DynaStar AeroDactyl TS Assembly Manual

Skill Level 3
Average Skills Needed
The AeroDactyl TS is a simple-to-build two-stage, payload
carrying rocket that was designed around the Estes 29mm diameter
rocket engines. These engines are low thrust, and therefore need
a low weight rocket for maximum speed performance. With these
motors, the rocket leaves a thick smoke trail as it zooms skyward.
The kit features a slotted body tube that allows the laser cut fins
to mount perfectly straight on the rocket. This allows the rocket to fly
straight and true. It also has a large payload bay, which can be used
to fly things like altimeters and other scientific payloads. You'll find
that it is a very versatile rocket because it can be used with a variety
of rocket motors. You can also fly the model as a single-stage vehi-
cle. With so many options it will never bore you.
Kit #05041
Skill Level 3
AeroDactyl TS Parts List
Item # Item Name
10252 AT-29/5.25 Laser Cut Booster Stage Engine
Mount Tube
10250 AT-29/7" Sustainer Stage Engine Mount Tube
10188 AT-66/18" Laser-Cut Sustainer Tube: 3-Slots
10189 AT-66/18" Laser-Cut Booster and Payload
tube: 3 Slots
12381 CBD-66 Plywood Disk
13039 AC-66A (Red) Laser-Cut
13044 AC-66A (Red)
13035 CR 24/29 (Green)
13315 CR 29/2.6"
13056 1/4" Launch Lug 3.0"
15565 AeroDactyl TS Sustainer Fin Sheet 1/8" Balsa
15566 AeroDactyl TS Booster Fin Sheet 1/8" Balsa
19480 Nose Cone PNC-66
23011 Parachute Rings
29117 DynaStar 32" Plastic Parachute
29500 Cotton Parachute String
29506 Kevlar Shock Cord 300#
29624 Wood Screw Eyelet Size 9
31105 AeroDactyl TS Instructions Sheet A 11x17
31106 AeroDactyl TS Instructions Sheet B 8.5x11
31107 AeroDactyl Fin Template Sheet
41012 AeroDactyl Decal
39034 AeroDactyl Face Card
Needed Tools and Materials
… Hobby Knife with Sharp Blades
… Ruler
… Wood Glue (recommended) or White Glue
… Sand Paper 200 grit
… Masking Tape
… Pencil
… Scissors
… Paper Towel
… Wood Dowel
Optional Tools / Finishing Supplies
… Super Glue (CyA Adhesive medium viscosity)
… Plastic Sheet (to cover the work surface)
… Paint Supplies: (Spray Paint, Brushes, etc)
… Wood Sealer/Sanding Sealer
… Safety Glasses (For general protection while building)
Mid-Power Rockets
Manufactured in the USA by:
Apogee Components Inc.
Colorado Springs, Colorado, USA
Visit us online at:
www.DynaStar-Rockets.com
Made In USA
Qty
1
1
1
1
1
1
1
2
4
1
1
1
1
8
1
21ft
10ft
1
1
1
1
1
1
P/N 31105
