Summary of Contents for Genie CCTV POE-INJ01S
- Page 1 POE-INJ01S Power Over Ethernet Injector User Manual...
- Page 2 Single Port : 61 x 40 x 12 mm *Design and Specifications are subject to change without notice. 5. Identifying External Components Colour Function Power Green Lights to indicate that POE injector is powered Yellow Lights to indicate the port in providing 48v DC Power POE-INJ01S - Power Over Ethernet Injector...
- Page 3 IEC cable to a Power source. 3. Use a Cat5/6 Cable to connect the Power Out Socket to a PoE Device such as a PoE compliant IPNC. 8. Network Diagram Power Switch POE-INJ01 IP Camera POE-INJ01S - Power Over Ethernet Injector...
- Page 4 GENIE CCTV LTD. CCTV House, City Park, Watchmead, Welwyn Garden City, Hertfordshire, AL7 ILT Tel: +44 (0) 1707 330541 Fax: +44 (0) 1707 330543 www.geniecctv.com Edition. GN-November 2015...
