product or circuit described herein;...
Page 3: Terminology
♦ Supplied in Module pairs with Documentation (CD), User Manual, and SMAC example software The MC13192U provides a low cost method to apply short range RF communication to any system. Supporting application software examples are available for Freescale Coldfire™, HC(S)12, and HCS08 targets. Modules are provided in pairs in the standard...
Page 4: Module Block Diagram
Standard installation places module at 90 degrees vertical to controller or host platform. Versatile connection to host controller boards will allow stacking in different configurations or connection by ribbon cable, contact Axiom with special requirements. Module applies an embedded antenna and derives the 3.3V to 5.5V DC input power from the supporting host platform so no other accessories are required.
Page 5: Channel Frequency Chart
MC13192U Transceiver Module User Guide Operation of the module provides four basic modes that are inherent in the MC13192 transceiver device: Standby (sleep), Idle (enabled but not active), Receive, and Transmit. Refer to the MC13192 reference manual for specific details on the modes. At power on the MC13192 enters the Standby mode.
Page 6: Module Option Jumpers
Position 1-2 (default): Enables the host MCU SPI port SS* signal or J1 pin 23 as the MC13192U select signal. Position 2-3: Enables the host MCU secondary select signal or J1 pin 24 as the MC13192U select signal. See the connection charts to determine signal name applied for particular host MCU. JP2 – Clock-Out Enable Option JP2 enables the MC13192 device optional clock output signal to connector J2 pin 14.
Page 7: J2 Connector
The module applies the J1 connector, a 24 pin (2x12) right angle .1 inch space pin header, for connection to the host controlling platform by default. This connector is configured for compatibility with many Freescale DEMO series MCU boards or Axiom CSM series microcontroller application boards, and the MCUSLK Project Board. User should review the Supporting Platform section for standard connections to host controller platforms.
Page 8: Mcu Project Board - Module Installation
Module DEMO or Host MCU Board Installation notes: 1) Host MCU board MCU Port and MC13192U Module J1 connectors align for pins 1 – The Host Board must be configured to supply regulated power on J1 pin 1 (+3.3V to +5.5V) and pin 3 (Ground).
Page 9: Csm, Demo Or Host Mcu Board - Module Installation On Ribbon Cable
1 – 24. Ribbon Cable Installation notes: 1) Host MCU board MCU Port and MC13192U Module J1 connectors align for pins 1 – 24 into and out of the ribbon cable. The Host Board must be configured to supply regulated power on J1 pin 1 (+3.3V to +5.5V) and pin 3 (Ground).
Page 10: Csm-12C32 Module Platform
MC13192U Transceiver Module User Guide CSM-12C32 Module Platform: CSM12C32 J1 Signal J1 Pin J1 Signal CSM12C32 I/O Signal Name Name I/O Signal VDD (3.3 - 5) 1 2 IRQ_OUT* PE1/IRQ* GND (vss) 3 PP5/KWP5 IDLE (GPIO1) 9 10 x PE0/XIRQ*...
