D
S
ean
toves
Dean Forge Fabrication Ltd. Dean Prior, Buckfastleigh, Devon TQ11 0LS
T e l: 0 1 3 6 4 6 4 3 5 7 4
w w w.d e a n–f o r g e.c o.u k
e m a i l: s t o v e s @ d e a n-f o r g e.c o.u k
Operating Instructions for the Dean Stoves 105SE Inset
(
105IS issue1st October 2016)
All stoves meet the essential type test requirement
BS EN13229:2001 + A1:2003 +A2:2004, CE marked
The 105Se inset is Ecodesign ready and satisfies all the stringent
emission requirements.
The Clean Air Act 1993 and Smoke Control Areas
Under the Clean Air Act local authorities may declare the whole or part of the district of the
authority to be a smoke control area. It is an offence to emit smoke from a chimney of a
building, from a furnace or from any fixed boiler if located in a designated smoke control area.
It is also an offence to acquire an "unauthorised fuel" for use within a smoke control area
unless it is used in an "exempt" appliance ("exempted" from the controls which generally apply
in the smoke control area).
The Secretary of State for Environment, Food and Rural Affairs has powers under the Act to
authorise smokeless fuels or exempt appliances for use in smoke control areas in England. In
Scotland and Wales this power rests with Ministers in the devolved administrations for those
countries. Separate legislation, the Clean Air (Northern Ireland) Order 1981, applies in
Northern Ireland. Therefore it is a requirement that fuels burnt or obtained for use in smoke
control areas have been "authorised" in Regulations and that appliances used to burn solid
fuel in those areas (other than "authorised" fuels) have been exempted by an Order made and
signed by the Secretary of State or Minister in the devolved administrations.
The Dean Stoves, 105Se inset has been recommended as suitable for use in smoke control
areas when burning wood logs.
To use the 105Se inset in smoke controlled areas the smoke control kit must be fitted to the
stove.
Further information on the requirements of the Clean Air Act can be found here:
http://smokecontrol.defra.gov.uk/
Your local authority is responsible for implementing the Clean Air Act 1993 including
designation and supervision of smoke control areas and you can contact them for details of
Clean Air Act requirements
Important
You will find a rectangular shaped plate with slotted holes in it, situated on the top of the main
grate. This grate is design to retain the ash when burning wood only and must NOT be used
when burning solid fuel (smokeless fuel or similar) or a mixture of wood and solid fuel. This
plate can be lifted out prior to lighting the fire, if required. Although the stove will burn wood
straight on the solid fuel grate, the rectangular shaped plate retains the ash and helps to give a
slower and hotter burn. By using the suppled tool/poker the ash can be pushed backwards and
forwards which will help it drop through to the ash pan. Always leave a small layer of ash on
the plate.
1
Advertisement
Summary of Contents for Dean Stoves 105SE
- Page 1 The Dean Stoves, 105Se inset has been recommended as suitable for use in smoke control areas when burning wood logs. To use the 105Se inset in smoke controlled areas the smoke control kit must be fitted to the stove. Further information on the requirements of the Clean Air Act can be found here: http://smokecontrol.defra.gov.uk/...
- Page 2 Unpacking Stove Remove all packaging and stickers, Check the protective brick lining and the baffle plate has not moved in transit. Remove the glove pack and operating tool from the inside of the stove. Safety Note Warning- The external parts of the appliance will get very hot to the touch and due care will be needed when operating.
-
Page 3: Door Operation
Door Operation The door handle can become very hot so use the glove provided. Handle:- When closed the door handle will be pointing down and straight with the door. Twist the door handle about ¼ of a turn anti – clockwise to open the door. Controlling the stove Diagram A: Primary and secondary air controls situated below the door... - Page 4 Lighting The Stove When Using Wood Lay a fire of sticks and paper. Firelighters can be used if necessary. Check the secondary air lever is fully open and the primary air is partially open. Light the fire and as the fire catches the paper you may then fully open the primary air vents.
- Page 5 Warning: The ash pan and content can be hot and must be stored in a non-flammable container away from flammable material then disposed of only when they are completely cold and there is no risk of causing a fire. Lighting The Stove With Solid Fuel Remove the rectangular shaped woodburning plate if in place.
- Page 6 Notes Down draughts In adverse weather conditions, a down draught may occur and this could make the stove smoke, if this should happen shut all the stove air controls. If this occurs on a regular basis call in your engineer. It is possible a chimney cowl could cure this problem.
-
Page 7: Securing The Stove
As with all stoves, fireguards must be installed when young children are present. Surround Frame The 105Se inset is supplied with an extension frame. This frame can be used when the fireplace aperture cannot be covered by the stove alone. The frame sits behind the stove front before the stove is secured into the fire place aperture. - Page 8 105Se Inset stove can be flued from its angled top outlet The 105Se inset model has a 125mm outlet and will need to be stepped up to a 150mm (6”) flue liner from the spigot unless the DEFRA stop is installed. The 105Se inset comes as standard with the DEFRA stop fitted, if the DEFRA stop is left in place then a 125mm liner/flue system can be installed.
-
Page 9: Data Plate
Diagram of flue outlet Pre – Lighting Check and Commissioning Check all Building Regulations have been adhered to. The baffle plate is in the right position. A smoke test has been done to check the chimney is clear. Data Plate All stoves are numbered and performance marked on a data plate which is found on a swinging arm located at base of the stove. - Page 10 Stove Type Flue gas temp down stream of spigot, closed doors. Wood logs Maxibrite 105Se Inset 292°C 283°C Stove Type Flue gas mass flow (g/s) Wood logs Maxibrite 105Se inset Distances from combustibles :- From a shelf above the stove 400mm...
- Page 11 Description of product: 105Se inset multi-fuel heating stove product range. Steel bodied stove fitted with a steel door. Are in conformity with the provisions of the following EC Directive (S) when installed in accordance with the installation instructions in the product...
- Page 12 Product Fiche according to Commission Delegated Regulation (EU)2015/1187 Energy Labelling of Local Space Heaters Supplier's Name Dean Stoves Model 105Se inset Energy Efficiency Class Nominal Heat Output to Room (KW) Nominal Heat Output to Water (KW) Seasonal Space Efficiency (%) 67.0 Net Efficiency (%) 77.0...
- Page 13 THE DEAN FORGE FABRICATION LTD STOVES GUARANTEE Dean Forge Fabrication Ltd offers a five year guarantee which covers the main body of the stove for manufacturing defects. In the event of any failure we will replace any defective part free of charge, labour cost excluded.
- Page 15 Dean Forge Fabrication Ltd Dean Prior Buckfastleigh Devon TQ11 0LS PRODUCT REGISTRATION Name ......................Address ...............................................................................Phone Number: ..........Suppliers Details: Name ......................Address ...............................................................................Phone Number: ..........Installers Details: Name ......................Address ...............................................................................Phone Number: ..........
