RS232/RS485 Converter User's Guide
DISCLAIMER:
RMV ELECTRONICS INC. does not assume any liability arising from the application and/or use of
the product/s described herein, nor does it convey any license. RMV ELECTRONICS INC. products are not authorized
for use as components in medical, life support or military devices without written permission from RMV ELECTRONICS
INC.
The material enclosed in this package may not be copied, reproduced or imitated in any way, shape or form without the
written consent of RMV ELECTRONICS INC. This limitation also applies to the firmware that the Integrated Circuits in
this package might contain.
WARRANTY:
RMV ELECTRONICS INC. will replace, free of charge, faulty components in this package with the
exception of the Integrated Circuits it might contain, for a period of 6 months after the date of purchase.
Chapter 1 INTRODUCTION
The RS232/RS485 converter allows the user to interface any device that uses an RS232 serial link to an
RS485 link. The RS485 link was conceived for long distance data acquisition and control applications.
The original specifications (which have been surpassed by the present hardware), supports a network of
up to 32 stations on the same lines, at speeds up to 115,200 baud to distances of 4,000 feet (1,200 meters).
The link is balanced so that any electrical noise getting into one of the lines also gets into the other line
thus allowing the receiver to cancel both noise signals.
RS485 links are much used in industrial process control where reliability is important. Also, the ability to
communicate over a long distance at a high speed is important for industrial plants where the stations
might be spread over a large area.
It is very common to have a PC in charge of controlling a given process. PC's in general have an RS232
serial port (COM port) and therefore there are two solutions to linking the computer to an RS485
network. One, is to install an RS485 interface in an expansion slot of the computer, and the other is to
convert the RS232 level signal coming out the computer serial port to an RS485 signal. This is what the
RS232/RS485 converter does. The converters are designed to work with the RMV Electronics RS485 line
of Data Acquisition and Control Boards. The RS485 Boards are specifically built for process control but
they can also be used back to back thus providing an RS232/RS485/RS232 link. This way, two computers
or devices using a standard RS232 serial port can communicate with each other at a maximum of 115,200
Bauds over a distance of up to 4000 feet, something impossible to achieve using an RS232 link. One
interesting application for using two RS232/RS485 converters back to back is when a computer needs to
be connected to an I/O-232 board at a distance longer than usual. This provides very good performance
while maintaining the simplicity of the RMV I/O-232 line of Data Acquisition and Control Boards.
