Summary of Contents for Test-Ok eC-test-mate
- Page 1 Hardware Reference Manual Version 1.1.0.0. 10/21/2014 Copyright © TEST-OK. All Rights Reserved. 1 / 35...
- Page 2 Table of contents Overview ..................3 eC-test-mate types ..............4 eC-test-mate Type I (TCC 211) ..........5 Functional description ................. 5 Analog Inputs (101..104) ................5 Analog Outputs (101..104) ................7 Digital Inputs (101..104) ................8 Digital Outputs (Group 101 and 102) ............9 Bi-Directional Digital I/O ................
-
Page 3: Overview
Each Test Probe type has a unique footprint so that it is impossible to connect a Test Probes to the wrong test points. An eC-test-mate Docking Station is available as well. The main advantage of plugging a Test Probe into the Docking Station is that the power that can be delivered by the Test Probe's power supply is increased. The USB standard limits the output current to 500mA which results in a maximum output power of 2.5W. -
Page 4: Ec-Test-Mate Types
If the Unit Under Test (UUT) requires more test points then there are available on one or when the mix of required test functions is not available from a specific eC-test-mate type, then it is possible to combine multiple eC-test-mates. -
Page 5: Ec-Test-Mate Type I (Tcc 211)
A block diagram of the eC-test-mate Type I is shown in the figure below: The eC-test-mate Type I board is connected to a PC via USB. Via this connection, information about outputs to be set and values of inputs are exchanged about five times per second. - Page 6 1 mV Accuracy: 20mV or 0.2% Sampling rate: 2kHz with digital filtering. The maximum allowed input voltage that will not result in damage is 44V. Associated test command(s): • TEST_ANALOG • MAP Copyright © TEST-OK. All Rights Reserved. 6 / 35...
-
Page 7: Analog Outputs (101..104)
Output specifications Input range: 100mV .. 24V Resolution: 6 mV Accuracy: 100mV .. 1V 20mV 1V and higher 0.1% (typically 0.05% above 3V) Associated test command(s): • SET_ANALOG • MAP Copyright © TEST-OK. All Rights Reserved. 7 / 35... -
Page 8: Digital Inputs (101..104)
Inputs 101..104 are located on the same test pins as (open collector) output bits 1..4 of group 102, making them useful for testing bidirectional signals. Note however the 330R resistor between the open collector output and the test pin!!! Associated test command(s): • TEST_DIGITAL • MAP Copyright © TEST-OK. All Rights Reserved. 8 / 35... -
Page 9: Digital Outputs (Group 101 And 102)
Note: the internal 100R resistor can only dissipate 100mW. E.g. when the output is programmed for 5V and 24V is applied on the corresponding EC-test-mate pin, then there will be a voltage of 18.5V across the 100R resistor which would result in 3.4W dissipation! Note: besides the maximum current, there is also a limit on dissipated power by the outputs. -
Page 10: Bi-Directional Digital I/O
• MAP Bi-Directional Digital I/O With the eC-test-mate Type I, it is possible to test up to 4 bi-directional digital signals. As described in previous two sections, the 4 output bits of Group 102 are located on the same connector locations as digital inputs 101..104. -
Page 11: Serial Channel (Uart 101)
Note 1: the naming of the connector pins is as seen from the eC-test-mate. SERIAL_TX is therefore an output on which the data towards the UUT is provided by the EC-test-mate and SERIAL_RX is an input on which data from the UUT is received. - Page 12 STX, ETX and DLE in the packet data. Thus, when receiving DLE, then this byte shall not be added to the packet but the next received byte shall be added without interpreting the received value as STX, ETX or DLE. Values used by the eC-test-mate Type I: STX = 0x0F (15 ETX = 0x04 (4...
-
Page 13: Programmable Power Supply (Supply 101)
The two figures at the end of this section show the available output current and power for a number of output voltages. Note: trying to draw more power from a standard USB port than it can provide will result in the eC-test-mate to temporarily disconnect (due to a reset of the USB circuitry). -
Page 14: Board Presence
BOARD_DETECT. Note: it is mandatory that the Board Detect pin of every eC-test-mate that is used in a test is connected to GND on the UUT when using the TEST-TRACK or eC-my-test software, since a test cannot be started when no board under test is detected. -
Page 15: Pin Assignment Type I
1.5..24V, 6mV resolution (12-bit DAC) Max. 7W or 1A when used with TEST-Mate docking station. Without the docking station, the maximum depends on the power capabilities of the USB port (2W typical) Copyright © TEST-OK. All Rights Reserved. 15 / 35... - Page 16 Copyright © TEST-OK. All Rights Reserved. 16 / 35...
