Barracuda Networks CudaCam Quick Start Manual

Dome ip camera
Hide thumbs Also See for CudaCam:
Table of Contents

Advertisement

Quick Links

Download this manual
CAM
CudaCam
Dome IP Camera

Quick Start Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CudaCam and is the answer not in the manual?

Questions and answers

Related Manuals for Barracuda Networks CudaCam

Summary of Contents for Barracuda Networks CudaCam

  • Page 1: Quick Start Guide

    CudaCam Dome IP Camera Quick Start Guide...
  • Page 2 Barracuda Networks reseller, whom we will be happy to coordinate with in order to provide additional deployment support. Thank you again for choosing the CudaCam Dome IP Camera. We encourage you to contact your reseller or our Technical Support team that is available around the clock to assist with technical questions or concerns.
  • Page 3 Table of Contents Setup 1. Create Your CudaCam Account 2. Wi-Fi Settings (Wi-Fi Users Only) 3. Determine How and Where to Mount Camera 4. Mount the Camera 5. Connect Ethernet Cable and Ensure Power 6. Aim and Focus the Camera 7.

  • Page 4: Create Your Cudacam Account

    Create Your CudaCam Account If you are a first time CudaCam user, create your CudaCam account. In a web browser, navigate to: http://www.cudacam.com Click the Camera Login button and then click I am a new user and complete the web form to create your account.

  • Page 5: Determine How And Where To Mount Camera

    Determine How and Where to Mount Camera You must install the camera as a sealed unit, with no path for moisture to enter. If not sealed, condensation can form inside the dome, blurring the camera view. Mounting options: The falcon dome camera can be surface mounted to a wall or ceiling, or it can be mounted recessed into a ceiling using a recessed mounting kit.

  • Page 6: Mount The Camera

    Mount the Camera Avoid Moisture The camera interior must remain dry. Any moisture in the camera can result in fogging and poor camera performance. Remove the Cover Using the supplied security screwdriver, release the four screws holding the clear dome assembly in place and remove the dome assembly. Physically Mount Camera If using conduit, seal the entry point carefully.

  • Page 7: Connect Ethernet Cable And Ensure Power

    Connect Ethernet Cable and Ensure Power Attach the Ethernet Cable. It is a very tight fit which may require some patience. The camera is powered by its PoE cable. You must use a 48 Volt Ethernet power injector or a PoE switch to provide power. PoE Injector PoE Switch If the LED does not light within 30 seconds after inserting the Ethernet jack,...

  • Page 8: Aim And Focus The Camera

    Aim and Focus the Camera Caution! Adjust the camera view only from the knurled base and camera mount assembly. Twisting the lens damages the camera. DO NOT Handle Rotate Lens Vertical Adjust Horizontal Adjust or Twist Lens with Knurled Base with Knurled Base with Lens Frame Check the field of view using a web browser or mobile device.

  • Page 9: Prepare And Seal The Camera

    Prepare and Seal the Camera Critical! To avoid fogging on the inside of the camera due to trapped moisture, the air in the camera must be completely dry. Inspect the three screw mount locations to ensure that the screws are snug and the rubber seals are compressed.

  • Page 10: Support

    Online Support • For additional product information, configuration instructions or supporting materials, visit www.cudacam.com. • Please email support@barracuda.com Telephone Support • For urgent matters, please call Technical Support at 408.342.5300. Phone lines are open 24 hours a day, 7 days a week.
  • Page 12 20cm between the radiator & your body. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. Warning: Any changes or modifications not expressly approved by Barracuda Networks, Inc. could void the user’s authority to operate the equipment.
  • Page 13 Copyright Information Copyright 2016 Barracuda Networks, Inc. All rights reserved. Use of this product and this manual is subject to license. Information in this document is subject to change without notice. CudaCam and Barracuda are trademarks of Barracuda Networks, Inc.
  • Page 16 Copyright 2016 Barracuda Networks Inc. 3175 S. Winchester Blvd., Campbell, CA 95008 408-342-5400/888-268-4772 (US & Canada) barracuda.com Dome-160429-01-fg...
