Summary of Contents for Mazi PP-06
- Page 1 Video/Audio Distributor Quick Start Guide PP-06/PP-12...
- Page 2 Video/Audio Distributor·Quick Start Guide Quick Start Guide This quick start guide is intended for users of video/audio distributor. Disclaimer REGARDING TO THE PRODUCT WITH INTERNET ACCESS, THE USE OF PRODUCT SHALL BE WHOLLY AT YOUR OWN RISKS. OUR COMPANY SHALL NOT TAKE ANY RESPONSIBILITES FOR ABNORMAL OPERATION, PRIVACY LEAKAGE OR OTHER DAMAGES RESULTING FROM CYBER ATTACK, HACKER ATTACK, VIRUS INSPECTION, OR OTHER INTERNET SECURITY RISKS;...
-
Page 3: Regulatory Information
Video/Audio Distributor·Quick Start Guide Regulatory Information FCC Information Please take attention that changes or modification not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. FCC compliance: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. - Page 4 Video/Audio Distributor·Quick Start Guide 2006/66/EC (battery directive): This product contains a battery that cannot be disposed of as unsorted municipal waste in the European Union. See the product documentation for specific battery information. The battery is marked with this symbol, which may include lettering to indicate cadmium (Cd), lead (Pb), or mercury (Hg).
- Page 5 Video/Audio Distributor·Quick Start Guide Safety Instruction These instructions are intended to ensure that user can use the product correctly to avoid danger or property loss. The precaution measure is divided into Warnings and Cautions: Warnings: Neglecting any of the warnings may cause serious injury or death. Cautions: Neglecting any of the cautions may cause injury or equipment damage.
- Page 6 Video/Audio Distributor·Quick Start Guide Please use the provided glove when open up the device cover, avoid direct contact with the device cover, because the acidic sweat of the fingers may erode the surface coating of the device cover. Please use a soft and dry cloth when clean inside and outside surfaces of the device cover, do not use alkaline detergents.
- Page 7 Video/Audio Distributor·Quick Start Guide Table of Contents 1 Overview ...................... 1 1.1 Introduction ..........................1 1.2 Main Features ........................... 1 2 Appearance ....................2 2.1 Appearance of Type I Model ..................... 2 2.2 Appearance of Type II Model ....................2 3 Interfaces Description ..................
-
Page 8: Main Features
Video/Audio Distributor·Quick Start Guide 1 Overview 1.1 Introduction The video/audio distributor supports network cable power supply, and has a built-in voltage-stabilized power. The type I model has eight 10/100M LAN interfaces, six of which support powering over network cables, and the type II model has sixteen 10M/100M LAN interfaces, twelve of which support powering over network cables. - Page 9 Video/Audio Distributor·Quick Start Guide 2 Appearance 2.1 Appearance of Type I Model Figure 2-1 Front Panel Figure 2-2 Rear Panel Table 2-1 Description Description 8 RJ-45 interfaces Power Indicator AC 220V, Power Socket 2.2 Appearance of Type II Model...
- Page 10 Video/Audio Distributor·Quick Start Guide Figure 2-3 Front Panel Figure 2-4 Rear Panel Table 2-2 Description Description 16 RJ-45 interfaces Power Indicators AC 220V, Power Socket...
- Page 11 Video/Audio Distributor·Quick Start Guide 3 Interfaces Description 3.1 Interfaces of Type I Model Figure 3-5 Interface of Type I Model Interfaces B1 and B2 can be connected to a distributor with a network cable. Interfaces A1, A2, A3, A4, A5, and A6 are device interfaces. Only video intercom devices supporting Power over Network Cable can be connected to device interfaces.
- Page 12 Video/Audio Distributor·Quick Start Guide Interfaces C1, C2, D1, and D2 can be connected to a distributor with a network cable. Interfaces A1, A2, A3, A4, A5, A6, B1, B2, B3, B4, B5, and B6 are device interfaces. Only video intercom devices supporting Power over Network Cable can be connected to device interfaces.
-
Page 13: Typical Application
Video/Audio Distributor·Quick Start Guide 4 Typical Application Building Client Software Indoor Indoor Extension 1 Extension 2 Resident 1 Resident 2 Video/Audio Distributor Center Master Station (Master Station) Resident 1 Resident 2 Switch Resident 1 Resident 2 Estate LAN Master Station in Guard's Room Video/Audio Resident 1... - Page 14 Video/Audio Distributor·Quick Start Guide 5 Installation (Wall Mounting) The video/audio distributor can be put on the desk or be installed onto the wall. Here we take the installation of type II model as example. Please refer to the bottom panel of the video/audio distributor. Figure 5-8 Dimensions of Bottom Panel Steps: 1.
- Page 15 Video/Audio Distributor·Quick Start Guide Appendix Spectification of Type I Model Model Type I Parameters Network Parameters Interface Number Sixteen 10M/100M Interfaces Interface Type RJ-45, Full/Half-Duplex, MDI/MDI-X Self-Adaptive Standard IEEE802.3, IEEE802.3u, IEEE802.3x Processing Type Storing and Forwarding Flow Control IEEE802.3x (Full-Duplex), Back Pressure (Half-Duplex) Priority Queue Four MAC Address List...
- Page 16 Video/Audio Distributor·Quick Start Guide Processing Type Storing and Forwarding Flow Control IEEE802.3x (Full-Duplex), Back Pressure (Half-Duplex) Priority Queue Four MAC Address List Internal Buffer 1 Mbit Other Parameters Power Supply AC 220V Power Consumption <6 W Working Temperature -30° C to 70° C (-22° F to 158° F) Working Humidity 5% to 95%, No Condensation Dimension...
