ADDLESTONE BH184 Installation Manual

TYPE BH184
VIDEO LAUNCH AMPLIFIER / VDA UNIT
Installation Guide
CAUTION
 Protect unit and power supply from rain / excessive moisture.
 Do not use the 12V power supply if its casing has been damaged.
APPLICATION
The BH184 unit combines a Video Launch Amplifier and Video Distribution Amplifier in one
unit. Installed at the camera it will function as a Launch Amplifier to improve picture quality
and increase transmission distances. Used at the control room end of the cable run it will
function as a Distribution Amplifier, splitting the video signal into two identical outputs with no
loss of signal strength or quality.
PACKAGE CONTENTS
When you open the packaging you should find the following:
1 x BH184 unit
1 x Type BH98 12V DC Regulated Power Supply
1 x Installation Guide
CARE AND MAINTENANCE
Following installation the BH184 unit should require little or no maintenance.
If required clean unit using damp cloth with a little mild detergent (having first disconnected
the power supply). The coax signal cables may be fitted or removed without disconnecting
the power supply.
END OF LIFE DISPOSAL
When this product eventually reaches the end of its working life it needs to be disposed of
correctly to prevent damage to the environment. It should not be disposed of with general
household type waste.
If you phone WeeeCare plc on 0844 800 2004 and quote our Account Number 135027 they
will arrange collection of this product from you. They will then correctly dispose of the unit
and recover any materials that may be recycled and reused. There will be no charge to you
for this service.