-
Page 17: Footprint Technical Drawings Type I
Footprint technical drawings Type I Copyright © TEST-OK. All Rights Reserved. 17 / 35... - Page 18 Copyright © TEST-OK. All Rights Reserved. 18 / 35...
-
Page 19: Ec-Test-Mate Type Ii (Tcc 212)
RS485, I2C and UART. Functional Description This section describes all the functional blocks of the eC-test-mate Type II which is specialized for testing UUTs with communication interfaces. Besides the electrical specification of the interface pins on the connectors of the eC-test-mate Type II there are also references to the TEST-OK Description Language (TDL) commands that can be used to control the functional blocks. -
Page 20: Digital Inputs (201..204)
'1' level of the serial interface. If left open, the UART_TX output will NOT work. Note 2: The internal eC-test-mate UART is shared between the UART test pins and the RS485 test pins. Depending on the last configuration command, either the UART pins or RS485 pins will be active. -
Page 21: Rs485 (Rs485 201)
Driver output current: -60..+60 mA Note 1: The internal eC-test-mate UART is shared between the UART test pins and the RS485 test pins. Depending on the last configuration command, either the UART pins or RS485 pins will be active. If the RS485 interface is inactive, the eC-test-mate's RS485 driver will be in the high-impedance state. -
Page 22: I2C (I2C 201)
Transient Voltage diodes protect the outputs against voltages above 5V if such a voltage is inadvertently applied to the test pins. Applying more than 8V for longer periods to these test pins may damage the eC-test-mate. Currently, the SCL clock frequency is fixed at 100kHz Associated test command(s): •... -
Page 23: Pin Assignment Type Ii
1.5..24V, 6mV resolution (12-bit DAC) Max. 7W or 1A when used with TEST-Mate docking station. Without the docking station, the maximum depends on the power capabilities of the USB port (2W typical) Copyright © TEST-OK. All Rights Reserved. 23 / 35... - Page 24 Copyright © TEST-OK. All Rights Reserved. 24 / 35...
-
Page 25: Footprint Technical Drawing Type Ii
Footprint technical drawing Type II Copyright © TEST-OK. All Rights Reserved. 25 / 35... - Page 26 Copyright © TEST-OK. All Rights Reserved. 26 / 35...
-
Page 27: Ec-Test-Mate Type Iii (Tcc 213)
This section describes all the functional blocks of the eC-test-mate Type III. Besides the electrical specification of the interface pins on the connectors of the eC-test-mate Type III there are also references to the TEST-OK Description Language (TDL) commands that can be used to control the functional blocks. -
Page 28: Analog Outputs (301..304)
Programmable Power Supply (Supply 101) for full specifications. Board Presence Board Presence for a detailed description of this function. Note: this pin MUST be connected to GND on the PCB under test. Copyright © TEST-OK. All Rights Reserved. 28 / 35... -
Page 29: Pin Assignment Type Iii
Output: 2.5..24V, 6mV resolution (12-bit DAC) Digital Output 301.2 Digital Output 301.3 Digital Output 301.4 Digital Output 301.5 Digital Output 301.6 Digital Output 301.7 Supply 301 1.5..24V, 6mV resolution (12-bit DAC) Copyright © TEST-OK. All Rights Reserved. 29 / 35... - Page 30 Max. 7W or 1A when used with TEST-Mate docking station. Without the docking station, the maximum depends on the power capabilities of the USB port (2W typical) Copyright © TEST-OK. All Rights Reserved. 30 / 35...
- Page 31 Copyright © TEST-OK. All Rights Reserved. 31 / 35...
-
Page 32: Footprint Technical Drawing Type Iii
Footprint technical drawing Type III Copyright © TEST-OK. All Rights Reserved. 32 / 35... - Page 33 Copyright © TEST-OK. All Rights Reserved. 33 / 35...
-
Page 34: Ec-Test-Mate Docking Station
Docking Station are electrically isolated from the PC and from the mains power supply. For correct functioning of the eC-test-mate kit only use the adapter that is provided with the Docking Station (a medical type AC-DC adapter, 9VDC 25-30 Watt) Copyright ©... -
Page 35: Ec-Test-Mate Dimensions
Dimensions Copyright © TEST-OK. All Rights Reserved. 35 / 35...
