- Page 1 Operating Manual SkyFunk 4 2,4 GHz wireless transmission system for 2 signal sources With 4 channels for audio and video transmission and 16 channels for transmission of remote control signals.
- Page 2 Technical data ..... . .8 European regulations TechniSat hereby declares that the product SkyFunk 4 com- plies with the basic requirements as well as the other rele- vant regulations set out in Guideline 999/5/EG.
-
Page 3: General
1 guarantee card 1 operating manual 2 General The SkyFunk 4 system serves to provide wireless transmissi- on of video and stereo audio signals. To do this, the video and audio signals of one or two sources (e.g. a satellite receiver or a video recorder) are converted by the transmitter to a frequency of approx. -
Page 4: Connections
This is essential to ensure error-free transmission of the remote control signals. > When you have completed establishing the above- mentioned connections, connect the mains adapter supplied with the DC input socket of the SkyFunk 4 transmitter. -
Page 5: Setting Up The Units
Connecting the SkyFunk receiver TV set Receiver Mains adapter Adapter cable (receiver) > Connect the cinch connector of the Scart-cinch adap- ter cable supplied marked Receiver with the Sky- Funk 4 receiver. Please ensure that jacks and sockets of the same colour are connected with each other. -
Page 6: Operation
If reception is still not satisfactory, check whether reception is improved on an alternative channel. 5 Operation Once you have completed all the above points, your SkyFunk 4 is ready for use. Mains (power) switch > Switch on both units, using the mains (Power) switch on the back panel of each unit. - Page 7 AV channel setting IR channel setting 5.1 Setting the transmission and reception channel for audio and video signals (AV channel) To change the transmission or reception channel, set the desired channel on both units (transmitter and receiver). The switches used to select the channel are located on the under- side of the units.
-
Page 8: Trouble-Shooting Guide
5.3 Reflection of IR signals The IR-reflect function of the transmitter means the IR signals are reflected by walls and furniture in such a way that you can control the AV sources by remote control. Ideally, ensure d i o there is a distance of around 5 m between the transmitter and a reflecting surface, e.g.
