Page 1 Assembly and Operation Instructions ebios-fire inserts GB 1...
Page 2 FOREWORD / QUALITY PHILOSOPHY You have chosen a Spartherm ebios-fire. Thank you for your confidence in our technology. In a world characterised by excess and mass production, the good name of our firm is inextricably linked to the credo of our owner, Gerhard Manfred Rokossa: “High technical quality combined with modern design and on-site customer...
Page 3 CONTENTS 1. General Information 5. Maintenance / Troubleshooting 1.1 Scope of delivery 5.1 Unit and glass seriously soots up, fast and unevenly 5.2 Fire ist difficult to ignite 2. Installation Instructions 5.3 Bad smell 2.1 Technical data 5.4 Appearance of flames changes 2.2 Burner mat CERAMAT FN 5.5 Spilt ethanol catches fire 2.3.
Page 4: General Information
Young children, the elderly and the frail: As with all naked flames, a guard allowed by the regulations: should be used to protect the above. Risk of burns! Never leave such individuals unsupervised near an ebios-fire when it is lit or when the fire Storage in basement: max. 20 litres has just gone out.
Page 5: Installation Instructions
The unit must be installed in such a way that it cannot be knocked over or tilted. The fire should be installed and lit for the first time by a Spartherm-authorised specialist. 2.1 TECHNICAL DATA Fig. 1 ebios-fire Item Designation Cover plate Bio-Ethanol...
Page 6 Point this out to your children and other per- sons in the household. ** This information refers only to the ebios-fire air demand for combus- tion. Any further air consuming devices in the room must be considered separately.
Page 7 Model ebios left end open 2L Model ebios left end open 2R Installation in furniture panel Installation in furniture panel Placement Placement Installation in fireplace casing Installation in fireplace casing Number of burners Number of burners Width mm Width mm Depth mm Depth mm Height mm...
Page 8 Model ebios C-shape C Model ebios double sided FD Installation in furniture panel Installation in furniture panel Placement Placement Installation in fireplace casing Installation in fireplace casing Number of burners Number of burners Width mm Width mm Depth mm Depth mm Height mm Height mm Weight kg...
Page 9: Burner Mat Ceramat Fn
Installation in furniture panel Placement Installation in fireplace casing The ebios-fire may only be installed in rooms and locations where the posi- Number of burners tion, structural conditions and type of use are without risk. The floor area of the installation room must be large enough and designed such that the Width mm ebios-fire can be operated in the proper manner as designed.
Page 10: Installation Location
2.5 INSTALLATION / ASSEMBLY The following must be observed to ensure safe and easy transportation: • The ebios-fire may only be lifted with transport aids from its rear side (if The ebios insert is a ready-to-use unit for fitting into a custom-made piece required), especially if sack barrows are used.
Page 11: General Instructions For Installation In Custom-Made Furniture Fireplace Casings
2.6. GENERAL INSTRUCTIONS FOR INSTALLATION 2.6.1 MINIMUM FURNITURE/FIREPLACE CASING IN CUSTOM-MADE FURNITURE/FIREPLACE DESIGN DIMENSIONS CASINGS • The front plate of the furniture unit should be of 2-part construction to • All minimum distances and installation dimensions must be observed facilitate installation. when designing the custom-made furniture.
Page 12: Installation Of Quadra Inside
2.6.2 INSTALLATION OF QUADRA INSIDE 1. The air inlet and air outlet panel can be removed to facilitate installation. 2. Place the ebios insert inside the ready-prepared interior of the furniture unit and level it up. 3. Screw the fire insert on to the furniture side panel, working from the 755 (Cut-out) bottom of the housing interior.
Page 13: Fire Precautions/Minimum Distances With Ebios Insert
7. Screw the Quadra Inside to the ebios insert at the 6 screw points provided. 8. Place the burner in the housing. Fig. 7 Air gap approx. 9 mm (without cover panel) 2.7 FIRE PRECAUTIONS/MINIMUM DISTANCES WITH EBIOS INSERT 9. Close the Quadra Inside housing cover. Please observe the correct posi- tioning so that there is a uniform air gap all round between the housing cover and the flame area (refer to Fig.
Page 14: Operating Instructions
• Never place any flammable objects on the open surfaces of the ebios insert. Do not place any items of washing on the ebios-fire unit for drying. Position racks for drying clothes outside the radiating range only Fig.
Page 15: Fuel
(wait for at least 1 hour after extinguishing). are prohibited. • Do not smoke when handling the fuel and the ebios-fire. • Any modifications to the ebios-fire units are prohibited • This is a decorative fireplace for private household use - it is not intended...
Page 16: Initial Operation
The ebios unit with the Quadra Inside is supplied with an empty burner to avoid spilling or evaporation of ethanol during transport. Ensure (especially before initial operation) that there is no ethanol in the safety pan. Fig. 16 ebios-fire Quadra-Inside Fig. 15 ebios insert A - ebios insert A - Housing...
Page 17: Initial Operation Of The Ebios Insert
3.3.1 INITIAL OPERATION OF THE EBIOS INSERT 9. Take the bottle for wetting the burner. Insert the bottle neck into the tank opening until submerged under the fuel. Squeeze the bottle for the air Proceed as follows: to escape and release slowly again for the fuel to be drawn in. Wait until 1.
Page 18: Topping Up With Fuel
3.4 TOPPING UP WITH FUEL 13. With the filled bottle, wet the burner mat with the fuel. The burner must NOT be filled when warm or burning and NOT via the burner channel! LIFE THREATENING! 14. Put the bottle aside. Wait at least 1 hour between extinguishing and refilling the burner! 15.
Page 19: Cleaning And Care
2.6 litres of 4. CLEANING AND CARE Bio-ethanol The ebios-fire Quadra Inside may only be cleaned when it is cold. 8. The fill level gauge indicates the maxi- 4.1 CLEANING OF TRIM COMPONENT mum permissible filling level. The maxi-...
Page 20: Maintenance / Troubleshooting
5. MAINTENANCE / TROUBLESHOOTING 5.3 BAD SMELL • The wicks and burner mat must be visually checked at regular intervals. • Fuel in the burner whilst not in use? The material is easily damaged. Therefore, do not fold or bend or do •...
Page 21: General Warranty Terms And Conditions
• Use of unsuitable or unspecified fuel. The recommended fuel for your The General Warranty Terms and Conditions apply only within the Federal ebios-fire is bioethanol with a concentration of more than 96%, mar- Republic of Germany and the European Union. The warranty period and keted by Spartherm Feuerungstechnik GmbH.
Page 22: Defect Remediation / Repairs
We our warranty we will remedy free of charge all defects demonstrably due to particularly advise you to have your ebios-fire products serviced regularly a material fault or manufacturing error, provided that the other terms and by a stove fitter/specialist dealer.
Page 23: Certification By Builder Of Custom-Built Furniture/Stove Containing With The Solitär Series
7. CERTIFICATION BY BUILDER OF CUSTOM-BUILT FURNITURE/STOVE CONTAINING WITH THE SOLITÄR SERIES The builder of any custom-built piece of furniture or stove unit containing the Solitär series, is obligated to confirm to the purchaser that the piece of furniture or stove was designed and built properly including correct instal- lation of the burner.
