Summary of Contents for AFREEY ANC-818R
- Page 1 Dual Codec Pan/Tilt IR Network Camera Quick Installation Guide This guide describes the basic functions of Pan/Tilt IR Network Camera. All detailed information is described in the user’s manual.
- Page 2 Before Install ◎ Power off the Network Camera as soon as it is found smoking or smelt unusual. Contact your distributor when such cases happen. ◎ Keep the Network Camera away from the water. If the Network Camera is wet, power off immediately. Contact your distributor when such cases happen.
- Page 3 ◎ Do not place the Network Camera on unsteady surfaces. ◎ Do not touch the Network Camera when it’s lightening. ◎ Do not disassemble the Network Camera. ◎ Do not drop the Network Camera. ◎ Do not manually pan and tilt the Network Camera when are power is on. ◎...
- Page 4 1. Package contents ◎ The Network Camera ◎ Quick Installation Guide (Wire or Wireless model) ◎ Power adapter ◎ Camera stand ◎ Software CD ◎ Antenna for wireless model only...
-
Page 5: Hardware Description
2. Hardware description ◎ Front panel Antenna for wireless model only Infrared LEDs and light sensor Lens Microphone Front LEDs ◎ Rear panel Antenna for wireless model only LAN Socket DC Power Jack... - Page 6 3. Install your Network Camera in Ethernet network Antenna for wireless model only 1. Use Ethernet cable to make connection from Ethernet port to the hub. * Use Category 5 Cross Cable when the Network Camera is directly connected to PC. 2.
- Page 7 4. Assign IP address 1. Run the IP Finder under the Software Utility directory from software CD. 2. The program will search the cameras on the same LAN. 3. After searching, the Network Camera will be found. Click on ip address and then click “Link”...
- Page 8 5. Connects to the Network Camera For detail setup and further configuration, please check user’s manual on the software CD.
- Page 9 6. Client Settings (Windows 2000) At the initial access to the “Connection type” page in Windows, the web browser will ask for a new plug-in installation, the plug-in being the Network Camera. This plug-in has been registered for certification and can be used to change the parameters at the client’s site.
- Page 10 3. Lower down the security level bar to “Low”, and press “Apply” Refresh IE Browser, a question frame will pop-up to ask for download Active-X. press “Install”.
- Page 11 7. Client Settings (Windows XP) 1. Initial IE browser, select function item “Tools”-> “Internet Options” 2. Security-> Custom Level...
- Page 12 3. Check “Enable” or “Prompt” in the list of Download unsigned ActiveX controls 4. Refresh IE Browser, a question frame will pop-up to ask for download Active-X. press “Install”.
