Summary of Contents for EXAGATE SYSGuard 6001
- Page 1 SYSGuard 6001 Quick Installation Guide...
- Page 2 12 V DC Adapter safely. Step 1 Plug-in 12 V DC Adapter to SYSGuard 6001 Main Unit. Wait for the “READY” LED. When the LED comes online SYSGuard 6001 Main Unit is ready to run. Step 2 Main unit is equipped with default IP address (192.168.1.131).
- Page 3 Step 5 Plug the ExaBus Cable in the ExaBus Port of the sensor so that it communicates with SYSGuard 6001 Main Unit or SYSGuard 6070 Expansion Module. Confirm that Power LED of ExaBus Port constantly lights. Press sensor assignment button for 2 seconds, Marking LED of the sensor will light. When sensor is detected by SYSGuard 6001 Main Unit Marking LED does not light anymore.
- Page 4 Operational Properties Power Supply Voltage 10,5 - 14,4 VDC typical 12 VDC Power Consumption 0,22 - 0,36 A typical 0,24 A 2,64 - 4,62 W typical 2,88 W Operational Temperature Range -10 +70 Operational Humidity Range 0 - 85 % Rh Storage Temperature Range -40 +85 Storage Humidity Range...
- Page 5 RS-232 1.18 in POWER 30 mm READY 10.63 in 270.2 mm 12.22 in 310.5 mm Top Panel View 4.10 in 104.3 mm SYSGUARD 6001 0.24 in 6.2 mm Main Unit Rear Panel View 12V 2.5A RESET 0.37 in 9.6 mm...
- Page 6 Installation Notes: ………………………………………………………………………………………………………………………………………………..…………………………………………………………………………………………………………………………………………………. …………………………………………………………………………………………………………………………………………………. …………………………………………………………………………………………………………………………………………………. …………………………………………………………………………………………………………………………………………………. …………………………………………………………………………………………………………………………………………………. …………………………………………………………………………………………………………………………………………………. …………………………………………………………………………………………………………………………………………………. …………………………………………………………………………………………………………………………………………………. …………………………………………………………………………………………………………………………………………………. …………………………………………………………………………………………………………………………………………………. …………………………………………………………………………………………………………………………………………………. …………………………………………………………………………………………………………………………………………………. …………………………………………………………………………………………………………………………………………………. …………………………………………………………………………………………………………………………………………………. …………………………………………………………………………………………………………………………………………………. …………………………………………………………………………………………………………………………………………………. …………………………………………………………………………………………………………………………………………………. …………………………………………………………………………………………………………………………………………………. …………………………………………………………………………………………………………………………………………………. …………………………………………………………………………………………………………………………………………………. …………………………………………………………………………………………………………………………………………………. …………………………………………………………………………………………………………………………………………………. …………………………………………………………………………………………………………………………………………………. …………………………………………………………………………………………………………………………………………………. ………………………………………………………………………………………………………………………………………………….
- Page 7 (Warranty duration may change depending on your country) Your sales or delivery receipt, showing the date of purchase of product is your proof of purchase. ExaGate is obliged to repair or replace the defective hardware (or any part of it’s) with no charge to owner.
