Tyco R/C G3474-0920 User Manual

7.2V R/C
7.2V R/C
X
CAUTION: Surfaces may become hot and cause burns if
electronics get wet. Do not operate vehicle through
water or snow.
I.CONTENTS/FEATURES
Vehicle
Transmitter
7.2v Battery pack
7.2v wall charger
6AA Batteries
Vehicle
q Steering adjuster control
*
For when your vehicle appears to veer to either the right or
left. use screwdriver (not included) to turn the knob in the
direction necessary to correct the vehicle's alignment.
w Try-Me button to activate lights and sounds
e 4AA battery door
r 7.2v battery latch
t 7.2v battery door
y ON/Fender lights/OFF/Try-Me (lights and music) switch
*
This switch has 4 positions:
I Vehicle On: Vehicle runs with music effects
and lights as you drive (In this mode vehicle will
perform at low speed)
Ä
Fender lights "on" only (Vehicle no movement forward)
O Vehicle OFF
Ä
F
/
Try-Me On: Activates 'try me' function with lights and
music effects(In this mode vehicle cannot be
driven)
u Media player music(MP3/CD's)/OFF/Cruise music switch
*
This switch has 3 positions:
ß
Vehicle runs with internally stored music (In this mode
vehicle will perform at low speed)
O Vehicle runs with no music (In this mode vehicle
will perform at maximum speed)
H
Vehicle runs with your MP3 or CD music player (In this
mode vehicle will perform at low speed)
*
Note: Both the switches turn to "0" position after run your
vehicle or your MP3/CD music end.
i Fender lights
o Trunk lock-use coin (not included) to open trunk after trunk lock
a Media player plug (for direct input into most media players)
*
Media player should first be placed into the the protective
sleeve and then plugged in. (The music player is not included)
*
Adjust the volume of the music using the volume control on
your music player.
s Protective media player sleeve
Transmitter
q Antenna
w Left & Right controls
e Forward & Reverse controls
r Battery door
CAUTION-ELECTRIC TOY:
8 YEARS OF AGE. AS WITH ALL ELECTRIC PRODUCTS,PRECAUTIONS SHOULD BE
OBSERVED DURING HANDLING AND USE TO PREVENT ELECTRIC SHOCK. INPUT:
120VAC, 60Hz, 12VA. OUTPUT:8.5VDC, 420mA, 3.6W.
®
TYCO R/C SUPPORT
Questions or problems with your product?
DON'T RETURN IT TO THE STORE!
Just call us for help.
U.S. consumers may also register their products at this number.
1 888 557-TYCO (8926)
tycorc.com
Keep these instructions for future reference: they
contain important information. IMPORTANT: Please
read all "Consumer Information" before operating your
vehicle.
q w
i
y
a
q
NOT RECOMMENDED
FOR CHILDREN UNDER
G3474-0920
G3474-S1
e r t
u
S Q
o
s
w
e
r
i
