GoodMeasure Integrator
Installation Guide for EDMI MK7A Meters
• Before installation, check that you have a portable computer that you
can use while on site to login to
installation
•
The Integrator must be installed by authorised persons in accordance with
safe working practices.
•
The Integrator is designed to be installed under the terminal cover of an EDMI
MK7A Smart Meter. These instructions assume that the meter has been
installed and is ready for service.
This guide shows you how to do the following steps:
1. Setup a hotspot device for temporary Internet access
2. Mount and connect the GoodMeasure Integrator (shortened to Integrator
subsequently)
3. Connect the Integrator to the permanent local WiFi network
4. Setup the meter or other device(s) to be read online through GoodMeasure
Step 1: Setup a Hotspot Device for Temporary Internet Access
There are three options for providing temporary Internet access. This step can be done at any time
before the Integrator hardware installation.
[Note: Some details may vary with different phone or access point makes and models.]
Android smartphone hotspot option
1. Ensure mobile data is enabled
2. Go to phone Settings menu
3. Select Wireless and Networks and then
Tethering and Portable Hotspot
4. Tick the box next to Portable Wi-Fi Hotspot
5. Tap Portable Wi-Fi Hotspot Settings
6. Set the SSID to 'goodmeasure' and
Password to '12412280'
Mobile access point option
1. Ensure the Mobile Access Point has data enabled and a credit balance for SIM data
2. Login using the Mobile Access Point's credentials
3. Locate the Settings menu
4. Locate the Wireless LAN menu and Settings
5. Change the SSID to 'goodmeasure' and the Password/Key to '12412280'
6.
Make sure that: Authentication is set to WPA/WPA2-PSK, Encryption Mode is set to
AES+TKIP and SSID Broadcast is enabled
GoodMeasure Integrator Installation Guide v3.1
www.GoodMeasure.net
iOS/ iPhone hotspot option
1. Ensure mobile data is enabled
2. Go to phone Settings menu
3. Select Personal Hotspot
4. Tap on Wi-Fi Password and edit the
password to '12412280'
5. Go back to Settings
6. Select General
7. Select About
8. Select Name and edit the name to
'goodmeasure'
www.goodmeasure.net
during the
Page 1
Advertisement
Table of Contents
Summary of Contents for GoodMeasure EDMI MK7A
- Page 1 2. Mount and connect the GoodMeasure Integrator (shortened to Integrator subsequently) 3. Connect the Integrator to the permanent local WiFi network 4. Setup the meter or other device(s) to be read online through GoodMeasure 5. Fit and seal the meter terminal cover 6. Not working? – Troubleshooting Step 1: Setup a Hotspot Device for Temporary Internet Access There are three options for providing temporary Internet access.
- Page 2 Twist the cable one full turn anticlockwise then rotate plug inwards to insert into the Integrator socket as shown in image 4 above. This twist helps prevent the terminal cover snagging on the cable during reassembly. GoodMeasure Integrator Installation Guide v3.1 www.goodmeasure.net Page 2...
- Page 3 Stay off once connected and operating The GoodMeasure administrator must now login to GoodMeasure to configure the Integrator settings and to connect to a permanently available local WiFi SSID. Step 4: Login to GoodMeasure The installation is not complete until the following steps are performed.
- Page 4 This step requires an Integrator to be powered on and able to communicate with the Internet through a local tethering point such as a smart phone hotspot that has the GoodMeasure default SSID and Password already setup. For details of these settings see Step 1 and check the status lights as per Step 3.
- Page 5 2. Select the Integrator device from the middle menu Select NETWORK on the right side of the screen 4. GoodMeasure will display a list of WiFi access points that the Integrator can see. 5. In the Visible SSIDs list Click the button next to the preferred access point 6.
- Page 6 Serial – The serial number of the meter as supplied by FCL Prefilled fields – only change as necessary e. Port – This is the Port on the GoodMeasure Integrator that the device is physically connected to. i. If the EDMI meter is wired to the Integrator using a GoodMeasure supplied cable, it is Port 2.
- Page 7 2. When re-fitting the terminal cover, it may be necessary to trim the internal plastic rib to prevent snagging. Trim if required Secure the terminal cover once it is fully attached and fit the cover seal. GoodMeasure Integrator Installation Guide v3.1 www.goodmeasure.net Page 7...
- Page 8 Check with the site owner that no restrictions or limitations have been applied to the site’s WiFi access If GoodMeasure is unable to read data from the EDMI meter… • Check Step 8 that the device has correct meter details: Port=port2, Baud rate=9600, framing=8n1, User ID and password correct, Serial=meter serial number.
