- Page 1 operating manual hyperion colorimeter...
- Page 2 Contents Introduction ..................3 White point references .............. 11 Measurement commands ............12 Hyperion ..................3 Hyperion highlights ..............3 User EEPROM commands ............13 Returned results ................ 15 Standards ..................4 Interfaces ..................... 5 Measurement example ..............16 USB interface ................5 Auto-ranging ..................
- Page 3 1 Introduction 1.1 Hyperion The Hyperion series colorimeter offers a unique combination of high speed and accurate colour measurement capabilities packed in a robust package. The improvement compared to the previous colorimeters is that the Hyperion has a significant improvement on filter characteristics and an incredible speed upgrade.
- Page 4 Windows, Linux and Apple OSX using NI VISA (www.ni.com/visa) and using the open source drivers on Linux (i686, x86_64 and ARM). Refer to the Admesy support site for a more detailed description and free source code or contact us.
- Page 5 2 Interfaces 2.1 USB interface The USB-B connector is used to connect the Hyperion to a PC/Laptop. The Hyperion uses the USBTMC class protocol and can therefore be used directly with third party provided VISA compliant libraries like NI-VISA. Hyperion can be used USB powered in case the host provides enough current.
-
Page 6: Interfaces 5
2.3 Trigger in/out 2.4 Power connections The Hyperion colorimeter has two trigger connections. One trigger output The Hyperion should be connected to USB with enough supply or using a and one trigger input. The type of connectors is SMA. When triggering is 9V DC power supply to the RS232 connector. -
Page 7: Communications Protocol
Hyperion colorimeter firmware. As soon as the firmware is idle to receive commands, the Power LED goes to the on state. The Admesy bootloader is a RAW USB device and in order to use this device in Windows, a driver must be installed which is supplied by Admesy. - Page 8 · · available Table 3 Supported operating systems. 1 Not tested: Available, but not tested by Admesy, 2 Native Kernel: Driver included with OS. 2 Windows XP SP3 is supported: Windows official support has ended as of April 8 2014...
- Page 9 5 Command set description Command table Valid command Notes syntax examples :SENSe: INT 50000 :sens:int 500000 Sets the integration time 5.1 Commands :sense:int 500000 of the Hyperion to 50ms The functions of the Hyperion can be best described via the following :SENS:INT 500000 categories.
- Page 10 0 – 1 5.4 Configuration commands :SENSe: SHUTter State Set shutter open/close 0 = open, 1 = close Configuration commands are used to set parameters of the Hyperion Returns shutter state :SENSe: None colorimeter that are used by the measurement functions. The settings are SHUTter? used globally by other measurement functions.
-
Page 11: White Point References
White point references Reference white " A" 100.0000 0.447587 0.407454 "D65" 100.0000 0.31271 0.329022 "C" 100.0000 0.310038 0.316106 "D50" 100.0000 0.345662 0.358506 "D55" 100.0000 0.33242 0.347438 "D75" 100.0000 0.299023 0.314871 "FL1" 100.0000 0.185922 0.273141 "FL2" 100.0000 0.184704 0.337311 "FL3" 100.0000 0.187339 0.379794 "FL4"... -
Page 12: Measurement Commands
5.6 Measurement commands Command syntax Parameters Range Purpose :MEASure:XYZ None Measure XYZ Table 9 shows the measurement commands of the Hyperion colorimeter. :MEASure:Yxy None Measure Y and x,y Regarding colour/luminance measurement, there are two kind of colour point :MEASure:Yuv None Measure Y and u',v' commands (MEASure/SAMPle). -
Page 13: User Eeprom Commands
5.7 User EEPROM commands :EEPROM: None Reads the configured delay before triggering CONFigure:TRIGD Table 10 shows the commands which can be used to store values in the the Hyperion. ELAY? user EEPROM space. It is advised to reboot the Hyperion after writing new 1 –... - Page 14 :EEPROM:CONFig None Reads the auto-range :EEPROM:READ: Reads the output unit setting (luminance, illuminance) ure:AUTORANGE UNIT :EEPROM: Read device ID “D65”, “A” etc :EEPROM:CONFig String[4] Used for Dominant READ:ID wavelength ure:WHITE (see table: 8) :EEPROM:WRITE Write all settings to :EEPROM:CONFig None Gets the currently EEPROM configured white point...
-
Page 15: Returned Results
5.8 Returned results :MEASure command return their result in ASCII formatted floating point as Exceptions to the above are the :MEASure:TEMPerature, :MEAS:Y and shown below where X,Y,Z can be substituted for Y,u,v or other colour :SAMPle:Y commands. spaces. :MEASure:TEMPerature → (Sensor temperature) → (X,Y,Z,clip,noise) →... -
Page 16: Measurement Example
6 Measurement example open device Open device (VISA open, RS232 port initialisation) The Hyperion uses default settings when the device is started. These can be programmed by the end user so that the device starts with the same settings each time it is connected. :sens:aver 1 Set averaging to 1 sample Although it's possible to program all Hyperion devices in production... -
Page 17: Auto-Ranging
7 Auto-ranging 7.1 Introduction 7.2 How auto-ranging works The Hyperion includes an auto range function. This function is useful in The auto-ranging works, by first setting a default integration time. If this case the measured object shows an unknown luminance value. In this already meets the criteria for a good measurement, the measurement will case, the Hyperion will try to find the optimum setting which is a trade-off be done using that integration time. -
Page 18: Auto-Range Parameters
Adjmin is set from 1-100, which means 1-100% of Max int = 200000 the Adjmax level (Adjmax is fixed by Admesy). These settings will provide a stable measurement on white and black. Maximum integration time: Although not really part of the auto- Auto-range algorithm will adjust to measure black 0.3cm/m... -
Page 19: Programming Hyperion For Auto-Ranging
However, additional measurement / test time. it requires the right settings to be set in advance. This can be done though Regarding the grey scales, like a gamma measurement is performed, Admesy Iliad application select DeviceStart-up... -
Page 20: Hyperion Formulas
8 Hyperion formulas 8.3 XYZ to CIE 1976 UCS Yu’v’ 8.1 Formulas The Hyperion colorimeter uses an XYZ sensor, meaning that other colour u'v' is noted without the hyphen in the Hyperion commands. All Yuv spaces are being converted from XYZ. The following sections show the commands perform CIE Yu'v' calculations. -
Page 21: Flicker Calculation
FFT to determine the AC and DC level of the measured signal. needed, it is recommended to acquire the raw data from the Hyperion and perform the calculation externally as for example in the Admesy Iliad application. The Hyperion has six types of flicker measurement, each with... - Page 22 After calculating the FFT, a weighting factor is applied to compensate for The amplitudes found in the previous page (P0 and P1) are reduced by human eye sensitivity to frequency. This has been defined as shown in the the factors and the final result will then be: graph and table below.
-
Page 23: Additional Colour Spaces
8.5 Additional colour spaces Admesy provides a colour library for its customers. This library is supplied Percent Flicker :MEASure:FLICker 4,samples,delay in the form of a shared library and contains all of the above calculations and a lot of additional colour space conversions and handy routines for ��... -
Page 24: Operating Mode
9 Operating mode 10 Typical spectral sensitivity The operating mode only matters in trigger mode. The mode is used to send back results by USB or RS232. The modes of the Hyperion are. USB mode RS232 mode A trigger actives only one command, for example “:meas:xyz”. This command needs to be set first by the host. - Page 25 Admesy B.V. The material in this document is subject to change. No rights can be Sleestraat 3 derived from the content of this document. All rights reserved. No part of 6014 CA Ittervoort this document may be reproduced, stored in a database or retrieval...
