Malanbao Lighting Equipments DFW-X1 User Manual

Water low fog machine
Hide thumbs
Table of Contents

Advertisement

Quick Links

DFW-X1
WATER LOW FOG MACHINE
USER MANUAL
Please read over this manual before operation the machine

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DFW-X1 and is the answer not in the manual?

Questions and answers

Summary of Contents for Malanbao Lighting Equipments DFW-X1

  • Page 1 DFW-X1 WATER LOW FOG MACHINE USER MANUAL Please read over this manual before operation the machine...
  • Page 2 CONTENTS 1. INTRODUCTION 2. SAFETY INSTRUCTIONS 3. DESCRIPTION OF PARTS 4. FLUID 4.1 GENERAL NOTES 4.2 STORAGE AND A POINT FOR ATTENTION OF THE FLUID 5. OPERATING THE DATA 5.1 PUTTING INTO OPERATION 5.2 OPERATION DISPLAY 5.3 DMX CONTROL 5.4 FLUID PROTECTION 6.

  • Page 3: Introduction

    1. Introduction Water Low Fog Machine is a newest low smoke effects revolutionary innovation. Only consume water and low fog liquid !!! Energy efficiency and environmental protection but large smoke output. Machine install in flight case with wheel, convenient transportation and handling! 2.
  • Page 4 ⑦ Power Switch ⑧ Fuse（15A） ⑨ Power line input ⑩ 2L Water low fog liquid tank ⑾ Water low fog liquid tube ⑿ Fast connector ⒀ Water input This is a auto water feeder when water less than normal level! Put the liquid tube into the bottle, it will put the water from bottle into machine automatically.

  • Page 5: Fluid

    4.Fluid 4. 4.1 General notes (1) To guarantee trouble-free operation the special “Water Low Fog Liquid“ must be used.Use of other liquids will void the manufacturer‘s warranty and can be dangerous to your health. (2) The Water Low Fog Liquid is 4bottles in a carton, 5liter per bottle. You can buy from the local dealer.

  • Page 6: Operation Display

    5.2 Operation display 5.21 FUNC Menu Picture 4 Adjust the output (Picture 4). Press FUNC one time, appear Picture 4, it means adjust the output, press UP and DOWN, it can adjust 1%~100% output, press VOLUM, it can jet immediately. Picture 5 Interval time (Picture 5).

  • Page 7: Dmx Control

    Picture 7. Smoke Output （Picture 7）. Press FUNC four times continuously，appear Picture 7, it means adjust the smoke output, press UP and DOWN, it can set 1%~100% smoke output. Picture 8. DMX adjust (Picture 8). Press FUNC six times continuously，appear Picture 8, press UP and DOWN, it can adjust 1~511 DMX start address.

  • Page 8: Wireless Controller

    If the tank still have liquid inside but the machine show “ Out Order”, please check the liquid tube and fast connector of bottle cap firstly and then check the pump. Picture 9. Fluid protection 5.5 FLUID PROTECTION SYSTEM ON AND OFF SETTING METHOD If you press many times “...

  • Page 9: Trouble-Shooting

    ※ Remove the filter,which protects the fan against dust and dirt,from time to time and clean it. ※Check the state of the fluid filter from time to time and clean or replace it when necessary. ※After several hours of operation,some droplets of condensation will have formed at the nozzle. That is normal and not a malfunction.

  • Page 10: Warranty Conditions

    Controller:LCD controller & Wireless controller & DMX512(1CH) Electronic temperature control system Water level sensor systems Fluid protection system Non-leak bottle N.W.:39.5KG Size:55*37*47.5cm 11. Warranty conditions 1. Free of charge, we will repair any defect or fault in the unit if it is caused by a proven factory fault and has been advised immediately after appearance and within 12 month of delivery to the end user.
