- Page 1 TrikeTransporter.com Vancouver, BC Canada MANUAL...
- Page 2 TrikeTransporter.com Vancouver, BC Canada Warranty Period： The guarantee period is two years from the date of purchase, applicable to the seller of vehicles unloaded from the container, under normal use and maintenance. The guarantee period does not include these circumstances: improper maintenance, assembly, change, abuse, negligence, the use of non-seller of accessories and damaged accessories.
- Page 3 TrikeTransporter.com Vancouver, BC Canada Content INTRODUCTION…………………………………………………………04 1. SAFETY – A BRIEF INTRODUCTION…………………………………05 2. IMPORTANT SAFETY INFORMATION……………………………06 3. SAFETY SIGNS………………………………………………………07 4. DAILY CHECK…………………………………………………………08 5. ASSEMBLY INSTRUCTION………………………………………10 6. MAINTENANCE………………………………………………………22 7. REGULAR CHECKS……………………………………………………24 8. SPECIFICTIONS…………………………………………………………25...
- Page 4 Vancouver, BC Canada FORE WORD: Thank you for choosing TRIKE TRANSPORTER We hope you like it. Please read the manual carefully before operating, as it contains safety and maintenance information. Failure to read this can lead to potential danger in the future.
- Page 5 TrikeTransporter.com Vancouver, BC Canada 1. SAFETY - A BRIEF INTRODUCTION INTRODUCTION Make sure to drive the trike safely. We provide this operational handbook to help you make rational decisions. All the information will remind you to avoid being injured. It is unrealistic and impossible to mention all the aspects of safe riding and maintenance, however this is a logical approach.
- Page 6 TrikeTransporter.com Vancouver, BC Canada 2. IMPORTANT SAFETY INFORMATION You can do lots to protect your safety when the vehicle is operating. You can find many useful suggestions in the handbook, here are some important suggestions as follows: It is forbidden for children under 16 years in the absence of adults to drive the vehicle. Exceeding the capacity of the vehicle is the main factor causing accidents.
- Page 7 TrikeTransporter.com Vancouver, BC Canada vehicle safety. Please read it carefully. 3. SAFETY SIGNS Make sure you and the trike are both in the good condition before riding. In order to help you, we will discuss how to evaluate your driving state, which part you should check, and how to make your trike comfortable, convenient and safe.
- Page 8 TrikeTransporter.com Vancouver, BC Canada ★Dress appropriately for driving the trike. ★Make sure you haven't used alcohol or drugs. ★A little alcohol can cause danger and make you incapable of controlling the trike well. ★Drugs can be dangerous when driving, even prescriptions from your doctor. Make sure you can drive the trike safety after you take medicine.
- Page 9 TrikeTransporter.com Vancouver, BC Canada ●Bell: Make sure the bell works well. ●Reflector: Make sure the reflectors are clean. ●Speed switch (gear switch): Get used to using the gears and make sure they work normally.
- Page 10 TrikeTransporter.com Vancouver, BC Canada 5.ASSEMBLING INSTRUCTION ●Frame and seat assemblage picture Thread glue painted to lock the nuts and bolts till achieving our torque standard. ● Canopy and passenger seat fixing picture...
- Page 11 TrikeTransporter.com Vancouver, BC Canada Bracket fixing dot...
- Page 12 TrikeTransporter.com Vancouver, BC Canada Seat fixing dot Rain cover fixing dot...
- Page 13 TrikeTransporter.com Vancouver, BC Canada Put the bending tube inside, wipe some thread glue, lock the bolts and nuts till they achieve the tensional standard. Place for fixing the gas spring...
- Page 14 TrikeTransporter.com Vancouver, BC Canada...
- Page 15 TrikeTransporter.com Vancouver, BC Canada Finished canopy Put the strut into the fixing position, fasten the bolt with thread glue till achieving the torque standard.
- Page 16 TrikeTransporter.com Vancouver, BC Canada ●Fixing front wheel: Put the strut into position; fasten bolt and nuts with thread glue till achieving our tensional standard.
- Page 17 TrikeTransporter.com Vancouver, BC Canada ●Fixing the rear wheel:...
- Page 18 TrikeTransporter.com Vancouver, BC Canada Place for the rear wheel Place for the brake disc...
- Page 19 TrikeTransporter.com Vancouver, BC Canada Fixed plate The hole position of the brake...
- Page 20 TrikeTransporter.com Vancouver, BC Canada Put the six screws which outstand inside of right wheel (has been installed brake disc) into the fixed plate, and then fix the brake into the hole. ●Note: While you are installing the brake, you can adjust the distance between the brake clamp and brake disc to ensure the performance of brake.
- Page 21 TrikeTransporter.com Vancouver, BC Canada Put the strut into the fixing position, fasten bolt and nuts with thread glue till achieving our tensional standard.
- Page 22 Spray atomization lubricating oil on drive chain, lubricate chain. ★Chain Adjustment Check the chain after the first 24 hours of using your Trike Transporter. If it’s too loose, it needs readjustment. ●Loosen No.1 nut ●Screw No.2 nut half round deasil, then screw No.1 nut.
- Page 23 Vancouver, BC Canada ★Storage Note If you haven’t used your Trike Transporter in over 30 days orif your putting it in storage, please do as follows: ●Please clean your trike, make the trike body is clean and dry, especially the rusty parts.
- Page 24 TrikeTransporter.com Vancouver, BC Canada 7. Regular Inspection and Maintenance The following inspection periods depend on normal circumstance; it needs m o r e frequent maintenance in dusty or wet areas. Item First week Monthly Quarterly Yearly Tire pressure and abrasion, braking capability, Loose bolts C、A、L...
- Page 25 TrikeTransporter.com Vancouver, BC Canada 8. Technical Specification ★Whole trike: Length: 2350mm, Width: 1150mm, Height: 1860mm ★Rear wheels distance: 1110mm ★Rear axles distance: 1900mm ★Distance from ground: Min. 130mm Max.400mm ★Tire spec: Front wheel: 20”- 2.125” Rear wheel: motorcycle wheel size 2.75”- 19” ★Loading weight: 400kgs...
- Page 26 TrikeTransporter.com Vancouver, BC Canada...
