ACX 60 DMX-controller
CLS ACX60
version 2.0 June 2012
- 1 -
www.cls-led.com
CLS Manuals
CLS Atmosphere LED-panel
INTRODUCTION
Thank you for choosing the CLS ACX60 DMX-controller. With the ACX60 you can program a maximum of 60 DMX-
channels, 40 chases and 24 scenes in a chase. The ACX60 has 6 hotkeys to switch fast to another chase.
Included items
The CLS ACX60 is shipped in one package containing the following items:
• 1 ACX60 controller
• 1 Power supply
• 1 Connection cable RJ11 - XLR
• 1 Connection cable RJ11 - RJ45
• 1 Connection cable RJ11 - 2 m
• 1 ACX60 splitter
• 1 Manual
Optional Accessories
• 707032
CLS LED-Powersupply for ACX60 9-12V new type
• 707035
CLS LDX3/05 LED dimmer 3x5A DMX controllable 12-24VDC
• 707037
CLS LDV-45 DMX LED dimmer 4 channels 5Amp 12V-48V output
• 707050
CLS ACX60 adapter RJ11 3 way
• 707051
CLS RJ11 RJ11 extension cord 2mtr
• 707052
CLS RJ11 RJ11 extension cord 5mtr
• 707053
CLS RJ11 RJ11 extension cord 7.5mtr
• 707060
Adapter cable RJ11-RJ45 5 mtr length for ACX60
• 707064
CLS conversion cable RJ11-XLR3 Female 50cm
NOTE: It is important to read this manual before you install or use this product.
SAFETY INFORMATION
Warning! This product is for professional use only. Read this manual before powering up or installing
the CLS ACX60. Follow the instructions listed below and observe all warnings in this manual.
Protection from electric shock
• Disconnect the power supply from AC power before installing, dismounting or maintaining the unit.
• Make sure all connectors are connected properly.
• Use only a source of AC power that complies with local building and electrical codes.
• Do not expose the unit to rain or moisture.
• Refer all service to a qualified technician.
Protection from burns and fire
• Do not install the ACX60 near a heat source.
• Do not install the ACX60 in a corrosive, flammable or explosive area.
• Do not modify the ACX60, or install other than genuine parts.
• Do not operate the unit if the ambient temperature exceeds 50°C.
Protection from injury due to falls
• Verify that all covers and mounting hardware is securely fastened
• Block access below the work area whenever installing or removing the unit.
- 2 -
www.cls-led.com
Advertisement
Related Manuals for Creative Lighting Solutions ACX60
Summary of Contents for Creative Lighting Solutions ACX60
- Page 1 Thank you for choosing the CLS ACX60 DMX-controller. With the ACX60 you can program a maximum of 60 DMX- channels, 40 chases and 24 scenes in a chase. The ACX60 has 6 hotkeys to switch fast to another chase. Included items The CLS ACX60 is shipped in one package containing the following items: •...
- Page 2 Factory-set (and maximum) is 60 DMX-channels. 3.1 Setting the dmx start address You have to select a start address for the controller, here you can set on which channel the ACX60 should start sending • If you are ready press the function-button [FCN] to save.
- Page 3 • You can change the wait-time (from 0.1 sec. to 99 min.) with the CH-buttons ([É] or [Ñ]). • Scroll with the %-buttons ([Å] or [Ç]) to see all 40 scenes. The ACX60 shows all scenes, also the scenes that not •...
- Page 4 ACX 60 DMX-controller 7.TIMER SETTINgS There are 4 different chase fade modes: mode 1, Mode 2, Mode 3, Mode 4 With timer settings you can set a date and time when there must be another chase. [Example] Monday till Friday Chase 2 Saturday till Sunday Chase 3...
- Page 5 Change it with the %-buttons. • First turn off the power supply. • Press and hold the [Å] or [Ç] + [FCN] + [OFF] buttons and power on the ACX60. • Press hotkey [1] to reset or press hotkey [2] to cancel.
- Page 6 ACX 60 DMX-controller WIRINg DIAgRAM TEChNICAL SPECIFICATIONS Power supply: 9-12 VDC ACX 60 Power consumption: Max. 0,3 Watt DMX protocol: DMX 512 Maximum DMX channels: Maximum scenes: Maximum chasers: 6 (maximum 24 scenes at each chaser) Housing: Steel frame Connector: RJ11 Dimensions: 120 x 116 x 55 mm (hxwxd)
